Guide to the Intake Air Temperature Sensor for 1991-1994 Chevrolet Commercial Chassis
Fix poor mileage and rough idling on your workhorse Chevy truck by understanding this critical engine sensor.
- A bad IAT sensor is a common cause of poor fuel economy and a rough idle on these trucks.
- A Check Engine Light with OBD-I Code 23 almost always points to a faulty IAT sensor or its wiring.
- Replacement is extremely easy and can be done in minutes with basic tools, as the sensor is on the air cleaner housing.
- Premium aftermarket brands like Standard Ignition offer a reliable, long-term fix.
Is Your Truck Running Wrong? It Could Be the IAT Sensor.
A failing Intake Air Temperature (IAT) sensor on your 1991-1994 Chevrolet Commercial Chassis can cause a range of frustrating engine problems. Because the sensor's reading is vital for fuel control, a bad signal can trick the computer into thinking the air is much colder than it is. This often leads to the computer adding too much fuel, a condition known as running rich. This can hurt your fuel economy and cause other performance issues.
Check Engine Light: Code 23
The most common sign of a problem is a Check Engine Light. For these OBD-I trucks, a faulty IAT sensor will typically trigger Code 23. This code means the sensor is sending a signal that indicates an extremely low temperature (like -40°F), which is usually caused by a broken internal part or a wiring issue. When this happens, the computer ignores the sensor and uses a default temperature value, leading to poor performance.
Choosing the Right Aftermarket Sensor
For a vehicle of this age, original GM parts are often discontinued and hard to find. The aftermarket offers reliable and affordable replacements. The choice between brands often comes down to a balance of quality and price.
- Premium Aftermarket (Standard Ignition): Brands like Standard Ignition (from Standard Motor Products) are well-known in the industry for producing parts that meet or exceed original equipment (OE) specifications. They are a trusted choice for technicians and owners who want a high-quality part with a strong reputation for reliability and long life.
- Budget-Friendly (True Tech): Brands like True Tech are typically positioned as a more economical option. While they meet the basic requirements to get the truck running properly, they may not have the same long-term durability or stringent quality control as more premium brands. This can be a good choice for a quick fix or if budget is the main concern.
Pro Tip: Location and Replacement
On most of these trucks with Throttle Body Injection (TBI), the IAT sensor is one of the easiest parts to replace. It is typically a small, two-wire sensor that screws directly into the base of the air cleaner housing. 🎬 Watch this video for a quick sensor replacement walkthrough. You can usually replace it in under 15 minutes with just a wrench and your hands.
Cost of a New Intake Air Temperature Sensor
The price you pay will depend on the brand you choose and where you buy it. Labor costs are very low for this repair due to how simple it is.
| Part Type | Typical Cost |
|---|---|
| New Aftermarket | $19.54 - $42.24 |
| Shop Labor | $25 - $50 |
Frequently Asked Questions (FAQ)
Where is the IAT sensor located on my 1991-1994 Commercial Chassis?
The IAT/MAT sensor is almost always located on the air cleaner assembly. Look for a small plastic sensor with a two-wire electrical connector, screwed into the metal or plastic base of the round air filter housing.
Is an IAT sensor the same as a coolant temperature sensor?
No. They are different parts that measure different things. The IAT measures air temperature, while the Engine Coolant Temperature (ECT) sensor measures coolant temperature. Both are critical, but they are not interchangeable and a failure in one will not be fixed by replacing the other.
Can I clean the IAT sensor instead of replacing it?
Sometimes, if the sensor is just dirty with oil or debris, cleaning it with a dedicated mass air flow sensor cleaner might help temporarily. However, failure is usually due to an internal electrical problem, not dirt. 🎬 See how to test your IAT sensor with a multimeter. Given the low cost of a new sensor, replacement is the most reliable repair.
Are there any recalls for the IAT sensor on these trucks?
No, there are no recalls or common Technical Service Bulletins (TSBs) from General Motors for the IAT sensor on the 1991-1994 Commercial Chassis. Failures are typically due to the age of the component.
Helpful Videos
Technical Specifications
OEM Part Numbers: 25036751 25037313
Typically a 2-terminal, screw-in sensor located on the air cleaner housing. It is a thermistor that changes resistance based on temperature.
