Honda Pilot Windshield Washer Pump Guide (2003-2013)
If your washer fluid isn't spraying, the pump is a likely suspect. Here’s how to choose the right replacement for your Pilot.
- The 2003-2013 Pilot uses one pump for both front and rear washers; don't buy two separate parts.
- Before replacing the pump, check the fuse and listen for a humming sound to rule out simpler issues.
- Replacement is a simple DIY job, accessible by removing the passenger-side inner fender liner.
- A leaking grommet is a common issue; many aftermarket pumps include a new one.
Is Your Honda Pilot's Washer Pump Failing?
When you activate your windshield washers and nothing happens, or only a weak dribble comes out, it’s easy to assume the pump has failed. While this is a common issue, it's important to check a few things first before buying a new part. A dead washer pump is a common problem on the 2003-2013 Honda Pilot, but so are other, simpler issues.
Mechanic's Tip: Quick Diagnosis
Before you replace the pump, perform these simple checks:
- Check the Fuse: A blown fuse is the easiest fix. Consult your owner's manual for the location of the washer pump fuse and inspect it.
- Listen for the Pump: Have a friend stand near the front passenger-side wheel while you activate the washer switch. If you hear a humming or buzzing sound, the pump motor is getting power and trying to work. This means the problem is likely a clog, not a dead pump.
- Check for Clogs: The small filter screen on the pump's intake can get clogged with debris or gelled washer fluid. Additionally, the washer nozzles on the hood can get blocked. You can try clearing the nozzles with a small pin. 🎬 Watch this video to diagnose weak or non-spraying washer fluid.
Common Ordering Mistakes
The 2003-2013 Honda Pilot uses a single pump for both the front and rear windshields. This pump has two outlets. Do not order separate front and rear pumps. Ensure the replacement part you are considering is listed as compatible with your specific model year, as there can be slight differences in connectors or fittings between the first (2003-2008) and second (2009-2013) generations.
🎬 See how to replace the washer pump on 2003-2008 models.Choosing the Right Aftermarket Washer Pump
For a part like the windshield washer pump, an aftermarket replacement is often a smart, budget-friendly choice. The original Honda pumps can fail, and the job to replace one is straightforward enough that you don't need to overspend on a factory part.
OEM vs. Aftermarket Quality
An Original Equipment Manufacturer (OEM) pump from Honda will be a direct-fit replacement with guaranteed quality, but it comes at a higher price. High-quality aftermarket brands like Trico offer a reliable alternative for a fraction of the cost. These parts are designed to meet or exceed original specifications and are a common repair choice for both DIYers and professional shops. Given the simplicity of the part and the ease of replacement, saving money with a reputable aftermarket pump is a practical decision for most Pilot owners.
Cost of Replacing a Honda Pilot Washer Pump
| Part Type | Estimated Cost |
|---|---|
| New Aftermarket (e.g., Trico) | $24 - $38 |
| New OEM (Honda) | $35 - $57 |
| Shop Labor | $50 - $100 |
Known Issues, Recalls, and TSBs
Searches for the 2003-2013 Honda Pilot did not reveal any specific recalls or Technical Service Bulletins (TSBs) from Honda or the NHTSA for the windshield washer pump itself. However, a common, non-part-failure issue is the rubber grommet that seals the pump to the reservoir. Over time, this grommet can degrade and cause washer fluid to leak. Some owners have successfully fixed minor leaks by applying RTV silicone around the seal. Many aftermarket pump kits include a new grommet.
Frequently Asked Questions (FAQ)
How hard is it to replace the washer pump on a 2003-2013 Pilot?
This is a relatively easy DIY job. The pump is located at the bottom of the washer fluid reservoir on the front passenger side of the vehicle. Access is gained by partially removing the inner fender liner. 🎬 Follow this guide for 2009-2013 Honda Pilot washer motor replacement. The pump pulls straight out of its grommet in the reservoir. No special tools are required, though a trim removal tool can be helpful for the fender clips.
Do I need to drain the washer fluid to replace the pump?
Yes. When you pull the old pump out of the reservoir, all the remaining fluid will drain out. It's best to have a bucket ready to catch the old fluid.
My front washer works but the rear doesn't. Is the pump bad?
It could be. Since a single pump operates both systems by reversing polarity, it's possible for it to fail in only one direction. However, you should first check for a clogged or disconnected hose leading to the rear window before replacing the pump.
What kind of washer fluid should I use?
While any standard windshield washer fluid will work, some owners report that fluids with special additives (like certain types of Rain-X) can sometimes gum up and clog the pump's filter screen over time. Using a basic, quality washer fluid is a safe bet.
Helpful Videos
Technical Specifications
OEM Part Numbers: 76806-S9V-A01 76806-SZA-A01 76806-SZA-A12
Single motor pump with dual outlets (front/rear).
We Have This Part in Stock
The information in this article is provided for general reference and educational purposes only. Vehicle specifications, procedures, and part compatibility can vary by production date, trim level, and region. Always consult your vehicle's factory service manual and verify part numbers before purchasing or performing repairs. Safety-critical components such as airbags, seat belts, and braking systems should be installed by a qualified professional.
