A Guide to Spark Plug Wire Sets for the 1991-1997 Ford Escort
Fixing misfires and restoring performance in your Escort starts with the right set of spark plug wires.
- For reliable performance, choose an OEM-quality brand like Motorcraft or NGK.
- Always replace spark plug wires as a complete set, and it's best practice to replace the spark plugs at the same time.
- Replace one wire at a time to avoid mixing up the firing order, which can cause the engine to run poorly or not at all.
- Before installing new wires, inspect the spark plug wells for oil, which indicates a leaking valve cover gasket that must be fixed.
Signs of Failing Spark Plug Wires in Your Escort
When spark plug wires start to fail on this generation of Ford Escort, the symptoms are usually easy to notice. Because the wires can't deliver a consistent, strong spark, the engine's performance suffers. You'll likely experience one or more of the following issues.
- Rough Idle: The engine may shake or vibrate more than usual when you're stopped at a light. This is often one of the first signs of a weak or inconsistent spark.
- Engine Misfires: You might feel a stutter, hesitation, or jerking, especially when accelerating. A check engine light may also appear, often with codes like P0300, P0301, P0302, P0303, or P0304, indicating a misfire on one or more cylinders.
- Reduced Power and Fuel Economy: Your Escort may feel sluggish and you'll likely notice you're filling up the gas tank more often. When the air-fuel mixture isn't burned completely due to a weak spark, it wastes fuel and reduces engine output.
- Difficulty Starting: A weak spark can make it harder for the engine to fire up, especially in cold or damp weather.
Choosing the Right Aftermarket Wire Set
For a vehicle like the 1991-1997 Escort, you don't need to insist on a dealership part. Many aftermarket brands offer excellent quality that meets or exceeds the original specifications, often at a better price. The key is to choose a reputable brand to avoid fitment problems and premature failure.
Pro Tip: Replace Wires and Plugs Together
It is highly recommended to replace your spark plugs at the same time you replace the wires. Old plugs can be hard on new wires, and installing both at once ensures your entire ignition system is refreshed for maximum performance and longevity. It's a simple, inexpensive way to do the job right.
Brand Quality Tiers
When shopping for a new wire set, consider these brand tiers:
- OEM & Premium Aftermarket: Brands like Motorcraft (the original Ford part), NGK, and Denso are top-tier choices. NGK, in particular, is a well-regarded OEM supplier known for high-quality materials and perfect fitment. These brands use high-temperature silicone jackets and robust terminals for long life and excellent performance.
- Quality Standard Aftermarket: Brands such as Standard Motor Products (SMP), Walker Products, and Karlyn STI offer a great balance of quality and value. They are reliable replacements that will restore original performance for daily driving.
- Performance Brands: While brands like MSD and Granatelli are known for high-performance applications, they are generally overkill for a stock Ford Escort. They often feature thicker 8mm or 8.5mm wires for better radio frequency interference (RFI) suppression and are built for high-output engines.
- Budget-Friendly Options: While the lowest price can be tempting, be cautious with lesser-known or private-label brands. They may not have the same quality boots, terminals, or wire length accuracy, which can lead to installation headaches and a shorter service life.
A Note on Valve Cover Gasket Leaks
A common issue on older engines is a leaking valve cover gasket. This allows oil to seep into the spark plug wells, which will quickly destroy a new set of spark plug wires and boots. When you replace your wires, inspect the spark plug tubes for any signs of oil. If you see oil, you must replace the valve cover gasket to protect your new parts.
Typical Replacement Costs
The cost to replace the spark plug wire set on a 1991-1997 Ford Escort is very reasonable. The parts are affordable and the labor is straightforward.
| Item | Estimated Cost |
|---|---|
| New Aftermarket Wire Set | $31 - $78 |
| New OEM (Motorcraft) Wire Set | $55 - $90 |
| Shop Labor | $50 - $100 |
Frequently Asked Questions (FAQ)
Do I need special tools to replace the spark plug wires?
No special tools are required. A pair of pliers can help to gently grip and twist the old boots off the spark plugs if they are stuck. Applying a small amount of dielectric grease inside the new boots will make installation easier and prevent them from sticking in the future.
Can I replace just one bad wire?
While you can, it's not recommended. Spark plug wires are sold in sets and should be replaced as a set. They all have the same amount of wear, so if one has failed, the others are likely not far behind. Replacing them all at once ensures a balanced and reliable ignition system.
How do I make sure I don't mix up the wires?
The best method is to replace one wire at a time. Remove the old wire for cylinder 1, then match its length to a new wire from the set and install it. Repeat the process for cylinders 2, 3, and 4. This prevents crossing wires, which would cause the engine to run very poorly or not at all. The coil pack on the Escort is typically numbered to help with identification.
Were there any recalls for Escort spark plug wires?
No. Searches of the National Highway Traffic Safety Administration (NHTSA) database show no recalls or technical service bulletins (TSBs) specifically related to the spark plug wires for the 1991-1997 Ford Escort.
Technical Specifications
OEM Part Numbers: WR-6059 F7PZ12259AA
Varies by engine (1.8L DOHC, 1.9L SOHC, 2.0L SOHC). Wires are vehicle-specific and pre-cut to length. Core material is typically a carbon or magnetic suppression core with a 7mm or 8mm silicone jacket.
