Lexus ES300 Engine Camshaft Position Sensor Guide (1994-2003)
Solve stalling, no-start, and poor performance issues in your ES300 by choosing the right sensor.
- Your ES300 has two camshaft sensors; identify the correct failed sensor (Bank 1 or Bank 2) using the OBD-II code before buying.
- Denso is the original equipment manufacturer and the most recommended brand for reliability.
- Symptoms often include a Check Engine Light (P0340, P0345), stalling, no-start conditions, and poor engine performance.
- Replacing the front sensor (Bank 2) is a simple DIY job, but cheaper aftermarket parts are known to fail prematurely.
Is a Failing Camshaft Position Sensor Causing Your ES300 Problems?
If your reliable Lexus ES300 suddenly starts acting up, a bad camshaft position sensor could be the culprit. This small electronic part plays a huge role in how your engine runs. When it fails, it can't tell the engine's computer where the camshaft is, leading to a variety of noticeable problems. 🎬 Watch: Common symptoms of a failing camshaft position sensor The computer may then trigger a Check Engine Light and store a diagnostic trouble code. Common codes for this issue include P0340, P0345, and P1350.
🎬 See how to fix a P1350 code on your 1MZ-FEChoosing the Right Aftermarket Sensor for Your Lexus
When replacing this sensor, you have a choice between dealership OEM parts and a wide range of aftermarket brands. For a Lexus, the quality of this sensor matters.
OEM vs. Aftermarket Quality
The original sensor on your ES300 was made by Denso. For the best reliability and performance, choosing a Denso aftermarket sensor is the safest bet, as it's the same technology as the original part. Brands like NGK (NTK), Delphi, and Standard Ignition are also considered high-quality aftermarket choices that perform well in these engines. Cheaper, lesser-known brands or unbranded parts are often a gamble; forum members frequently report that these budget sensors can fail quickly, sometimes within months, forcing you to do the job all over again. While the initial cost is lower, a poor-quality sensor can lead to repeated repairs and frustration.
Brand Quality Tiers
- Top Tier (OEM Equivalent): Denso. These are identical to the part your Lexus came with from the factory.
- High Quality Aftermarket: NGK (NTK), Delphi, Beck Arnley, Standard Ignition. These brands have a strong reputation for reliability and are a good alternative to OEM.
- Standard/Economy Tier: Dorman, Walker, Holstein, URO Parts, and others. These are more budget-friendly, but quality and longevity can be inconsistent. They may be a choice for a quick fix, but be aware that they might not last as long as higher-tier options.
How Much Does a Camshaft Position Sensor Replacement Cost?
The cost depends on whether you do it yourself or take it to a shop. The part itself is not very expensive, but labor can add to the total.
| Part/Service | Estimated Cost |
|---|---|
| New Aftermarket Sensor | $22 - $134 |
| New OEM (Dealer) Sensor | $150 - $225 |
| Shop Labor | $80 - $150 |
| Total Professional Replacement | $230 - $375+ |
Common Ordering Mistake: Bank 1 vs. Bank 2
Your ES300's V6 engine has two camshaft position sensors: one for Bank 1 and one for Bank 2. Bank 1 is the cylinder bank closer to the firewall (rear), while Bank 2 is closer to the radiator (front). The diagnostic code (e.g., P0340 for Bank 1, P0345 for Bank 2) will tell you which one has failed. Make sure you order the correct sensor for the specific bank that needs replacement, as they are not always interchangeable.
Frequently Asked Questions
Where are the camshaft position sensors located on my 1994-2003 ES300?
Your ES300 has two sensors. The Bank 2 sensor is located on the front of the engine, near the radiator hose and oil dipstick. The Bank 1 sensor is on the rear cylinder head, closer to the firewall. The front sensor is much easier to access than the rear one.
Can I replace the camshaft position sensor myself?
Yes, this is a DIY-friendly job for many owners. The front sensor (Bank 2) is especially easy, requiring only basic tools like a 10mm socket. 🎬 Watch this step-by-step walkthrough for replacing the sensor You'll need to remove the electrical connector, undo one bolt, and swap the sensor. The rear sensor (Bank 1) is more difficult to reach. Always disconnect the negative battery terminal before starting.
How many camshaft position sensors does my ES300 have?
The 1994-2003 Lexus ES300 with the 1MZ-FE V6 engine has two camshaft position sensors. One sensor monitors the camshaft for the front bank of cylinders (Bank 2), and the other monitors the rear bank (Bank 1).
What's the difference between a camshaft and crankshaft sensor?
They work together. The camshaft sensor tracks the position of the camshafts, which control the valves. The crankshaft sensor tracks the position of the crankshaft, which is connected to the pistons. The ECM compares signals from both sensors to ensure the engine's timing is perfect. A failure in either sensor can cause similar symptoms.
Helpful Videos
Technical Specifications
OEM Part Numbers: 90919-05013 90080-19006 90919-05024 90919-05012
Your 1994-2003 ES300 uses a 1MZ-FE V6 engine with two camshaft position sensors, one for each cylinder bank. These are typically magnetic resistance element (MRE) type sensors held in place by a single 10mm bolt.
