Nissan Maxima Front Alignment Caster and Camber Kit (1995-2014)
If your Maxima is pulling to one side or wearing out tires, you may need more alignment adjustment than the factory parts offer.
- The 1995-2014 Maxima lacks factory adjustment for front camber/caster, making an aftermarket kit necessary to correct alignment issues.
- Symptoms include uneven tire wear, the car pulling to one side, and a crooked steering wheel.
- The kit itself is inexpensive, but professional installation and a mandatory four-wheel alignment will make up most of the total cost.
- Choose a quality aftermarket part like Mevotech's 'Supreme' line, as it is a critical suspension component.
Is Your Maxima Fighting You on the Road?
If you've noticed your 1995-2014 Nissan Maxima is wearing down the inside or outside edge of its front tires, it's a classic sign of a camber alignment problem. You might also feel the car pulling to the left or right, or the steering wheel might be crooked even when you're driving straight. This happens because, 🎬 Watch: Common signs your car is due for an alignment from the factory, your Maxima's front suspension doesn't have a way to adjust two key alignment angles: caster and camber. Over time, as suspension parts wear or if the car's height is changed, these angles can fall out of spec, and a standard alignment can't fix it.
Why a Standard Alignment Isn't Enough
An alignment shop can only adjust what the car's hardware allows. For many Maxima models in this year range, that's only the front 'toe' setting. If your camber or caster is off, the technician will tell you they can't correct it without installing an aftermarket kit. This is a common issue, not a sign of a bad mechanic.
Choosing the Right Aftermarket Kit
Since Nissan doesn't offer an adjustable part, you must turn to the aftermarket. The most common solution is a cam bolt kit. These kits are inexpensive and effective, providing the necessary adjustment range (typically around +/- 1.75 degrees) 🎬 See how to properly install these adjustable cam bolts to solve alignment problems.
Mevotech Alignment Kits:
Mevotech is a common brand for these kits. They offer different quality levels, and it's important to know which you're getting.
- Mevotech Supreme: This is their standard, daily-driver grade part. Owners have used these parts on Maximas and found them to be a perfectly serviceable solution for correcting alignment issues. They are a good balance of cost and quality for a typical street-driven car.
- Mevotech (Budget Line): The lower-cost Mevotech parts are considered budget-tier. Like many value-oriented suspension parts, their lifespan can be a gamble. For a part that is critical for your alignment, sticking with the 'Supreme' line is a safer bet.
Pro Tip: It's All in the Alignment
The quality of the alignment job is just as important as the part itself. Installing the kit adds the *ability* to make adjustments, but a skilled technician with a modern alignment rack is needed to dial it in correctly. After installing the kit, a full four-wheel alignment is mandatory.
Cost to Install an Alignment Kit on a Nissan Maxima
| Item | Estimated Cost |
|---|---|
| New Aftermarket Alignment Kit (e.g., Mevotech) | $22 - $25 |
| Shop Labor to Install Kit | $75 - $150 |
| Four-Wheel Alignment | $80 - $170 |
| Total Estimated Cost | $177 - $345 |
Note: Labor costs can vary significantly by location and shop. The kit installation is often charged as 0.5-1.0 hour of labor on top of the alignment fee.
Frequently Asked Questions
Will this kit fix my car's pulling or drifting?
If the pulling is caused by incorrect camber or caster, then yes, this kit provides the adjustment needed to fix it. Nissan even has a Technical Service Bulletin (TSB #NTB08-097L) for diagnosing vehicle pull, which highlights how important correct alignment angles are. However, pulling can also be caused by tire issues or other worn suspension parts, so a full inspection is key.
Can I install this kit myself?
Yes, a DIYer can typically install the cam bolts. It involves removing the two bolts holding the steering knuckle to the bottom of the strut and replacing them with the new cam bolts. However, you CANNOT complete the job yourself. The car will need an immediate professional alignment to set the angles correctly, so you will need to drive it directly to a shop.
🎬 Watch this before you start your camber bolt installationIs there an OEM or Nissan version of this kit?
No, Nissan does not make an alignment adjustment kit for these models. The original factory bolts are non-adjustable. Aftermarket kits from brands like Mevotech, Moog, or Eibach are the only way to add camber and caster adjustment.
Are there any recalls for this problem?
There are no recalls specifically for a lack of camber adjustment. There was a recall on some older models for a front suspension link pin that could break and affect steering, but it's a separate issue. The need for this kit is due to the original design, not a defect.
Helpful Videos
Technical Specifications
Adjustment Range: Camber/Caster ±1.75 Degrees. Bolt Diameter: 14mm.
