Ford Explorer Starter Motor Guide: 1991-1995
Don't get stranded by a bad starter; here's what you need to know for your first-generation Explorer.
- A single, loud click when turning the key is a classic sign of a bad starter on this Explorer.
- The starter is located on the lower passenger side of the engine and is a feasible DIY replacement for most home mechanics.
- Before replacing the starter, check the fender-mounted starter relay, as it can cause similar symptoms and is a cheaper fix.
- For this vehicle's age, a new aftermarket starter from a brand like MPA offers a reliable and cost-effective repair.
Is Your Explorer's Starter Failing?
A starter problem on a 1991-1995 Ford Explorer can be mistaken for a dead battery. Before you replace any parts, it's important to know the specific signs of a bad starter. The most common symptom is hearing a clicking sound when you turn the key, but the engine doesn't crank. This usually means the starter's solenoid is getting power but the motor itself isn't strong enough to turn the engine. Other signs include slow, labored engine cranking, grinding noises, or sometimes, no sound at all. Some owners have reported intermittent starting issues, where the truck starts fine one day and not the next.
Don't Confuse a Bad Starter with a Bad Battery
A weak or dead battery is the most common reason a car won't start. If your dashboard lights are dim or don't come on at all when you turn the key, your battery is the likely culprit. If the lights are bright and you hear a distinct 'click', the starter is a more probable cause. Also, check your battery cable connections to make sure they are clean and tight.
Choosing a New Aftermarket Starter
For an older vehicle like the first-generation Explorer, a new aftermarket starter is a cost-effective choice. The original starters were not designed to last forever, and a new unit can provide reliable starting for years to come. When shopping, you'll mainly see two types of brands:
- OEM-Brand (Motorcraft): Motorcraft is Ford's official parts brand. Choosing a new or remanufactured Motorcraft starter ensures you get a part designed specifically for your vehicle with original-equipment fit and performance. They are generally considered a high-quality, reliable option, though often at a higher price point.
- Aftermarket Brands (MPA, etc.): Brands like MPA (Motorcar Parts of America) specialize in producing replacement parts that meet or exceed original specifications. These are often brand-new units, not remanufactured, and can offer excellent value. For a vehicle of this age, a quality new aftermarket starter is a very practical and reliable repair.
For the 1991-1995 Explorer, both new and remanufactured starters are available. A new aftermarket part from a reputable brand like MPA avoids the risk of getting a poorly rebuilt unit and often comes with a good warranty.
Check Your Transmission Type
While many parts are interchangeable, always confirm the starter fits your specific transmission (automatic or manual). Most listings specify fitment for an automatic transmission, which was most common on the 4.0L V6. Double-checking this detail can save you the headache of a return.
Cost of Replacing Your Explorer's Starter
Here is a general breakdown of what you can expect to pay for a new starter motor for your 1991-1995 Ford Explorer. Prices can vary based on brand and where you buy.
| Part Type | Estimated Cost |
|---|---|
| New Aftermarket (MPA, etc.) | $85 - $177 |
| Remanufactured (Motorcraft) | $130 - $220 + Core Charge |
| Shop Labor | $100 - $200 |
Frequently Asked Questions
Is it the starter or the fender-mounted solenoid?
These Explorers often have a starter relay (solenoid) on the fender wall in addition to the solenoid on the starter itself. If you hear a click from the engine bay but not from the starter motor, the fender relay could be the problem. It's a much cheaper and easier part to replace, so it can be worth testing first.
How difficult is it to replace the starter myself?
For a DIY mechanic with the right tools, replacing the starter on a 1991-1995 Explorer is a manageable job. It is located on the lower passenger side of the engine and is typically held on by two bolts. You will need to safely raise and support the vehicle to gain access. The most difficult part can be reaching the top bolt.
Are there any recalls on the starter for this Explorer?
No, there have been no specific recalls issued by the NHTSA for the starter motor on the 1991-1995 Ford Explorer. There were several other recalls for this vehicle generation, but none related to the starting system.
What tools do I need to replace the starter?
You will typically need a ratchet with extensions, a 10mm socket or wrench for the electrical connections, and a 13mm socket for the mounting bolts. Always disconnect the negative battery terminal before beginning any work to prevent short circuits.
Technical Specifications
OEM Part Numbers: F07U-11000-BA F0TZ-11002-B F7PU-11000-KA F7PZ-11002-KA SA-776 SA-853
Voltage: 12V, Power: 1.4 kW, Rotation: Clockwise, Teeth: 10, Type: PMGR (Permanent Magnet Gear Reduction).
