Lincoln Navigator Starter Replacement Guide (1998-2017)
Don't get stranded by a bad starter; learn the symptoms and find the right replacement for your Navigator.
- A single click or slow crank are classic signs of a failing starter, but always test your battery first to rule it out.
- Replacement is possible for a skilled DIYer, but be prepared for a hard-to-reach top bolt, especially on 5.4L V8 models.
- For this vehicle, a new aftermarket starter from a reputable brand like Bosch, Denso, or Remy offers a great combination of quality and value.
- Ensure you order the correct starter for your specific engine (e.g., 5.4L V8 vs. 3.5L V6), as they are not interchangeable.
Is Your Lincoln Navigator's Starter Failing?
A starter motor rarely fails without giving some warning signs. While a complete no-start is the final symptom, you'll often notice other issues first. It's important to distinguish these from a weak battery, which can cause similar problems. If your vehicle's lights and radio work but the engine won't crank, the starter is a likely suspect.
Common Failure Symptoms:
- Single, Loud Click: You turn the key and hear one sharp click, but the engine doesn't turn over. This often means the starter's solenoid is engaging, but the motor itself isn't working.
- Rapid Clicking Noise: A series of fast clicks usually points to a weak battery, but it can also be a failing starter that isn't drawing enough power to crank the engine.
- Slow, Sluggish Crank: The engine seems to struggle to turn over, cranking much slower than usual. This can indicate a worn-out starter motor.
- Grinding or Whirring Noise: A grinding sound might mean the starter gear isn't engaging correctly with the flywheel. A whirring noise without the engine cranking means the starter motor is spinning but not engaging the engine at all.
Pro Tip: Check Your Battery First!
Many symptoms of a bad starter are identical to those of a weak battery or corroded battery terminals. Before you spend money on a new starter, make sure your battery is fully charged and the cable connections are clean and tight. If jump-starting the vehicle doesn't solve the problem, the starter is the more probable cause.
Choosing a New Aftermarket Starter
When replacing your starter, you'll choose between an OEM part from Motorcraft or a new aftermarket part. For a vehicle in the 1998-2017 range, a new aftermarket starter from a quality brand offers an excellent balance of reliability and value. Unlike some complex electronics, aftermarket starters have a proven track record.
Aftermarket Brand Tiers:
- Premium Aftermarket (Bosch, Denso): These brands are often the original equipment manufacturers (OEMs) for many automakers. They are known for high-quality, reliable parts that meet or exceed factory specifications. A new or remanufactured starter from Bosch or Denso is a top-tier choice.
- Quality Aftermarket (Remy, WAI Global): Brands like Remy and WAI Global are well-established in the aftermarket. Remy has a good reputation and is a go-to brand for many. WAI Global is also frequently used, with some users reporting positive experiences and good value. These brands offer a solid balance of price and performance.
- Standard Aftermarket (BBB Industries): BBB Industries is a major supplier of remanufactured parts to many auto parts stores. They provide a cost-effective solution, though experiences can vary like with any remanufactured part.
A Note on Remanufactured vs. New
A "remanufactured" starter is a used original part that has been rebuilt with new wear-and-tear components like brushes and bearings. A "new" aftermarket starter is made entirely from new components. For the Navigator, both new and quality remanufactured units from reputable brands are considered reliable options. The choice often comes down to warranty and price.
Cost to Replace a Lincoln Navigator Starter
The cost can vary based on your vehicle's year and the type of part you choose. Labor costs also differ by location and the specific engine in your Navigator.
| Part/Service | Estimated Cost |
|---|---|
| Shop Labor | $122 - $179 |
| New OEM (Motorcraft) | $142 - $278 |
| New Aftermarket | $84.69 - $211.92 |
| Total Professional Replacement | $206 - $390 (Aftermarket) to $264 - $457 (OEM) |
Frequently Asked Questions
Can I replace the starter myself?
Yes, this is a DIY-feasible job for someone with mechanical experience, but it can be challenging. The starter is typically held on by three bolts. On many 5.4L V8 models, the top bolt is notoriously difficult to access. Mechanics often use long extensions and a swivel socket, sometimes going through the passenger-side wheel well to reach it. 🎬 Watch this step-by-step guide for replacing a Navigator starter. Always disconnect the battery's negative terminal before starting any work.
Where is the starter located on my Navigator?
On most 1998-2017 Lincoln Navigators with V8 engines, the starter is located on the lower passenger side of the engine, where the engine meets the transmission bell housing. 🎬 See exactly where the starter is located on your engine. You will need to lift the vehicle securely on jack stands to access it from underneath.
Are there any recalls or TSBs for the starter?
Our search found no specific recalls or Technical Service Bulletins (TSBs) issued by Lincoln or the NHTSA for starter motor failure on 1998-2017 Navigators. However, numerous TSBs exist for other issues, so it's always wise to check for your specific VIN.
How do I know I'm ordering the right starter?
The Lincoln Navigator had different engines over its 1998-2017 model years, including the 5.4L V8 and the 3.5L EcoBoost V6. These different engines may use different starters. Always confirm the part fits your specific year, model, and engine size before ordering. Using your vehicle's VIN is the most accurate way to ensure a match.
Helpful Videos
Technical Specifications
OEM Part Numbers: DU2Z-11V002-CRM DL3Z-11002-A CK4Z-11002-C 9L3Z-11002-AARM 7L1Z-11002-A 5L3Z-11002-A 6L3Z-11002-AA
Voltage: 12V. Configuration: Permanent Magnet Gear Reduction (PMGR) is common. Tooth Count: Varies by part number, typically 9-12 teeth.
