A Guide to Ignition Coils for the 1994-1997 BMW 840Ci (E31)
Solving misfires and restoring smooth V8 power to your classic 8-Series.
- Check for oil leaks from the valve cover gaskets before replacing coils; this is a common root cause of failure on the 840Ci.
- Replace all eight spark plugs when you replace the ignition coils to ensure longevity and performance.
- For best results, replace all eight coils at once using a high-quality OEM brand like Bosch or a premium aftermarket brand like Delphi or NGK.
- A flashing Check Engine Light indicates a misfire; avoid driving the vehicle to prevent damage to your catalytic converters.
Is Your 840Ci Ignition Coil Failing?
On the M60 and M62 V8 engines found in the 1994-1997 BMW 840Ci, ignition coil failure is common over time. However, the coils themselves are often not the root cause. A very frequent issue on these engines is a leaking valve cover gasket. This allows engine oil to seep into the spark plug wells, soaking the bottom of the ignition coil boot. Over time, the oil degrades the boot, causing a poor connection to the spark plug and leading to misfires. Eventually, this stress can cause the coil itself to fail entirely. Decades of engine heat and vibration also contribute to the breakdown of these electronic components.
Symptoms of a Bad Ignition Coil
- Rough Idle: The car may shake or vibrate noticeably when stopped.
- Engine Misfires: You may feel a stuttering or hesitation during acceleration. This is often accompanied by a flashing Check Engine Light.
- Loss of Power: With one cylinder not firing correctly, the V8 will feel sluggish and weak.
- Reduced Fuel Economy: The engine's computer tries to compensate for the misfire, often by using more fuel.
- Difficulty Starting: In cases where multiple coils have failed, the engine may struggle to start or not start at all.
Check for Oil Leaks First
Before replacing your coils, inspect the spark plug wells for any signs of oil. If oil is present, you must replace the valve cover gaskets. 🎬 See how to replace leaking valve cover gaskets on your M60/M62. Installing new coils without fixing the oil leak will only lead to the new parts failing prematurely.
Choosing the Right Aftermarket Coil for Your 840Ci
Not all aftermarket coils are created equal. For a premium vehicle like the E31 840Ci, choosing a quality part is crucial for performance and reliability. The brands available can be grouped into tiers.
Tier 1: OEM & OES Brands
These are the manufacturers who likely made the original parts for BMW. They offer the best fit, performance, and longevity, making them the safest choice.
- Bosch: As a primary original equipment manufacturer for BMW, Bosch coils are the benchmark for quality and reliability. Choosing Bosch is the closest you can get to the original part your car was built with.
- Bremi: A German brand often cited by BMW enthusiasts as a high-quality OEM-level alternative.
Tier 2: Premium Aftermarket Brands
These are well-respected companies known for producing high-quality components that meet or exceed OEM standards. They are excellent alternatives to the dealer part.
- Delphi: A major OEM supplier for many car brands, Delphi is known for its engineering and quality. For some newer BMWs, Delphi coils were even used as a factory update over Bosch.
- NGK: Famous for their spark plugs, NGK also manufactures excellent ignition coils that are highly regarded for their reliability.
- Hitachi: A major Japanese manufacturer known for high-quality electronics.
Tier 3: Standard & Economy Brands
These brands focus on providing a cost-effective solution. While they can get your car running, their lifespan and performance may not match the higher-tier options. They can be a viable choice for a budget-conscious repair, but the trade-off in durability should be considered.
- URO Parts: Known for providing a wide range of affordable parts for European cars. Quality can sometimes be inconsistent compared to premium brands.
- Standard Ignition (SMP), Walker Products, Motorad, DriveWire, Global Parts, Skyward, Vemo: These brands offer a functional replacement at a lower price point.
Pro Tip: Replace in Sets
If one coil has failed due to age, the others are likely not far behind. It is highly recommended to replace all eight coils at the same time. 🎬 Watch this step-by-step guide on replacing BMW V8 ignition coils. This restores balanced engine performance and prevents you from having to repeat the repair when the next coil fails. At the very least, replace the failing coil and its corresponding spark plug.
Frequently Asked Questions (FAQ)
Should I replace all 8 ignition coils at once?
Yes, it is highly recommended. All the coils on your engine have been exposed to the same amount of heat and vibration for the same amount of time. If one has failed, the others are likely nearing the end of their service life. Replacing them all at once ensures reliability and smooth, balanced engine power.
What else should I replace with my ignition coils?
Always replace your spark plugs. Worn spark plugs have a larger gap, which requires the coil to work harder to create a spark, leading to premature coil failure. Also, inspect your valve cover gaskets for leaks, as this is a primary cause of coil failure on the 840Ci's V8 engines.
Is there a difference between coils for the M60 (94-95) and M62 (96-97) engines?
The 1994-1995 840Ci uses the M60 V8, while the 1996-1997 models use the M62 V8. While they are very similar, some parts can differ. Always verify the exact part number for your specific year and engine. Many aftermarket coils are designed to fit both the M60 and M62 engines, but it is crucial to confirm fitment before purchasing.
How do I know if the coil is bad, or if it's the spark plug?
A scan tool can read fault codes (like P0301 for a cylinder 1 misfire) which points to the problem cylinder. To isolate the issue, you can swap the ignition coil from the misfiring cylinder with a coil from a known good cylinder. Clear the codes and run the engine. If the misfire code moves to the new cylinder, the ignition coil is bad. If the misfire stays on the original cylinder, the problem is likely the spark plug, 🎬 Check out this quick tip for diagnosing engine misfires. fuel injector, or another issue.
Helpful Videos
Technical Specifications
OEM Part Numbers: 12131712219 12137594937 12131748018 0221504470
This vehicle uses eight individual, coil-on-plug style ignition coils. The 1994-1995 840Ci has the M60 V8 engine, and the 1996-1997 model has the M62 V8 engine. While many coils fit both, always verify the part number for your specific vehicle.
