Volvo S80 Power Steering Pump: A Guide for 1999-2010 Models
That whining sound from your engine bay when you turn the wheel is a common issue for Volvo S80 owners.
- Before replacing the pump for a whining noise, ALWAYS replace the power steering reservoir first; its internal filter clogs and is a very common culprit.
- Use the correct fluid. Most S80s require a specific synthetic hydraulic fluid (like Pentosin CHF-11S), not generic power steering fluid.
- If you own a 2007 S80, check for the open recall (NHTSA #11V378000) regarding a power steering hose that can burst.
- When replacing the pump, it's best practice to also replace the reservoir, fluid, and any suspect O-rings or hoses to prevent future leaks.
Is Your S80's Power Steering Pump Failing?
If you own a 1999-2010 Volvo S80, you might notice some distinct sounds or feelings from your steering. The most common problem is the power steering pump. These pumps can fail over time, but sometimes the problem is something simpler. This guide will help you understand the issues and choose the right aftermarket part.
Common Failure Symptoms
- Whining Noise: The most frequent complaint is a whining or groaning sound that gets louder when you turn the steering wheel and changes pitch with engine speed. 🎬 Watch: Hear what a failing S80 power steering pump sounds like.
- Stiff Steering: The steering wheel becomes difficult to turn, especially when parking or driving slowly.
- Fluid Leaks: You may see puddles of reddish or greenish fluid under the front of your car. Leaks can come from the pump itself, the hoses, or the reservoir.
- Foamy Fluid: If the fluid in the reservoir looks bubbly or foamy, it means air is getting into the system, often due to a leak or a bad seal.
Stop! Check This Before Replacing Your Pump
A very common issue on the Volvo S80 is a clogged filter inside the power steering fluid reservoir. This filter is not sold separately. A clogged reservoir can starve the pump for fluid, causing it to whine loudly, even if the pump itself is perfectly fine. Many owners have replaced the pump only to have the noise remain. Before buying a new pump, it is highly recommended to replace the power steering reservoir first. 🎬 See how to replace the reservoir and hose on P2 models. It's an inexpensive part that is often the true cause of the problem.
Known Issues for the 1999-2010 Volvo S80
Recall for 2007 Models: Volvo issued a recall for certain 2007 S80 sedans with the 6-cylinder non-turbo engine (NHTSA Campaign ID: 11V378000). An improperly routed power steering return hose could burst, leading to a sudden and dangerous loss of power steering. If you own a 2007 S80, you should check with a Volvo dealer to see if this recall applies to your vehicle and if the repair was performed.
Choosing the Right Aftermarket Power Steering Pump
When your pump does need replacement, you have several aftermarket options. Quality can vary, so it's important to understand the brands.
- Premium Brands (Bosch): Bosch is an original equipment (OE) supplier to many European car brands, including Volvo. Choosing a Bosch pump is the closest you can get to dealer quality. They are well-made and reliable, but also the most expensive aftermarket option.
- Remanufactured Brands (Cardone, BBB Industries): These companies are major suppliers of remanufactured parts. This means they take old pump cores, rebuild them with new seals and bearings, and test them. Quality can be inconsistent. While some units work perfectly for years, others may fail quickly. They offer a good value and often come with a warranty, but be prepared for the possibility of needing to use that warranty.
- Value Brands (Atlantic Automotive Enterprise, Mapco, PWR, Replacement): These brands typically offer new, lower-cost pumps. They are a budget-friendly option, but long-term reliability may not match premium or even good remanufactured units. If your budget is tight, they can be a viable choice, but a quality remanufactured part from a company with a good warranty might be a safer bet.
Pro Installation Tips
When replacing the pump, always replace the power steering reservoir, the O-rings on the high-pressure line, and use new fluid. For P2 platform cars (1999-2006), the correct fluid is often Pentosin CHF-11S, not standard power steering fluid or ATF. Using the wrong fluid can damage the new pump and other components. Always bleed the air out of the system after installation by turning the steering wheel from lock to lock several times with the engine running.
Replacement Cost
The cost to replace a Volvo S80 power steering pump depends on the parts you choose and who does the work. Note that labor for the V8 engine is significantly higher due to difficulty.
| Part / Service | Estimated Cost |
|---|---|
| New Aftermarket Pump | $142 - $346 |
| New OEM Pump | $610 - $832 |
| Remanufactured Pump | $150 - $280 |
| Shop Labor | $230 - $340 |
| Total Professional Replacement (Aftermarket) | $372 - $686 |
Frequently Asked Questions
Is replacing the S80 power steering pump a DIY job?
For the first generation (1999-2006), it is a manageable DIY job for someone with mechanical experience. The pump is located at the top of the engine and is relatively easy to access. For the second generation (2007-2010), especially models with the V8 engine, the job is much more complex and may be best left to a professional.
🎬 Watch this walkthrough for diagnosing and replacing a 2009 S80 pump.What is the difference between the first (1999-2006) and second (2007-2010) generation pumps?
The pumps are different parts for the P2 (1999-2006) and P3 (2007-2010) chassis S80s. They are not interchangeable. The location and replacement procedure also differ significantly, with the later models generally being more difficult to work on.
What kind of power steering fluid should I use?
This is critical. Most 1999-2010 S80s require a specific synthetic hydraulic fluid, often Pentosin CHF-11S or an equivalent. Do not use generic power steering fluid or automatic transmission fluid (ATF) unless your owner's manual specifically allows it. Using the wrong fluid will cause noise and can quickly destroy the pump and seals.
My new pump is still whining. What's wrong?
If a new pump is whining, the most likely causes are air in the system that needs to be bled out, or the true problem was a clogged power steering reservoir. Ensure the system is properly bled. If the noise continues, the reservoir is the most likely culprit.
Helpful Videos
Technical Specifications
OEM Part Numbers: 36000267 8251736 36002409 8251738
Belt-driven hydraulic pump. Fitment varies between 1999-2006 (P2) and 2007-2010 (P3) generations and by engine type. Requires specific synthetic hydraulic fluid.
We Have This Part in Stock
The information in this article is provided for general reference and educational purposes only. Vehicle specifications, procedures, and part compatibility can vary by production date, trim level, and region. Always consult your vehicle's factory service manual and verify part numbers before purchasing or performing repairs. Safety-critical components such as airbags, seat belts, and braking systems should be installed by a qualified professional.
