Eagle Talon Ignition Coil Guide: 1990-1998 Models
Everything you need to know before replacing the ignition coil on your 1G or 2G Eagle Talon.
- A failing ignition coil causes misfires, rough idle, and potential no-start conditions.
- OEM-quality aftermarket brands like Delphi, Hitachi, and NGK are reliable choices for most owners.
- The coil pack is different between 1G (1990-94) and 2G (1995-98) models due to the mounting bracket.
- Consider testing or replacing the power transistor (ignitor) as well, as it is another common failure point with similar symptoms.
Is Your Eagle Talon's Ignition Coil Failing?
A bad ignition coil is a common problem on older cars like the 1990-1998 Eagle Talon. The constant heat cycles under the hood can cause the internal windings of the coil to break down over time. This leads to a weak or inconsistent spark, which can cause a variety of engine performance issues. If you're experiencing problems like engine misfires, especially under boost, a faulty coil pack is a likely suspect.
Choosing the Right Aftermarket Ignition Coil
The original factory ignition coils on the DSM platform were very robust and are often considered sufficient even for high-horsepower builds. However, after 25+ years, failure is common. When shopping for a replacement, you have several good options.
Brand Quality Tiers for Eagle Talon
- OEM-Equivalent Quality: Brands like Delphi, Hitachi, and NGK are well-regarded in the DSM community and are known for producing reliable parts that meet or exceed original factory specifications. These are excellent choices for a stock or mildly modified Talon and offer a great balance of quality and price.
- Performance Upgrade: MSD offers a popular performance coil pack. It's designed to provide a hotter, more powerful spark, which can be beneficial for highly modified, high-boost engines. However, for a stock or near-stock vehicle, it's generally considered overkill, and the stock-style coils are more than adequate.
- Standard Replacement: Brands like Standard Ignition (SMP), Spectra, and Walker Products offer affordable, direct-fit replacements that are a good option for daily drivers on a budget. While they may not have the high-performance reputation of other brands, they provide a functional and cost-effective solution.
Pro Tip: Check the Ignitor (Power Transistor)
The ignition system on the Eagle Talon also uses a separate component called a power transistor, or ignitor. This part works with the coil to control the spark. It is another common failure point and can produce the same symptoms as a bad coil. If you replace your coil and still have a no-spark or misfire issue, the ignitor is the next part to test.
1G vs. 2G Talon: What's the Difference?
The ignition coils for first-generation (1990-1994) and second-generation (1995-1998) Talons are electrically very similar. However, they use different mounting brackets. While they can be interchanged if you modify the bracket, it's easiest to buy the correct part for your year range. Also, be aware that 1990 models have a unique ignition setup compared to 1991-1994 cars, so double-check fitment for that specific year.
Cost to Replace an Eagle Talon Ignition Coil
| Part Type | Estimated Cost |
|---|---|
| New Aftermarket Coil | $17 - $201 |
| Used OEM Coil | $40 - $60 |
| Shop Labor | $75 - $150 |
Frequently Asked Questions
Can I drive with a bad ignition coil?
It is not recommended. Driving with a bad coil means your engine is misfiring, which leads to poor performance, terrible fuel economy, and a rough ride. More importantly, unburned fuel can get into the exhaust and damage your catalytic converter, leading to a much more expensive repair.
Is it hard to replace an Eagle Talon ignition coil myself?
No, this is a great job for a DIY mechanic. The coil pack is usually easy to access on top of the engine. It's held on by a few bolts and has one electrical connector. The job typically takes less than an hour with basic hand tools.
Should I replace my spark plugs and wires with the coil?
Yes, it's a good idea. The ignition coil, spark plug wires, and spark plugs all work together. If your coil has failed, there's a good chance the plugs and wires are also old and worn. Replacing them all at once ensures the entire ignition system is healthy and can prevent future problems.
What's the difference between an ignition coil and an ignitor?
The ignition coil transforms voltage. The ignitor (or power transistor) acts like a switch, telling the coil when to charge and when to release its energy to the spark plugs. On a Talon, they are two separate parts that both need to function for the ignition system to work.
Technical Specifications
OEM Part Numbers: MD158956
The 1990-1998 Eagle Talon uses a waste-spark system with a single ignition coil pack. This pack contains two separate coils that each fire two spark plugs simultaneously. The primary difference between 1G and 2G packs is the mounting bracket design. The 1990 model year has a unique power transistor and coil setup compared to 1991-1994 models.
We Have This Part in Stock
The information in this article is provided for general reference and educational purposes only. Vehicle specifications, procedures, and part compatibility can vary by production date, trim level, and region. Always consult your vehicle's factory service manual and verify part numbers before purchasing or performing repairs. Safety-critical components such as airbags, seat belts, and braking systems should be installed by a qualified professional.
