Saturn Vue Manifold Absolute Pressure (MAP) Sensor: A Replacement Guide (2002-2010)
Learn to spot the signs of a failing MAP sensor in your Saturn Vue and how to choose the best aftermarket replacement.
- A failing MAP sensor on a Saturn Vue will cause a check engine light, poor gas mileage, rough idle, and hesitation.
- For this vehicle, a quality aftermarket brand like Bosch, Delphi, or Standard Motor Products offers the best value.
- Replacement is very easy and can be done at home in under 30 minutes with basic tools, saving on labor costs.
- Always verify the part fits your specific engine (2.2L 4-cyl vs. 3.5L V6) as they may differ.
Symptoms of a Failing MAP Sensor in a Saturn Vue
When a MAP sensor starts to fail, it sends incorrect information to your vehicle's computer. This can cause a variety of noticeable problems. You will almost certainly get a Check Engine Light on your dashboard. Common trouble codes associated with MAP sensor failure include P0106, P0107, P0108, and P0068.
🎬 Watch: Diagnosing P0068 and testing the MAP sensor on a 2.2L engine.Other common symptoms include:
- Poor Fuel Economy: One of the first things you might notice is needing to fill up your gas tank more often.
- Rough Idle: Your Vue might shake or vibrate more than usual when stopped, or the engine RPM may surge up and down.
- Hesitation or Stalling: You may experience a delay when you press the gas pedal, or the engine might stall completely when coming to a stop.
- Loss of Power: The vehicle may feel sluggish and have trouble accelerating, especially when going up hills.
- Black Smoke from Exhaust: If the sensor causes the engine to run too rich (too much fuel), you might see black smoke coming from the tailpipe.
- Failed Emissions Test: An incorrect air-fuel mixture will lead to higher emissions, causing a failed test.
Diagnosing the Problem
While these symptoms strongly point to a MAP sensor, other issues like a vacuum leak or a clogged catalytic converter can cause similar problems. It's important to have the trouble codes read with a scanner to confirm the issue is related to the MAP sensor circuit before replacing the part.
Choosing the Right Aftermarket MAP Sensor
For a vehicle like the 2002-2010 Saturn Vue, a quality aftermarket MAP sensor is a smart and cost-effective choice. OEM (Original Equipment Manufacturer) parts can be expensive and may not offer a significant advantage in longevity for this component. However, quality varies among aftermarket brands. Here’s a breakdown of available brands to help you choose.
Brand Tiers for Your Saturn Vue
- Top Tier (OEM Quality or Better): Brands like Bosch and Delphi are often original equipment suppliers to many automakers. They have a strong reputation for quality, durability, and providing accurate sensor readings that meet or exceed factory specifications. NGK/NTK is another top-tier brand known for its engine management components. Choosing one of these brands gives you the highest confidence in the part's performance and longevity.
- Mid Tier (Reliable Replacements): Standard Motor Products (SMP) and Walker Products are well-regarded in the aftermarket. They produce reliable parts that function correctly and offer a good balance between price and quality. Many professionals and DIY mechanics use these brands with confidence.
- Economy Tier (Budget-Friendly): Brands like Global Parts, MTC, Facet, and True Tech typically offer the lowest prices. While they can get your vehicle running, their long-term reliability and the precision of their sensor readings can be inconsistent. These are best considered for temporary fixes or if budget is the absolute primary concern.
Pro Tip: Check Engine Compatibility
The 2002-2010 Saturn Vue was available with several different engines, including a 2.2L 4-cylinder, a 3.5L V6 (from Honda), and other GM V6 engines. The exact MAP sensor part number can vary by engine. Always confirm the part fits your specific engine before purchasing.
Cost of Replacing a Saturn Vue MAP Sensor
The cost is relatively low, especially if you do the work yourself. The job is simple and requires basic tools.
| Item | Estimated Cost |
|---|---|
| New Aftermarket MAP Sensor | $39.20 - $89.28 |
| Shop Labor | $70 - $140 |
| DIY Total | $39.20 - $89.28 |
| Shop Replacement Total | $109 - $229 |
Frequently Asked Questions (FAQ)
Where is the MAP sensor located on my Saturn Vue?
The MAP sensor is typically located directly on the intake manifold or on the throttle body. For the 2.2L engine, it is behind the throttle body. 🎬 See this walkthrough for replacing the sensor on a 2.2L Vue. For the 3.5L V6 engine, it is on top of the throttle body, held in by a single screw. It is a small, black plastic sensor with an electrical connector.
Can I clean my MAP sensor instead of replacing it?
While some sensors can be cleaned, it is generally not recommended for MAP sensors. The internal components are delicate and can be damaged by cleaning solvents. A user in a forum noted that cleaning their throttle body may have contaminated and ruined their MAP sensor. Given the relatively low cost of a new part, replacement is the most reliable solution.
Is it difficult to replace a Saturn Vue MAP sensor?
No, this is a very easy repair for a DIY mechanic. The process usually involves disconnecting the electrical connector, removing one or two screws, and swapping the old sensor for the new one. 🎬 Watch: How to test and replace a sensor for P0107 and P0108 codes. The entire job can typically be done in less than 30 minutes with basic hand tools like a screwdriver or a small socket wrench.
What happens if I ignore a bad MAP sensor?
Driving with a failed MAP sensor can cause long-term damage. Running too rich (too much fuel) can foul your spark plugs and damage your expensive catalytic converter. Running too lean (not enough fuel) can cause engine overheating and internal damage. It's best to replace it as soon as possible to avoid more costly repairs.
Helpful Videos
Technical Specifications
OEM Part Numbers: 12569240 16137039 16254719 89053400
3-pin, bolt-on sensor. Provides a variable voltage signal to the ECU based on intake manifold pressure.
We Have This Part in Stock
The information in this article is provided for general reference and educational purposes only. Vehicle specifications, procedures, and part compatibility can vary by production date, trim level, and region. Always consult your vehicle's factory service manual and verify part numbers before purchasing or performing repairs. Safety-critical components such as airbags, seat belts, and braking systems should be installed by a qualified professional.
