GMC Safari Windshield Washer Pump Guide (1995-2005)
Everything you need to know about replacing the windshield washer pump on your 1995-2005 GMC Safari.
- The 1995-2005 GMC Safari uses two washer pumps if equipped with a rear wiper, both located on the washer fluid reservoir.
- Replacing the pump is a simple DIY task that usually takes less than an hour and requires no special tools.
- Aftermarket brands like Trico offer quality replacement pumps, while brands like Dorman offer complete reservoir assemblies that are a smart upgrade for aging vehicles.
- If the pump is silent when activated, it has likely failed, but you should always check the fuse first.
Is Your Windshield Washer Pump Failing?
A bad windshield washer pump can be a nuisance and a safety hazard. If you're pressing the button and nothing's happening, it's time to diagnose the problem. The most common signs of a failing pump are straightforward.
Common Symptoms of a Bad Washer Pump:
- No Fluid Spraying: The most obvious symptom. If the reservoir is full but the nozzles are dry, the pump is a likely culprit.
- No Sound: You should hear a distinct buzzing sound from the pump when you try to use the washers. If it's silent, the pump motor may have failed or isn't receiving power.
- Weak Spray: If the fluid barely reaches the windshield, the pump motor could be getting weak and failing to generate enough pressure.
- Leaking Fluid: Puddles of blue or green fluid under the front of your van can indicate a cracked pump housing or a bad seal where the pump enters the reservoir.
Check the Simple Things First
Before you replace the pump, make sure your washer fluid reservoir is full. Also, check the fuse for the washer circuit. Sometimes, the spray nozzles themselves can get clogged with wax or debris. You can try cleaning them with a small pin or needle to see if that restores flow.
🎬 Watch: How to diagnose weak spray and clogged nozzles.Choosing a New Aftermarket Pump
For the 1995-2005 GMC Safari, you have a few good options when it comes to new aftermarket parts. The original OEM pumps can be hard to find and expensive. Aftermarket brands offer a cost-effective and reliable alternative.
Trico: Trico is a well-known brand in wiper and washer components. Their pumps are often described as easy to install, sometimes fitting directly in place of the original without modification. They are designed to provide performance similar to the original equipment and are a popular choice for DIY repairs.
Dorman: Dorman offers complete reservoir assemblies for the Safari, which include a new tank, cap, and both washer pumps. This is an excellent option if your reservoir tank is old, brittle, or leaking, as it solves multiple potential problems at once 🎬 See this walkthrough for replacing the entire reservoir assembly. for a reasonable price.
When shopping, you'll notice that many aftermarket pumps for this van are sold as part of a complete reservoir kit. Given the age of these vehicles, replacing the entire assembly is often the smartest repair, preventing future leaks from the plastic tank itself.
Front vs. Rear Pump
Your Safari has two pumps if it has a rear wiper. The bottom pump on the reservoir typically feeds the front windshield, while the upper one feeds the rear. They are often identical parts, but it's crucial to connect the correct hoses and electrical connectors during installation.
Cost of a New Windshield Washer Pump (1995-2005 GMC Safari)
| Part Type | Estimated Cost |
|---|---|
| New Aftermarket Pump Only | $20 - $30 |
| New Aftermarket Reservoir with Pump(s) | $35 - $70 |
| Shop Labor for Replacement | $61 - $90 |
Frequently Asked Questions
Is replacing the washer pump a DIY job?
Yes, for most people this is a very feasible DIY repair. The washer reservoir and pumps are located in the engine bay and are relatively easy to access. The replacement typically requires no special tools, as the pump is press-fit into the reservoir and the hoses and electrical connector are simple to detach and reattach. The entire job can usually be done in under an hour.
🎬 Watch: Step-by-step guide to replacing a GM washer pump.Are there any recalls on the GMC Safari washer pump?
Our search of the National Highway Traffic Safety Administration (NHTSA) database did not find any specific recalls for the windshield washer pump on the 1995-2005 GMC Safari.
Do I need to replace the whole reservoir or just the pump?
If only the pump has failed and your reservoir tank is in good condition, you can replace just the pump. However, the plastic on these reservoirs can become brittle with age. Many aftermarket suppliers sell the reservoir complete with new pumps for a very reasonable price, which can be a more durable long-term repair.
What if I replace the pump and it still doesn't work?
If a new pump doesn't solve the problem, the issue is likely electrical. First, check the fuse. If the fuse is good, you'll need to use a multimeter to check for 12-volt power at the pump's electrical connector when the washer switch is activated. A lack of power could indicate a bad switch, a broken wire, or a problem with the control module.
Helpful Videos
![[TUT] 1998 Chevy Astro Van Coolant / Washer Reservoir Replacement](https://img.youtube.com/vi/u_0N-2q-c4Y/mqdefault.jpg)
Technical Specifications
OEM Part Numbers: 22127573 89025063 22109926 22111443 12363310
The washer system on the 1995-2005 GMC Safari utilizes one or two small electric pumps that press-fit into a combination coolant overflow and washer fluid reservoir. Models with a rear wiper use two pumps. The pumps are typically 12-volt and connect via a simple two-pin electrical connector.
