A Practical Guide to the 1996-2007 Dodge Caravan Wiper Motor
Everything a Caravan owner needs to know when their windshield wipers fail.
- Common failure symptoms include slow operation, incorrect parking, and only working on high speed.
- Check for a recalled motor on 2005-2006 models, as a known defect can cause sudden failure.
- If wipers won't turn off, try swapping the wiper relay in the fuse box before replacing the entire motor.
- A wiper arm puller tool is highly recommended for DIY replacement to avoid damaging parts.
Is Your Caravan's Wiper Motor Failing?
If you're having trouble with your wipers, the motor is a likely suspect. These motors work hard and eventually wear out. Common signs of failure are specific and easy to spot once you know what to look for.
Symptoms of a Bad Wiper Motor
- Slow or Jerky Wipers: The wipers move much slower than they used to, even on the fastest setting.
- Only One Speed Works: Often, only the high-speed setting will work, which points to a problem with the motor's internal controls.
- Wipers Won't Park Correctly: When you turn them off, the wipers stop in the middle of the windshield instead of returning to their resting position at the bottom. This is a classic sign of a bad park switch inside the motor.
- No Movement at All: You turn the switch and nothing happens. You might hear a faint humming or clicking sound from the base of the windshield, which means the motor is getting power but can't move.
- Wipers Won't Turn Off: This can be caused by a failed relay in the fuse box or a bad park switch in the motor that constantly tells the system it isn't parked.
Recall Notice for 2005-2006 Models
A safety recall (NHTSA ID: 06V067000) was issued for 2005-2006 Dodge Caravan and Grand Caravan models. The wiper motor shaft could break without warning, causing the wipers to stop working completely. The recall also included some 2001-2006 vans that had a specific service replacement motor installed. You can check with a dealership or on the NHTSA website to see if your vehicle was part of this recall.
Choosing the Right Aftermarket Wiper Motor
When replacing the wiper motor on your Caravan, you don't need to buy an expensive part from the dealer. Aftermarket parts are a cost-effective solution. They are designed to fit and function like the original. Here’s a look at the brands you'll likely find.
- Good Tier: WAI Global
WAI is a large manufacturer of automotive electrical parts. Their new wiper motors are generally considered a reliable, quality option designed to meet original equipment (OE) specifications. They are a solid choice for a balance of price and performance. - Economy Tier: Cardone
Cardone is a huge name in the aftermarket, offering both new and remanufactured parts. While their new parts are a decent budget option, quality on their remanufactured units can sometimes be inconsistent. If choosing Cardone, a new part is often the more reliable bet. - Budget Tier: Replacement
This is often a generic or store brand. These are the most affordable new parts available. They will get your wipers working again, but may not offer the same durability or precise finish as more established brands.
How Much Does a New Wiper Motor Cost?
The total cost depends on whether you do the job yourself or have a shop do it. The part itself is affordable, but labor can add a significant amount to the final bill.
| Part/Service | Estimated Cost |
|---|---|
| New Aftermarket Wiper Motor | $70 - $147 |
| Shop Labor | $160 - $235 |
| Total Professional Installation | $230 - $382 |
Frequently Asked Questions
Is it hard to replace the wiper motor myself?
It's a moderately difficult job that a DIYer with some experience can handle. 🎬 Watch this step-by-step guide to removing the cowling and motor. It takes about 1.5 to 2 hours. You'll need to remove the wiper arms, the plastic cowl panel at the base of the windshield, and then the entire wiper linkage assembly to access the motor. A special wiper arm puller tool is highly recommended, as the arms can be seized onto their posts.
My wipers won't turn off. Is it the motor? 🎬 See this quick fix if your wipers won't turn off.
It could be, but you should check the simple things first. A common cause for this on the Caravan is a stuck wiper relay in the under-hood fuse box (also called the IPM). 🎬 Watch how to locate and test your wiper fuses and relays. Try swapping the wiper relay with an identical one (like the horn relay) to see if the problem stops. If it does, you just need a new relay. If not, the problem is likely the park switch inside the wiper motor.
Do I need to buy the linkage assembly too?
Not usually. In most cases, only the motor fails. You can unbolt the old motor from your existing linkage and bolt the new one on. However, inspect the plastic bushings on your linkage arms. If they are worn or broken, it's a good time to replace the entire assembly.
How do I make sure the wipers park in the right spot after replacement?
Before you bolt the wiper arms back on, connect the new motor electrically and turn the wipers on for one cycle, then turn them off. This allows the motor to move to its natural 'park' position. Then, you can install the wiper arms in their correct resting position at the bottom of the windshield.
Helpful Videos
Technical Specifications
OEM Part Numbers: 05114534AA
The wiper motor for the 1996-2007 Dodge Caravan is typically sold as a motor-only unit that bolts to the existing wiper linkage. It uses a multi-pin electrical connector. The assembly is located in the wiper tray, underneath the plastic cowl at the base of the windshield.
