Ford Excursion Accelerator Pedal Sensor Guide (2000-2005)
Solving dead pedal, limp mode, and throttle problems in your 2000-2005 Ford Excursion.
- You MUST verify if you have fixed or power-adjustable pedals before ordering; they are not interchangeable.
- Symptoms include a 'dead pedal' where the engine only idles, sudden power loss, and a check engine light.
- This is an easy DIY replacement that takes less than 30 minutes with basic tools.
- A known defect affected 2002-2003 diesel models with adjustable pedals, leading to a Ford service campaign (FSA 03B03).
Is Your Excursion's Gas Pedal Acting Up?
A failing accelerator pedal sensor is a known issue on the 2000-2005 Ford Excursion, especially on diesel models with power-adjustable pedals. When this part fails, it can leave you stranded with an engine that only idles. Symptoms often start small and get worse over time. Understanding the signs and choosing the right replacement part is key to a lasting repair.
Symptoms of a Failing Accelerator Pedal Sensor
A bad pedal sensor will make your truck unreliable and unsafe to drive. Look for these common warning signs:
- Dead Pedal: This is the most common symptom. You press the gas pedal, but nothing happens. The engine idles but won't rev up. This can happen intermittently at first.
- Sudden Loss of Power: The truck may suddenly drop to idle speed while you are driving, forcing you to pull over.
- Check Engine or Wrench Light: A failing sensor will almost always turn on a warning light on your dash. Common trouble codes include P0220, P0221, and P2138.
- Erratic or Surging Acceleration: The truck might accelerate on its own or feel jerky, even with steady pressure on the pedal.
- Limp Mode: Your truck's computer may limit engine power to prevent an accident, a feature known as 'limp mode' or 'Reduced Engine Power'.
Known Issue: Power-Adjustable Pedals (2002-2003 Diesels)
Ford issued a Field Service Action (FSA 03B03) for 2002-2003 Excursions with the 7.3L diesel engine and power-adjustable pedals. The original sensors were known to fail because internal grease would leak and disrupt the signal. If you have this model, your pedal assembly may be one of the defective units.
Choosing the Right Aftermarket Part: The Most Common Mistake
Before you buy, you MUST know if your Excursion has fixed or power-adjustable pedals. The parts are not interchangeable. Look for the pedal adjustment switch on your dashboard, usually to the left of the steering wheel. If you have this switch, you need the assembly for adjustable pedals.
- Fixed Pedal Assembly: This is the less expensive and more common version.
- Adjustable Pedal Assembly: This part is much more expensive because it includes the motor and mechanism for adjustment. The sensor is integrated and typically cannot be replaced separately on these units.
Aftermarket Brand Quality: Dorman vs. Standard Ignition
For this part, the original Ford (Motorcraft) component is often preferred by mechanics but can be extremely expensive or discontinued. Aftermarket brands offer a more affordable solution.
- Dorman: Dorman is a well-known brand that produces a wide range of replacement pedal assemblies for the Excursion. They are a cost-effective and widely available option.
- Standard Ignition (SMP): SMP is another trusted aftermarket manufacturer. They state that their sensors are built to match the specific original output, which is important for proper engine communication.
Pro Tip: While some owners report success with aftermarket brands, others have had to replace them more than once. Given the huge price difference, a quality aftermarket part is a practical choice for most owners. However, if you plan to keep your Excursion for many more years, investing in an OEM part, if available, may provide longer-term peace of mind.
Cost of Replacing an Accelerator Pedal Sensor
| Part Type | Estimated Cost |
|---|---|
| New Aftermarket (Fixed Pedals) | $130 - $250 |
| New Aftermarket (Adjustable Pedals) | $450 - $1200+ |
| New OEM (Motorcraft) | $500 - $1500+ (if available) |
| Shop Labor | $75 - $150 |
Frequently Asked Questions (FAQ)
Can I replace just the sensor?
On some Excursions, particularly older models with fixed pedals, you might be able to replace just the sensor. However, for most, and especially for all models with power-adjustable pedals, the sensor is built into the pedal assembly and the entire unit must be replaced.
Is this a difficult repair to do myself?
No, this is a very easy DIY job. The pedal assembly is held in place by three 10mm bolts under the dashboard and has one electrical connector. Most people can complete the job in under 30 minutes with basic hand tools.
My throttle isn't working, but it's not the pedal sensor. What else could it be?
On 6.0L Powerstroke models, a 'no throttle' condition can sometimes be caused by a shorted sensor elsewhere on the same circuit, like the Exhaust Back Pressure (EBP) sensor. A damaged wiring harness or water in a connector can also cause the same symptoms.
Do I need to recalibrate the new pedal sensor?
Yes, it's a good practice. After installing the new pedal, turn the ignition to the 'ON' position (don't start the engine), slowly press the pedal all the way to the floor, then slowly release it. Turn the ignition off. This helps the computer learn the new sensor's voltage range.
Technical Specifications
OEM Part Numbers: 1C3Z9F836C 1C3Z9F836BA 3C3Z9F836BA EC3Z9F836A F81Z9F836AB 6C3Z9F836A
Electronic 'drive-by-wire' pedal assembly with integrated Accelerator Pedal Position (APP) sensor. Available in two distinct versions: one for fixed pedals and one for power-adjustable pedals. Connects via a single multi-pin electrical connector.
We Have This Part in Stock
The information in this article is provided for general reference and educational purposes only. Vehicle specifications, procedures, and part compatibility can vary by production date, trim level, and region. Always consult your vehicle's factory service manual and verify part numbers before purchasing or performing repairs. Safety-critical components such as airbags, seat belts, and braking systems should be installed by a qualified professional.
