Hummer H2 Starter Motor Guide for 2003-2009 Models
A no-start or slow-crank on your H2 could be a bad starter; here’s how to choose the right replacement part.
- Failure symptoms often mimic a bad battery; always test the battery first to avoid a misdiagnosis.
- Heat soak is a common H2 issue where the starter fails when hot but works again after cooling down.
- When replacing the starter, you must transfer the original heat shield to the new part to protect it.
- High-quality aftermarket brands like ACDelco or Bosch offer reliability comparable to OEM parts for this vehicle.
Is Your Hummer H2 Starter Failing?
A bad starter can leave you stranded. Because the symptoms of a failing starter can be similar to a weak battery or loose cable, it's important to diagnose the problem correctly. Before replacing parts, make sure your battery is fully charged and the terminals are clean and tight. If the battery is good, look for these common starter failure symptoms.
Symptoms of a Bad Starter:
- Single Loud Click: You turn the key and hear one distinct click, but the engine doesn't crank. This is often the starter solenoid trying to engage the motor, but the motor itself is failing.
- No Sound at All: If you turn the key and nothing happens, and the battery is known to be good, the starter could be completely dead.
- Slow, Labored Cranking: The engine turns over very slowly, like the battery is dying. A failing starter can draw too much power, causing this symptom. This is especially common when the engine is hot.
- Intermittent Starting: The truck starts fine one day but refuses to crank the next. This unpredictability is a classic sign of a starter on its way out.
- Whirring or Grinding Noise: You might hear the starter motor spin (a whirring sound), but it fails to connect with the engine's flywheel, so the engine doesn't turn over.
Known Issue: Heat Soak
A very common problem for 2003-2009 H2s is starter 'heat soak'. This happens when the starter gets very hot from being close to the engine's exhaust manifold. When it's hot, it may refuse to crank. After the engine cools down for 30 minutes or more, it might start normally again. If this describes your problem, you almost certainly need a new starter. 🎬 See how heat soak affects your starter and how to fix it When replacing, it is critical to transfer the factory heat shield to the new starter.
Choosing the Right Aftermarket Starter
For a vehicle like the 2003-2009 H2, a quality aftermarket starter offers excellent value. You don't necessarily need to pay for a dealership OEM part. Aftermarket brands come in different quality tiers.
Premium Aftermarket (OEM-Equivalent)
These brands are known for making parts that meet or exceed original factory specifications. They are a reliable choice for a daily-driven H2.
- ACDelco (Professional or Gold lines): ACDelco is GM's parts division, and their aftermarket lines are considered a top-quality choice. They offer both new and remanufactured units that are built to a high standard.
- Bosch: A major OEM supplier for many car brands, Bosch offers high-quality new and remanufactured starters that are built to last.
Performance Aftermarket
If your H2 is modified, or if you want extra cranking power to combat heat soak, a performance starter is a good upgrade. These often have higher torque ratings.
- Powermaster: A well-known brand for high-torque and performance starters.
- Proform: Another brand offering starters designed for higher performance applications.
Standard Aftermarket
These brands provide a balance of quality and affordability, making them a popular choice for budget-conscious repairs.
- MPA (Motorcar Parts of America): A large supplier of starters, often sold under various store brand names.
- TYC / TRQ: These brands offer a wide range of affordable replacement parts, including starters.
New vs. Remanufactured
A 'remanufactured' starter isn't just used. It has been completely disassembled, cleaned, and rebuilt with new internal components like bushings, contacts, and brushes. A quality remanufactured starter from a top brand like ACDelco or Bosch is often just as reliable as a new one and can be a great value.
Hummer H2 Starter Replacement Cost
The cost to replace your H2's starter depends on the part you choose and whether you do the work yourself. Shop labor rates are typically between $134 and $197 for this job.
| Part Type | Estimated Part Cost |
|---|---|
| New Aftermarket | $101 - $284 |
| Remanufactured Aftermarket | $115 - $250 |
| New OEM (Dealer) | $250 - $675 |
| Used OEM | $55 - $110 |
Frequently Asked Questions
Can I drive my H2 with a bad starter?
No. If the starter is completely dead, the engine will not be able to start, leaving you stranded.
How do I know it's the starter and not the battery?
First, try jump-starting the vehicle. If it starts right up with a jump, your battery is likely the problem. If you have a good battery but only hear a click or a slow crank (especially when hot), the starter is the more likely culprit. Many auto parts stores can test your battery for free to confirm.
Is it hard to replace the starter on a 2003-2009 Hummer H2?
For a DIYer with some experience, it is a manageable job. It is located on the passenger side and typically held on by two long bolts. The main challenges are the weight of the starter and removing the skid plates to get access. You should plan for 2-3 hours for your first time.
🎬 Watch this video for helpful H2 starter installation tipsAre there any recalls on the H2 starter?
No. There have been no safety recalls issued by the NHTSA for the starter motor on the 2003-2009 Hummer H2. However, there is a Technical Service Bulletin (TSB) for a 'starter clicks - no crank' condition, showing it's a recognized issue.
Helpful Videos
Technical Specifications
OEM Part Numbers: 89017630 12583115 19185
The starter for the 6.0L and 6.2L V8 engines is typically a 12V unit with a 1.6 kW power rating and an 11-tooth gear. It mounts to the passenger side of the engine block with two long bolts.
We Have This Part in Stock
