Toyota Avalon Windshield Washer Pump Replacement Guide (1995-2013)
Everything you need to know before replacing the windshield washer pump on your 1995-2013 Toyota Avalon.
- Always check the washer system fuse before deciding to replace the pump.
- Replacement is a simple DIY job that requires accessing the pump behind the passenger-side wheel well liner.
- Quality aftermarket brands like ACDelco and Trico offer reliable performance at a much lower cost than OEM parts.
- Ensure the new rubber grommet is installed correctly to prevent leaks after the repair.
Is Your Avalon's Windshield Washer Pump Failing?
A non-working windshield washer system is often caused by a failed washer pump. This is a common wear-and-tear item. Before you assume the pump is bad, always check the fuse first. The fuse location can be found in your owner's manual. If the fuse is good, the symptoms below usually point to a bad pump.
Symptoms of a Bad Washer Pump
- No Sound, No Spray: You pull the lever and the wipers move, but you hear no humming sound from the front of the car and no fluid comes out. This usually means the pump motor has failed or is not getting power. 🎬 Watch a DIY fix for a pump with no sound or spray.
- Pump Hums, But No Spray: You can hear the pump motor running, but little or no fluid sprays onto the windshield. This can mean the pump is weak, or there are clogs in the lines or nozzles.
- Leaking Fluid: You notice a puddle of blue, green, or orange washer fluid under the front passenger side of your car. The pump's housing can crack with age, causing the reservoir to leak.
Known Issues for 2013 Toyota Avalon
There was a recall for some 2013 Toyota Avalon models concerning the windshield wiper system. However, this recall was for the windshield wiper switch assembly, not the washer pump itself. A faulty switch could prevent the wipers and pump from activating. If you have a 2013 model, it is worth checking if your vehicle was part of this recall.
Choosing a New Aftermarket Washer Pump
For a vehicle like the 1995-2013 Avalon, a new aftermarket washer pump offers the best balance of cost and reliability. The original equipment (OEM) pump from Toyota is expensive, and there is little benefit for this simple part.
- OEM Quality vs. Aftermarket: A genuine Toyota pump can cost over $75. A quality aftermarket pump provides the same performance for a fraction of the price. Brands like ACDelco and Trico are dependable choices.
- ACDelco: While known as an original equipment supplier for GM vehicles, ACDelco also makes reliable parts for many other brands. They are a trusted name and a solid choice for your Avalon.
- Trico: Famous for wiper blades, Trico also produces a line of washer pumps designed for easy, direct-fit installation. They are a popular and affordable option that meets OEM specifications.
Pro Tip: The new pump should come with a new rubber grommet. This small seal is critical for preventing leaks where the pump pushes into the reservoir. Always use the new grommet provided with your new pump.
Windshield Washer Pump Replacement Cost
The cost to replace the washer pump on a 1995-2013 Avalon is very reasonable, especially if you do it yourself. The part itself is inexpensive, and labor is minimal.
| Part/Service | Estimated Cost |
|---|---|
| New OEM Pump | $60 - $146 |
| New Aftermarket Pump | $27 - $49 |
| Shop Labor | $67 - $98 |
| Total Shop Replacement | $94 - $147 (Aftermarket) |
Can I Replace the Pump Myself?
Yes, this is a great DIY job for beginners. The pump is located on the washer reservoir, which is behind the front passenger-side wheel well liner. The basic steps involve:
- Turning the front wheels to the right for clearance.
- Removing a few clips and screws holding the plastic wheel well liner.
- Peeling the liner back to access the pump.
- Placing a bucket underneath to catch leftover fluid.
- Disconnecting the single electrical plug and the washer fluid hose.
- Pulling the old pump straight out of the reservoir.
- Installing the new grommet and pushing the new pump in.
- Reconnecting the hose and electrical plug, then refilling and testing for leaks. 🎬 Watch this step-by-step walkthrough for a 2002 Avalon pump replacement.
Frequently Asked Questions (FAQ)
Do I need any special tools to replace the washer pump?
No special tools are required. You will need basic hand tools like a screwdriver or a small socket set to remove the fasteners for the wheel well liner.
My Avalon has one washer pump. Is it for the front only?
The Toyota Avalon is a sedan and typically only has a single washer pump for the front windshield. It is not designed for a rear washer system.
The new pump is installed, but the connector won't click on. What should I do?
This can sometimes happen with aftermarket parts. Compare the locking tab on the new pump to the old one. If it's slightly different, you may need to carefully file it down slightly for the connector to securely click into place. Applying a small amount of silicone grease to the connector's rubber seal can also help it slide on easier.
Should I clean the reservoir tank while I'm replacing the pump?
It's a good idea. Once the old pump is removed and the tank is empty, you can flush it out with a garden hose to remove any slime or debris 🎬 See how to remove and clean the entire washer fluid tank. that may have built up over the years. This helps prevent clogs in your new pump and nozzles.
Helpful Videos
Technical Specifications
OEM Part Numbers: 85330-06030 85330-06031 85330-60190 85330-06070
12V electric pump, single outlet, press-fit installation into washer reservoir.
We Have This Part in Stock
The information in this article is provided for general reference and educational purposes only. Vehicle specifications, procedures, and part compatibility can vary by production date, trim level, and region. Always consult your vehicle's factory service manual and verify part numbers before purchasing or performing repairs. Safety-critical components such as airbags, seat belts, and braking systems should be installed by a qualified professional.
