A Guide to Front Brake Pad Sets for the 2004-2006 Scion xA
Choosing the right front brake pads is the key to safe, quiet stops in your Scion xA.
- The Scion xA has front disc brakes and rear drum brakes; ensure you are buying front pads.
- Squealing is a warning, but grinding means you must stop driving and replace the pads and likely rotors immediately.
- For OEM-like quiet performance, choose ceramic pads from brands like Advics or Akebono.
- Always replace brake hardware and lubricate caliper slide pins for a quiet, long-lasting job.
Is it Time for New Brake Pads?
The most common signs you need to replace the front brake pads on your 2004-2006 Scion xA are audible. You might hear a high-pitched squealing noise when you apply the brakes, which is often the first warning. This sound comes from a small metal tab called a wear indicator, which is designed to contact the brake rotor when the pad material gets low. If you ignore the squeal, it will eventually turn into a loud, harsh grinding noise. This is a serious issue that means the pad material is completely gone, and the metal backing plate is grinding against the rotor, causing significant damage.
Known Issues, Recalls, or TSBs
For the 2004-2006 Scion xA, there are no open recalls or widespread Technical Service Bulletins (TSBs) from Toyota related to the front brake pads. The most common reported problems, like brake noise, are related to normal wear and tear. Some owners have reported persistent squeaking even after a pad replacement, which is often caused by not replacing or resurfacing the brake rotors, failing to lubricate caliper slide pins, or not using new hardware clips.
Choosing the Right Aftermarket Pads for Your xA
Your Scion xA came from the factory with quiet, long-lasting ceramic-based brake pads. When choosing a replacement, you have several options that can match or even change your car's braking feel.
OEM-Equivalent Brands
These brands are known for providing parts that meet or exceed the quality of the original factory pads. They are an excellent choice for daily driving, offering a balance of quiet operation, low dust, and reliable stopping power. Many owners prefer these for a no-fuss, factory-feel replacement.
- Advics: Advics is an original equipment (OE) supplier to Toyota, so their aftermarket pads are designed to restore the original braking performance and feel. They are a top-tier choice for quality and fit.
- Akebono: Like Advics, Akebono is a well-regarded OEM supplier for many Japanese vehicles, including Toyota. Their ProACT line is a popular premium ceramic pad that offers quiet, smooth stopping with very little brake dust.
Performance Upgrade Brands
If you want more initial bite and better resistance to brake fade during spirited driving, a performance pad is a good option. These pads may create slightly more dust or noise than OEM pads as a trade-off for increased performance.
- Hawk Performance: Scion owners have recommended Hawk pads for their significant improvement in stopping power over the stock pads. They are a popular upgrade for those seeking a sportier feel.
- EBC Brakes: EBC offers different compounds, from the OEM-replacement Ultimax2 to the Greenstuff pads for better performance, allowing you to choose based on your driving style.
- Powerstop: Powerstop often bundles pads and rotors together in kits. They are a popular choice for an all-in-one brake job, providing a noticeable upgrade over stock components.
Daily Driver & Budget-Friendly Brands
These brands offer a great combination of quality and value. They are perfect for a daily-driven xA, providing safe, reliable braking without the premium price tag of OEM-supplier brands.
- Bosch QuietCast: Often recommended as one of the best values, Bosch QuietCast pads are known for being quiet and reliable for everyday use.
- Centric/StopTech: Centric provides a wide range of brake parts and is a go-to for a solid daily driver replacement.
- Raybestos: The Element3 line from Raybestos is another well-regarded option that provides good performance and longevity for the price.
Common Ordering Mistake: Front vs. Rear Brakes
The 2004-2006 Scion xA has disc brakes on the front wheels and drum brakes on the rear wheels. This guide and these parts are only for the front disc brakes. Ensure you are ordering a front "Disc Brake Pad Set" and not rear "Brake Shoes."
Cost of Replacing Scion xA Front Brake Pads
| Part Type | Estimated Cost |
|---|---|
| New OEM Pads (Dealer) | $75 - $105 |
| New Aftermarket Pads | $26 - $88 |
| Shop Labor | $100 - $180 |
| Total (Aftermarket Pads + Labor) | $126 - $268 |
Cost estimates are for parts and labor and can vary by location and shop. This estimate is for brake pads only and does not include the cost of new rotors.
Frequently Asked Questions (FAQ)
Do I need to replace my rotors with my brake pads?
It is highly recommended. Most shops will insist on replacing or resurfacing rotors when installing new pads. Installing new pads on old, worn, or warped rotors can cause noise, vibration, and reduced performance. Given the low cost of new rotors for the xA, replacement is usually the best and most cost-effective option.
What's the difference between ceramic and semi-metallic pads?
Ceramic pads, like the ones your xA came with, are known for being very quiet and producing a fine, light-colored dust that is less noticeable on wheels. Semi-metallic pads can offer better performance in extreme temperatures but are often noisier and produce more dark-colored dust. For a daily-driven Scion xA, ceramic pads are the preferred choice for most owners.
What is "bedding-in" new brake pads?
Bedding-in is a process of a few controlled stops to transfer an even layer of friction material from the new pads onto the brake rotors. This ensures smooth, quiet, and powerful braking. Most brake pad manufacturers include specific bedding-in instructions in the box. Following this procedure is crucial for best performance.
Why are my new brakes making noise?
If new brakes are squeaking, it can be due to several factors. The most common cause is brake dust buildup or vibration between the pads and the caliper. Ensure that new hardware clips were used, and a small amount of brake lubricant was applied to the contact points on the caliper bracket and the back of the pads. Also, make sure the caliper slide pins are clean and move freely.
Technical Specifications
OEM Part Numbers: 04465-52210 04465-52170
Fits front axle. The system uses single-piston floating calipers. The vehicle is equipped with rear drum brakes, which use brake shoes, not pads.
