Subaru Legacy Windshield Washer Pump Guide (1995-2000)
Everything you need to know about replacing the windshield washer pump on your second-generation Subaru Legacy.
- A failed washer pump is common; symptoms include no spray or weak spray.
- Before replacing, check the fuse, fluid level, and for clogged nozzles.
- Replacement is an easy DIY job, taking less than an hour with basic tools.
- Aftermarket brands like Trico offer reliable, direct-fit replacements for this vehicle.
Is Your Windshield Washer Pump Failing?
A failing washer pump is a common issue on older vehicles like the 1995-2000 Subaru Legacy. The symptoms are usually straightforward. Understanding them can help you decide if a replacement is necessary.
Diagnosing the Problem
🎬 Watch: A professional guide to diagnosing washer system issues.Before buying a new part, check these simple things first:
- Check Fluid Level: It sounds obvious, but make sure the washer fluid reservoir is not empty.
- Listen for the Pump: When you activate the washer, you should hear a distinct humming sound from the pump motor. If you hear the hum but no fluid comes out, the pump may be worn out, or you could have clogged nozzles or a leak. If you hear nothing at all, it's likely the pump has failed or there's an electrical issue like a blown fuse.
- Check for Clogs and Leaks: Use a small pin to gently clear any debris from the washer nozzles on the hood. Also, check the rubber hoses for visible cracks or leaks.
Common Failure Symptoms
| Symptom | Possible Cause |
|---|---|
| No fluid sprays, but pump motor is humming | Worn out pump impeller, clogged lines, or low fluid level |
| No fluid sprays and no sound from pump | Failed pump motor, blown fuse, or bad electrical connection |
| Weak or uneven spray | Failing pump, partially clogged nozzles, or a leak in the hose |
Choosing the Right Aftermarket Pump
For a 1995-2000 Subaru Legacy, the original OEM washer pump has likely been discontinued or is hard to find. Fortunately, aftermarket parts provide a reliable and affordable solution. Brands like Trico offer direct-fit replacement pumps designed to meet or exceed original equipment performance. These pumps are engineered for easy installation without needing special modifications.
Pro Tip: When replacing the pump, it's a good idea to also replace the small rubber grommet that seals the pump to the reservoir. This prevents leaks and ensures a snug fit. Many aftermarket kits include a new grommet.
Known Issues & Recalls
Searches for official recalls and Technical Service Bulletins (TSBs) did not show any specific issues for the windshield washer pump on the 1995-2000 Subaru Legacy. While later model year Legacys had recalls related to the windshield wiper motor overheating, this issue does not apply to the washer pump on these vehicles.
Frequently Asked Questions (FAQ)
Can I drive my Legacy with a broken washer pump?
Yes, you can still drive the vehicle. However, a non-functioning washer system can be a safety hazard in conditions where your windshield gets dirty, such as rain, snow, or dusty roads, as it reduces visibility.
Is this a difficult part to replace myself?
No, this is considered an easy DIY repair for most people. It typically requires basic hand tools and can be completed in under an hour. The pump is usually accessible by moving the battery or removing the front part of the passenger-side wheel well liner. The pump itself simply pulls out from the reservoir.
🎬 See this walkthrough on how to replace the pump.Do I need a separate pump for the front and rear wipers?
Yes. If your Legacy is a wagon with a rear wiper, it uses two separate pumps. They are often mounted on the same fluid reservoir. 🎬 Watch: How to swap pumps on a Subaru wagon. Make sure you are ordering the correct pump (front or rear) for the one that has failed.
Why is my new aftermarket pump not working?
First, double-check the electrical connection to ensure it is secure. Second, confirm the fuse is not blown. If those are fine, the issue may be upstream in the electrical system, such as the switch itself, though this is rare. Also, ensure you have filled the reservoir with fluid, as the pump may not prime if run dry.
Helpful Videos
Technical Specifications
OEM Part Numbers: 86610FC000 86611AC010
The pump is a small, 12V electric motor that press-fits into a rubber grommet on the windshield washer fluid reservoir. For the 1995-2000 Legacy, the front pump is located low on the reservoir, accessible from the engine bay. Aftermarket replacements from brands like Trico are designed to match the specific fit and electrical connection of the original part.
