A Ford Expedition Owner's Guide to the 2003-2007 Rear Lateral Arm Assembly
If you're hearing clunks from the rear of your Expedition, this guide explains the likely cause and how to fix it.
- A clunking noise from the rear over bumps is the number one symptom of a bad lateral arm.
- A wheel alignment is not optional; it is required after this repair to prevent rapid tire wear.
- It is strongly recommended to replace lateral arms in pairs to ensure balanced handling and safety.
- Inspect the arms for severe rust, which is a known issue that can lead to part failure on these trucks.
Is Your Expedition Making a Clunking Noise?
A loud clunk or knock from the rear of your truck when going over bumps is the most common sign of a failing lateral arm. The sound comes from worn-out rubber bushings that allow metal parts to hit each other. You might also notice the rear of the vehicle feels loose or seems to 'wander' on the highway, especially in turns. Another key symptom is uneven wear on the inside or outside edge of your rear tires, as the worn arm can no longer hold the wheel alignment steady.
Known Issue: Rust and Corrosion
Owners have reported that the rear suspension arms on these Expeditions are prone to rusting, especially in areas that use road salt in the winter. In severe cases, the arm can rust through and break, causing a sudden loss of vehicle control. It is wise to inspect these arms for heavy rust or cracking, even if you don't have symptoms yet.
Choosing the Right Aftermarket Part
For the 2003-2007 Expedition, replacing the entire lateral arm assembly is much easier than trying to press out old bushings. Aftermarket assemblies come ready to install. The main choice is between standard replacement brands and those that offer enhanced designs.
- Dorman: This is a common, budget-friendly brand. Dorman parts are known for being a direct fit and are popular with DIY mechanics. They are a standard, reliable choice for daily driving, though some users note they may not last as long as more premium options.
- Mevotech: Mevotech often provides a good balance of quality and price. They are known for sometimes offering improved designs over the original and are considered a solid mid-tier option for drivers looking for durability.
Cost to Replace a Rear Lateral Arm
The total cost depends on whether you do the job yourself or hire a shop. A wheel alignment is required after the repair, so be sure to factor that in.
| Part or Service | Estimated Cost |
|---|---|
| New Aftermarket Part | $56 - $69 |
| Shop Labor | $125 - $250 |
| Wheel Alignment | $100 - $150 |
| Total Professional Repair | $281 - $469 (per side) |
Pro Tip: Replace in Pairs
It is highly recommended to replace both the left and right lateral arms at the same time. If one has failed due to age and mileage, the other is likely worn as well. Replacing them in pairs ensures balanced handling and prevents you from having to do the same job again soon.
Frequently Asked Questions (FAQ)
Do I absolutely need a wheel alignment after replacing a lateral arm?
Yes, an alignment is mandatory. The lateral arm (toe link) is the primary adjustment point for rear toe. Skipping the alignment will cause poor handling and destroy your rear tires very quickly.
Can I drive my Expedition with a bad lateral arm?
If the only symptom is a minor clunk, you can likely drive it cautiously to a repair shop. However, if the handling feels loose or the rear end wanders, it should be considered unsafe to drive. A complete failure of the arm can lead to a loss of vehicle control.
What's the difference between a lateral arm and a trailing arm?
On your Expedition's rear suspension, the lateral arm (or toe link) controls side-to-side wheel position. The trailing arm is a different part that controls the front-to-back movement of the wheel. Both can cause clunking noises when they fail.
Is this a difficult job to do at home?
For a DIYer with good mechanical skills and tools like a breaker bar, torque wrench, and jack stands, this job is manageable. The passenger side is straightforward. The driver's side can be more difficult because the gas tank may block one of the bolts, sometimes requiring extra patience or specific tools to access.
Technical Specifications
OEM Part Numbers: 2L1Z-5A972-AA 6L1Z-5A972-A
This part is a rear suspension lateral link, also known as a toe link. It is a critical component of the 2003-2007 Expedition's independent rear suspension (IRS) and is responsible for setting the rear toe angle.
