Ford Taurus Multi-Purpose Relay Guide: 1996-2008
Understand the common multi-purpose relay in your Taurus and how to fix issues like a no-start or failing A/C.
- Your Taurus uses identical multi-purpose relays for many functions; a failure can cause a no-start, A/C issues, or other electrical problems.
- Diagnosing a bad relay is easy: swap the suspect relay with a known good one from a less critical system (like the horn) and see if the problem moves.
- Replacement is a simple, 5-minute DIY job. The relays are located in the under-hood fuse box and just plug in.
- An affordable aftermarket relay is a reliable and cost-effective choice for this repair.
Symptoms of a Failing Relay
Because your Taurus uses the same type of relay for different jobs, the symptoms of failure will depend on which relay has gone bad. A failing relay is often caused by age, internal wear, or an electrical overload. Here are the most common scenarios:
- Engine Cranks but Won't Start: This is a classic sign of a bad fuel pump relay. The relay isn't switching on the fuel pump, so the engine isn't getting any gas. 🎬 Watch: Locate the fuel pump relay and inertia switch. You might also experience the engine stalling while driving.
- Car Won't Crank at All: If you turn the key and hear a single click or nothing at all, the starter relay could be the culprit. It's failing to send the powerful electric current needed to turn the starter motor.
- A/C Blows Air, But It's Not Cold: The A/C system uses a relay to engage the compressor clutch. If this relay fails, the compressor won't turn on to cool the air, even though the cabin fan is working fine. 🎬 See how to find and test your A/C relay.
Pro Tip: The Swap Test
Many relays in your fuse box are identical. As a simple diagnostic trick, you can swap the suspect relay (like the A/C relay) with a known good one from a non-essential system (like the horn). If the horn stops working and your A/C starts working, you've found the bad relay.
Choosing the Right Aftermarket Relay
When shopping for a new relay, you'll find options from the original manufacturer (OEM) and aftermarket brands. For a vehicle like the 1996-2008 Taurus, an aftermarket relay is often a smart choice.
- OEM: An OEM relay from Ford will be a direct replacement, but it can be more expensive and sometimes harder to find for older models.
- Aftermarket (Replacement Brand): Aftermarket brands produce relays that are designed to meet or exceed original specifications. For a common part like this, a quality aftermarket relay provides the same function and reliability as the original but at a lower cost. Since these relays are simple, standardized components, there is little risk in choosing a reputable aftermarket option.
Cost of Replacing a Ford Taurus Relay
Replacing a relay is one of the most affordable repairs you can perform. The part itself is inexpensive, and labor is minimal because it's a simple plug-in component.
| Part/Service | Estimated Cost |
|---|---|
| New OEM Relay | $20 - $45 |
| New Aftermarket Relay | $10 - $25 |
| Shop Labor | $41 - $61 |
Cost estimates are for a single relay and may vary by location and vehicle condition. The labor cost reflects a minimum shop charge or diagnostic time.
Frequently Asked Questions
Can I replace the relay myself?
Yes, this is a very easy DIY job. The relays are located in the fuse box in the engine bay. They simply pull out and the new one plugs in. No special tools are needed. It typically takes less than 10 minutes.
Where is the relay located on my Taurus?
Most of the important relays (fuel pump, A/C, starter) are in the power distribution box under the hood, usually near the battery. The inside of the box cover has a diagram showing what each relay does.
🎬 Watch: A complete guide to the Taurus fuse box diagram.Are all the relays in the fuse box the same?
No, but many of them are. Your fuse box will contain several identical multi-purpose relays for different systems. They often have the same part number printed on them. There are also other specialized relays that are not interchangeable, so always check the diagram or compare the old part to the new one.
Are there any recalls for Ford Taurus relays?
No, there are no active recalls or technical service bulletins (TSBs) from the NHTSA specifically for relay failures on the 1996-2008 Ford Taurus.
Helpful Videos
Technical Specifications
OEM Part Numbers: F57B-14B192-AA F8OZ-14N089-AA 5M5Z-14N089-A
Standard 4 or 5-pin ISO style multi-purpose relay, typically rated for 20-40 amps at 12V.
