Saab 9-5 (1999-2011) Suspension Strut Bellows: A Complete Guide
Protecting your Saab 9-5's struts is crucial for ride quality; here's what you need to know about replacing the bellows.
- A torn strut bellow exposes your strut to damage; replace it promptly to avoid a more costly strut replacement.
- Aftermarket brands like KYB offer excellent quality and value for the Saab 9-5.
- Replacement requires a spring compressor and is a moderately difficult DIY job; consider replacing strut mounts at the same time.
- Clunking noises are common on the 9-5 and may be caused by other worn suspension parts, not just the bellow.
Is a Torn Strut Bellow a Serious Problem?
A torn strut bellow on your Saab 9-5 is a sign of impending trouble. While the car is still safe to drive, the damaged boot allows dirt and moisture to attack the strut's piston rod and seals. Over time, this contamination will wear out the strut itself, leading to a much more expensive repair. Early replacement of a torn bellow is a smart, preventative measure that saves you money and preserves your Saab's ride quality. You'll know it's time for a replacement when you see visible cracks or tears in the rubber boot, or if you hear clunking noises from the suspension over bumps, which can indicate the internal bump stop has failed.
Choosing the Right Aftermarket Bellows for Your 9-5
For a vehicle like the Saab 9-5, where parts can sometimes be scarce, the aftermarket provides excellent and affordable options. 🎬 See a detailed review of KYB suspension components. You don't need to hunt down a Genuine Saab part, as quality aftermarket brands offer reliable protection.
Brand Tiers for Suspension Strut Bellows:
- Reputable Aftermarket (KYB): KYB is a well-known manufacturer of suspension components and a common OEM supplier for many car brands. Their aftermarket bellows are designed to meet or exceed original equipment quality, offering a durable and direct-fit solution. For most 9-5 owners, a KYB boot kit is a reliable and cost-effective choice that provides excellent protection.
- Value-Oriented (Skyward, others): Brands like Skyward or other store-brands offer a budget-friendly alternative. While they will fit and function, the materials and long-term durability may not match that of a premium brand like KYB. They are a viable option if the budget is the primary concern, but it's wise to inspect them periodically for wear.
Pro Tip: Replace in Pairs and Check the Mounts
It is highly recommended to replace strut bellows in pairs (both front or both rear). If one has failed due to age, the other is likely not far behind. This is also the perfect time to inspect the strut mounts and bearings. A worn strut mount can cause clunking noises and poor steering feel. Replacing the bellows, bump stop, and mount at the same time is efficient since the strut assembly must be removed for all these jobs.
Vehicle-Specific Issues for the Saab 9-5
While there are no widespread recalls or Technical Service Bulletins (TSBs) specifically for the strut bellows on the 1999-2011 Saab 9-5, general suspension wear is common. Owners frequently report clunking noises which can be attributed to worn sway bar end links, 🎬 Learn how to replace sway bar end links yourself. control arm bushings, or the strut top mounts. A torn bellow is often discovered during the diagnosis of these other suspension noises. There was a recall for potential corrosion on front lower control arms in certain "salt-belt" states, but this did not involve the strut bellows directly.
| Part Type | Cost Range (Part Only) |
|---|---|
| New OEM (Genuine Saab) | $40 - $60 |
| New Aftermarket (KYB, Skyward) | $19.97 - $36.57 |
| Shop Labor | $197 - $288 |
Frequently Asked Questions (FAQ)
Do I need a special tool to replace the strut bellows?
Yes, replacing the strut bellows requires removing the entire strut assembly and then compressing the coil spring to disassemble it. A spring compressor is a critical safety tool 🎬 Watch this step-by-step guide on replacing your front struts. for this job. Attempting this without the proper tool is extremely dangerous as the compressed spring holds a large amount of energy. The job also requires a good set of metric sockets and wrenches.
Should I replace the whole strut or just the bellow?
If the strut is not leaking oil and still provides good damping (the car doesn't bounce excessively over bumps), you can just replace the bellow and bump stop. However, if your Saab has over 80,000 miles on its original struts, it's worth considering replacing the entire strut assembly while it's apart. A new strut will restore performance and you won't have to pay for the labor twice.
Is there a difference between front and rear bellows?
Yes, the front and rear strut bellows are typically different parts and are not interchangeable. Always verify the position (front or rear) when ordering.
Will a new strut bellow fix my car's clunking noise?
Not usually. The bellow itself is a soft rubber or plastic part and does not make noise. However, a torn bellow leads to the failure of the internal bump stop, which can cause a clunk when the suspension bottoms out. More commonly, clunking noises on a Saab 9-5 are caused by worn sway bar end links, strut top mounts, or control arm bushings.
Helpful Videos
Technical Specifications
OEM Part Numbers: 4565180 13243574
Fits front or rear suspension struts for all 1999-2011 Saab 9-5 models. Note that parts differ between front and rear, and for models with or without sport suspension.
