Ford Freestar Windshield Washer Pump Replacement Guide (2004-2007)
Get your windshield washers working again by diagnosing and replacing the pump on your 2004-2007 Ford Freestar.
- Before replacing the pump, always check for a blown fuse and clean the washer nozzles with a pin.
- Replacement is a simple DIY job, typically requiring you to move the coolant reservoir to access the pump at the bottom of the washer tank.
- A humming sound with no spray points to a clog, while no sound at all points to an electrical issue or a dead pump.
- Check the price of a genuine Ford OEM pump (Part # 7L2Z-17664-A), as it can be surprisingly competitive with aftermarket options.
Is Your Windshield Washer Pump Failing?
When the washer pump on your 2004-2007 Ford Freestar gives out, the signs are usually obvious. The most common issue is a complete lack of washer fluid spraying onto your windshield. Before you assume the pump is bad, make sure your washer fluid reservoir is full. If the tank is full, there are two main scenarios:
- You hear nothing: If you activate the washer switch and hear no humming sound from the front of the vehicle, the pump is likely dead or not receiving power. This could be the pump itself, a blown fuse, or a wiring issue.
- You hear a humming sound: If you can hear the pump motor running but no fluid comes out, the pump might be clogged internally, or you could have clogged nozzles or a blocked hose. 🎬 Watch: 7 common reasons your washer fluid isn't spraying.
Diagnose Before You Buy
Before ordering a new pump, perform a few quick checks. First, check the fuse for the washer system in your vehicle's fuse box. On some Fords, the washer pump gets its power through a relay inside the main windshield wiper motor, so if the fuse is good, the problem could be the wiper motor or the multifunction switch on the steering column. 🎬 See this guide on how to troubleshoot a washer pump. Also, try cleaning the spray nozzles on the hood with a small pin to clear any debris.
Choosing the Right Aftermarket Pump
For the 2004-2007 Freestar, the aftermarket offers reliable and affordable solutions. Brands like Trico specialize in wiper and washer components and have been in the business for a long time.
Trico Windshield Washer Pumps: These are designed to be direct-fit replacements, meaning they install easily without any modifications. They are typically made from durable plastic and are built to match the performance of the original factory part. For a vehicle like the Freestar, a quality aftermarket pump from a reputable brand like Trico provides a good balance of performance and value.
Interestingly, the original equipment (OEM) Ford part is sometimes available at a price that is very competitive with aftermarket options. It's worth checking the price of the genuine Ford pump (part number 7L2Z-17664-A) before making a final decision, as you might be able to get the factory part for a similar cost.
Windshield Washer Pump Replacement Cost
The cost to replace the washer pump on a Ford Freestar is reasonable, especially if you do it yourself. The part itself is not expensive, and labor time is low.
| Part/Service | Estimated Cost |
|---|---|
| New Aftermarket Pump | $27 - $41 |
| New OEM Ford Pump | $23 - $35 |
| Shop Labor | $98 - $143 |
| Total Shop Replacement | $132 - $182 |
DIY Installation is Feasible
Replacing the washer pump on a Freestar is a straightforward job that most DIYers can handle. On the similar Ford Freestyle platform, the pump is located at the bottom of the washer fluid reservoir. Access is gained by unbolting and moving the coolant reservoir aside—you don't need to disconnect its hoses. Once you can reach the washer tank, the old pump simply pulls out of its rubber grommet, the electrical connector and fluid hose are swapped to the new pump, and it's pushed back into place. The entire job can often be done in under an hour.
🎬 Watch this step-by-step washer pump replacement walkthrough.Frequently Asked Questions (FAQ)
Can I drive my Freestar with a broken washer pump?
Yes, you can still drive the vehicle. However, your ability to clear the windshield of dirt, insects, or road spray will be gone, which can be a serious safety hazard in poor weather or driving conditions.
Is there a recall on the 2004-2007 Ford Freestar washer pump?
No, there are no active recalls or common Technical Service Bulletins (TSBs) from Ford or the NHTSA for the windshield washer pump on this specific vehicle. Recalls for washer systems on other Ford models do not apply to the Freestar.
Why did my washer pump fail?
Failure is usually due to the age and normal wear and tear of the internal electric motor. Running the pump while the reservoir is empty can also cause it to wear out faster. In colder climates, using plain water instead of freeze-resistant washer fluid can cause the fluid to freeze and damage the pump.
What if a new pump doesn't fix the problem?
If you've replaced the pump and checked the fuse, but it still doesn't work, the issue is likely electrical. The problem could be the multifunction switch (the stalk on your steering column), the wiring, or a relay inside the main wiper motor assembly that controls the pump.
Helpful Videos
Technical Specifications
OEM Part Numbers: 7L2Z-17664-A 6F9Z-17664-A F75Z-17664-BA F75Z-17664-BB
The pump for the Freestar is a dual-nozzle unit that serves both the front and rear windshields. It is a 12V electric motor that press-fits into a rubber grommet on the washer fluid reservoir.
