Ford Explorer Ambient Air Temperature Sensor Guide (2002-2011)
Is your Explorer's temperature display wrong or is the A/C acting up? Your ambient air temperature sensor has likely failed.
- A bad ambient air temperature sensor primarily affects the dashboard temperature display and the automatic climate control system.
- For most owners, a quality aftermarket brand like Dorman or Standard Ignition provides the best value for this repair.
- Replacement is a simple DIY task that takes less than 15 minutes and requires only basic tools.
- There are no major recalls or technical service bulletins (TSBs) specifically for this part on the 2002-2011 Ford Explorer.
Symptoms of a Failing Sensor
When the ambient air temperature sensor goes bad, the symptoms are usually straightforward and not severe. You will likely notice one or more of the following issues:
- Incorrect Temperature on Dash: The most common sign is the outside temperature reading on your dashboard being obviously wrong. It might show a very low temperature (like -40°F), a very high one, or just be stuck on one number.
- Automatic A/C Problems: If your Explorer has automatic climate control, a bad sensor can cause problems. The system might blow hot air when it should be cold, or vice-versa, because it's getting incorrect information about the outside temperature.
- Check Engine Light: In some cases, a failed sensor can trigger the check engine light. You might see diagnostic trouble codes (DTCs) such as P0071, P0072, or P0073 when the vehicle is scanned. 🎬 Watch this guide to test and fix a P0073 code.
Choosing the Right Aftermarket Sensor
For a simple part like an ambient air temperature sensor, you don't always need to buy the most expensive option. However, quality can vary between brands. Here’s a breakdown of the available aftermarket brands to help you choose.
Brand Quality Tiers
- OEM (Original Equipment): Motorcraft is Ford's official brand. This is the part your Explorer was built with. It guarantees perfect fit and performance but is usually the most expensive option.
- Premium Aftermarket: Brands like Standard Ignition (SMP) and Dorman are well-regarded in the industry. They produce quality parts that meet or exceed OEM specifications. For a sensor like this, these brands offer a great balance of quality and value and are a reliable choice for most owners.
- Value/Economy Aftermarket: Brands such as Holstein, URO Parts, Skyward, and True Tech are typically more budget-friendly. Holstein positions itself as a quality alternative with good warranties. URO Parts is often seen as a budget brand, and while quality has improved over the years, it can be inconsistent for some components. For a non-critical sensor, these brands can be a cost-effective solution, but premium brands often provide more peace of mind.
Pro Tip: OEM vs. Aftermarket for This Part
The technology in an ambient air temperature sensor is not complex. A high-quality aftermarket sensor from a brand like Dorman or Standard Ignition will perform just as well as the OEM Motorcraft part for this specific application. The main risk with the cheapest options is less accurate readings or a shorter lifespan.
Installation and Location
On the 2002-2011 Ford Explorer, the ambient air temperature sensor is typically located in the front of the vehicle, behind the grille. It is often mounted to the radiator core support. Replacement is very easy and can be done with basic tools.
- Locate the sensor behind the front grille.
- Press the tab on the electrical connector and pull it off the sensor.
- The sensor is usually held in place by a plastic clip or a single small bolt. Unclip or unbolt it.
- Install the new sensor, plug in the connector, and you're done. 🎬 See this step-by-step sensor replacement walkthrough for your Explorer.
| Part Type | Estimated Cost |
|---|---|
| New Aftermarket | $6.47 - $63.18 |
| New OEM (Motorcraft) | $35 - $70 |
| Shop Labor | $50 - $100 |
Frequently Asked Questions
Where is the ambient air temperature sensor located on a 2002-2011 Explorer?
It is almost always found behind the front grille, mounted to the radiator support. You can usually see it by looking through the grille openings.
🎬 Watch this video to see exactly where the sensor is located.Can I replace this sensor myself?
Yes, this is a very easy DIY job. It typically requires no special tools and can be completed in under 15 minutes. The sensor unplugs and unclips or unbolts from its mount.
What happens if I don't replace a bad sensor?
Driving with a bad sensor will not damage your vehicle. However, your outside temperature display will be wrong, and the automatic climate control system may not work correctly, which can be an annoyance.
Why is my new sensor reading a few degrees off?
After installation, it can take some time for the sensor and the vehicle's computer to calibrate. Also, heat from the engine or pavement can cause the reading to be higher when the vehicle is stopped. The reading is most accurate when the vehicle is moving.
Helpful Videos
Technical Specifications
OEM Part Numbers: DY1162 6L2Z-12A647-A DY1137
2-Terminal, Plug-in Connector
