A Guide to the Windshield Washer Pump for the 2001-2010 Volvo S60
If your washers have stopped spraying, the fix is often simple and inexpensive.
- Before replacing the pump, check for simple fixes like a blown fuse or clogged system from old fluid.
- Accessing the pump is the hardest part; it may require removing the front bumper cover for best results.
- Be sure to verify your chassis number or visually inspect your old pump before ordering, as parts changed around 2004-2005.
- A quality aftermarket pump from a brand like Vemo or Trico offers a reliable repair for a fraction of the OEM cost.
Is Your Volvo S60 Windshield Washer Not Working?
A non-spraying washer system is a common problem on the first-generation Volvo S60. When you activate the washers, you should hear a faint humming sound from the front of the car. If you hear the hum but see no fluid, the problem could be a clog or a leak. If you hear nothing at all, the pump has likely failed or is not receiving power. Before replacing the pump, it's wise to check for simpler issues first.
First, Check for Clogs
A very common issue on these Volvos is not a failed pump, but a clogged system. Algae or sludge can form in the reservoir, especially if different types of washer fluid are mixed. This gunk can clog the small filter at the pump's inlet. Before buying a new pump, try cleaning the system. 🎬 Watch: How to fix the most common Volvo washer issue You can use a siphon to empty the old fluid and look for debris. Sometimes, simply cleaning this filter and flushing the reservoir with warm water can restore function.
Symptoms of a Failing Windshield Washer Pump
- No Fluid Sprays: The most obvious symptom. You activate the switch, the wipers move, but no fluid comes out.
- No Sound from the Pump: If you don't hear a whirring or humming noise when you try to use the washers, the pump motor has likely failed.
- Low or Weak Spray: If the fluid just dribbles out, the pump motor may be getting weak and failing to create enough pressure. This can also be a symptom of a clog.
- Visible Fluid Leaks: Puddles of blue washer fluid under the front of your car, especially near the passenger-side wheel, point to a leak. 🎬 See this guide on locating the reservoir pump and hoses The pump's grommet seal can dry out and crack, causing fluid to leak from the reservoir.
Choosing the Right Aftermarket Pump
For the 2001-2010 S60, you don't need to buy a Genuine Volvo part to get your washers working again. Aftermarket pumps are affordable and get the job done. However, quality can vary between brands.
| Brand Tier | Brands | Quality & Cost Assessment |
|---|---|---|
| Premium Aftermarket | Vemo | Vemo is a German brand known for producing high-quality electronic parts and sensors for European vehicles, often meeting or exceeding OE standards. They are a reliable choice if you want a part that is built to last. Expect to pay a bit more than other aftermarket options. |
| Standard Aftermarket | Professional Parts Sweden (PPS), Trico | Professional Parts Sweden specializes in parts for Volvo and Saab, which sounds promising. However, owner experiences suggest quality can be inconsistent, with some parts failing prematurely. Trico is a well-known brand, famous for wiper blades, and offers a wide range of pumps that are generally considered reliable for daily use. These brands offer a good balance of cost and acceptable quality. |
| Economy | Various unbranded parts | The lowest-priced options are often unbranded or from lesser-known manufacturers. While they may work, their long-term durability and fitment can be a gamble. Given the low cost of standard aftermarket parts, it's often worth spending a few extra dollars for a brand with a better reputation. |
DIY Replacement Guide
Replacing the washer pump on the S60 is a straightforward job, but accessing it is the main challenge. The pump is push-fitted into the bottom of the washer fluid reservoir, which is located in front of the passenger-side wheel.
There are two common methods to gain access:
- Wheel Well Access: Some owners report success by turning the steering wheel all the way to the right, removing the front portion of the plastic fender liner, and reaching in to access the pump. This avoids removing the bumper but can be a very tight squeeze.
- Bumper Removal: The most reliable method is to remove the front bumper cover. While this sounds intimidating, it's a manageable task on the S60, 🎬 Watch: Step-by-step walkthrough for removing the reservoir tank typically involving a series of Torx screws and plastic clips along the top, sides, and bottom. This gives you wide-open access to the reservoir and pump.
Once you can reach the pump, the process is simple:
- Have a bucket ready to catch the remaining washer fluid.
- Disconnect the electrical connector and the washer fluid hose(s).
- Carefully pull the old pump straight out of the rubber grommet in the reservoir. The fluid will drain out.
- Clean the inside of the reservoir if you see any debris. It's highly recommended to replace the small rubber grommet seal at the same time.
- Press the new pump firmly into the new grommet.
- Reconnect the electrical plug and hose(s).
- Refill the reservoir and test the pump before reassembling your car.
Check for Headlight Washers
Some S60 models are equipped with high-pressure headlight washers. These systems may use a second, separate pump. Ensure you are ordering the correct pump for the windshield, not the headlights.
Frequently Asked Questions (FAQ)
How do I know if I need a new washer pump?
First, check fuse #15 in the cabin fuse box. If the fuse is good, listen for the pump's motor when you try to use the washers. If you hear nothing, the pump is the likely culprit. If you hear the motor running but get no fluid, you could have a clog, a leak, or a pump with a broken internal impeller.
Are there any recalls or TSBs for the S60 washer pump?
No. While there have been Volvo recalls for wiper arm software and loose wiper arm nuts on other models, there are no specific recalls or Technical Service Bulletins (TSBs) from Volvo or the NHTSA for windshield washer pump failure on the 2001-2010 S60.
What is the most common mistake when ordering this part?
The most common mistake is ordering the wrong part due to changes during the model run. Volvo used different pumps starting around the 2004-2005 model years. The OEM part number 30699674 is common for earlier models, while 31349235 is often listed for later ones. Always visually inspect your current pump and its electrical connector before ordering, or use your vehicle's chassis number to confirm fitment with the seller.
Can I just use a universal washer pump?
While universal pumps exist, it is not recommended for your S60. These often require you to cut and splice the factory wiring connector, which can lead to future electrical issues. A direct-fit aftermarket pump is inexpensive and ensures a proper, reliable connection without modifications.
Helpful Videos
Technical Specifications
OEM Part Numbers: 30699674 31349235 30649800 81439800
The windshield washer pump is a 12V electric motor that press-fits into the washer fluid reservoir, typically with a single outlet port for the front windshield. Some vehicles may have a second pump for headlight washers.
