2003-2014 Toyota Matrix Door Hinge & Check Replacement Guide
Solve your sagging, popping, or free-swinging door problems for good.
- First, confirm if your problem is the door hinge (sagging door) or the more common door check (free-swinging door).
- Replacing the door check is an easy DIY fix, while replacing the entire hinge is a complex job best left to a professional.
- No safety recalls have been issued for the door hinges on the 2003-2014 Toyota Matrix.
- Aftermarket brands like Dorman and Replacement offer a cost-effective solution for this common repair.
Is It Your Hinge or Your Door Check?
Many Toyota Matrix owners confuse a bad door check with a bad door hinge. Getting the diagnosis right is key, as the parts and the repair jobs are very different. Most often, the problem is the door check, which is a much easier and cheaper fix.
- Bad Door Check: The most common failure. The main symptom is a door that swings freely with no resistance. It won't hold itself open on a slight incline and can easily be caught by the wind, potentially hitting a car parked next to you. You might hear a pop or click, but the door itself is not sagging.
- Bad Door Hinge: This is less common but more serious. A worn hinge causes the door to physically sag. You'll notice the door is hard to close, you have to lift it to latch properly, and you may see uneven gaps between the door and the car's body. It can also cause creaking or grinding sounds from metal-on-metal contact.
Symptoms of a Failing Door Hinge or Check
Diagnose Before You Buy
Open your door and try to lift it up and down from the far end. If you feel movement or play, and see the hinge pivot points moving, your hinges are worn. If the door is solid but just swings freely without stopping, your door check has failed.
Common Ordering Mistakes
The biggest mistake is ordering a new set of hinges when you only need a door check. The front door check for the Matrix is often a universal part that can be flipped to fit either the driver's or passenger's side. Always confirm if you need the hinge (the pivot) or the check (the strap) before purchasing.
Choosing the Right Aftermarket Part
For a daily driver, a quality aftermarket part offers a great balance of price and performance. OEM parts are available but are often significantly more expensive, especially for a simple part like a door check.
Brand Tiers for Toyota Matrix Door Hinges:
- Dorman: A widely recognized aftermarket brand. Dorman's quality can be hit-or-miss depending on the part, but they are a common choice and readily available. They often provide a functional replacement at a much lower cost than OEM. For a part like a door hinge, their products are generally considered a reliable repair option.
- Replacement: This is typically a house brand or generic equivalent. These parts are designed to be the most budget-friendly option. They meet the basic specifications to fit and function like the original part, making them a good choice for a straightforward, cost-effective repair.
Pro Tip: Replace in Pairs?
For door hinges, it's a good idea to replace both the upper and lower hinges at the same time if one is showing significant wear. A worn hinge puts extra stress on the other. For door checks, you only need to replace the one that has failed.
🎬 See this walkthrough for replacing the rear door checksCost of Replacing a Toyota Matrix Door Hinge
| Part | Cost Range |
|---|---|
| New Aftermarket Door Hinge | $25 - $50 |
| New Aftermarket Door Check | $10 - $20 |
| OEM Toyota Door Hinge | $100 - $180+ |
| OEM Toyota Door Check | $100 - $150 |
| Shop Labor (Hinge Replacement) | $250 - $500 |
| Shop Labor (Door Check Replacement) | $80 - $150 |
Note: Costs are estimates and can vary by location and garage. Hinge replacement is labor-intensive because the fender and door often need to be removed.
Frequently Asked Questions
Is there a recall on the 2003-2014 Toyota Matrix door hinges?
No. As of early 2026, there are no active recalls from the NHTSA or Toyota for the door hinges on the 2003-2014 Toyota Matrix. There was a recall for door glass bolts on 2003-2004 models, but this is unrelated to the hinges.
Can I replace just the hinge pin and bushing?
Yes, hinge pin and bushing kits are available. This can be a cheaper option if the hinge body itself is in good condition. However, this repair still requires specialized tools and the removal of the old pin, which can be difficult. For many DIY mechanics, replacing the entire hinge assembly is more straightforward.
How difficult is it to replace a Matrix door hinge or door check?
Replacing the door check is a relatively easy DIY job that takes about an hour. It involves removing the interior door panel 🎬 Watch: How to remove the door panel and replace the check to access the bolts. Replacing the door hinge is much more difficult. It often requires removing the door, supporting its weight, and potentially removing the front fender to access all the bolts. This is a job best left to experienced mechanics.
🎬 Watch: A guide on how to replace a car door hingeDo I need to paint the new aftermarket hinge?
Most aftermarket hinges come with a black E-coat or primer for corrosion resistance. While not strictly necessary, painting the hinge to match your vehicle's body color will provide a factory look and an extra layer of protection against rust.
Helpful Videos
Technical Specifications
OEM Part Numbers: 68720-12150 68710-12150 68740-02050 68720-02060 68710-02060 68610-02170 68620-02061
This article covers both the upper and lower door hinges, as well as the door check strap, for all doors on the 2003-2014 Toyota Matrix.
We Have This Part in Stock
The information in this article is provided for general reference and educational purposes only. Vehicle specifications, procedures, and part compatibility can vary by production date, trim level, and region. Always consult your vehicle's factory service manual and verify part numbers before purchasing or performing repairs. Safety-critical components such as airbags, seat belts, and braking systems should be installed by a qualified professional.
