Saturn Relay Serpentine Belt Guide for 2005-2007 Models
Understand the signs of a failing serpentine belt and how to choose the right replacement for your van's specific engine.
- Confirm your engine size (3.5L for 2005, 3.9L for 2006-07) before ordering, as the belts are different.
- Plan to replace the belt tensioner and inspect the idler pulleys at the same time as the belt to prevent future failure.
- Listen for squealing or grinding noises, as these are the earliest and most common signs of a failing belt system component.
- A broken belt will make the vehicle undrivable; do not ignore warning signs.
Is Your Saturn Relay Making Noises?
A failing serpentine belt system often gives audible warnings. The most common issues on the 2005-2007 Saturn Relay are not always the belt itself, but the pulleys that guide and tension it. A high-pitched squeal, chirp, or a grinding noise from the engine area are tell-tale signs of a problem. These sounds often point to a worn-out bearing in the belt tensioner or an idler pulley. You should also visually inspect the belt for cracks, fraying, glazing, or missing ribs, which are clear signs it needs replacement.
🎬 Watch: How to spot the signs of a failing belt.Choosing the Right Aftermarket Serpentine Belt
When shopping for a new serpentine belt, it's crucial to buy one that matches your Relay's specific engine, as they are different lengths. The 2005 model uses a 3.5L V6, while the 2006-2007 models have a 3.9L V6. Always confirm the engine size before purchasing.
While the original GM/ACDelco part is available, high-quality aftermarket brands offer excellent performance and value. For this part, there is little difference in quality between a premium aftermarket brand and the original from the dealer.
- Premium Brands (Good): Dayco is a well-known manufacturer that produces belts meeting OE quality standards. They are a reliable and cost-effective choice for a direct replacement.
- Premium Brands (Better): Continental belts, which took over the popular Goodyear Gatorback design, are highly regarded. They are often praised for their quiet operation and ability to solve chirping issues on problem-prone drives.
- Premium Brands (Best): Gates is one of the most respected names in belt-drive systems and is a very common choice for professional mechanics. Gates belts are known for their durability and precise fit, making them a top-tier option.
Pro Tip: Replace More Than Just the Belt
The automatic belt tensioner and idler pulleys wear out at a similar rate to the belt. Since the belt must be removed to replace these parts, it is highly recommended to replace the belt, tensioner, and any noisy idler pulleys at the same time. This saves you from having to do the same job twice and prevents the new belt from being damaged by a failing pulley.
Aftermarket Serpentine Belt Cost for 2005-2007 Saturn Relay
| Part | Estimated Cost |
|---|---|
| New Aftermarket Serpentine Belt | $23.45 - $60.55 |
| New Aftermarket Tensioner Assembly | $25.00 - $100.00 |
Cost estimates are for the parts only and do not include labor or taxes. Prices are subject to change.
Frequently Asked Questions
When should I replace my Saturn Relay's serpentine belt?
Most serpentine belts are designed to last between 60,000 and 100,000 miles. However, you should inspect it regularly for signs of wear like cracks, fraying, or glazing. Any unusual noises like squealing or chirping are also indicators that the belt or its pulleys need immediate attention.
Is the belt different for the 3.5L and 3.9L engines?
Yes, the belts are different lengths and are not interchangeable. The 2005 Saturn Relay came with a 3.5L V6 engine. The 2006 and 2007 models came with a 3.9L V6 engine. You must purchase the correct belt for your specific engine to ensure proper fit and function.
What is a belt tensioner and why should I replace it?
The belt tensioner is a spring-loaded pulley that automatically keeps the serpentine belt tight. The spring can weaken over time, or the pulley's internal bearing can fail, causing noise and allowing the belt to slip. 🎬 See this step-by-step guide to replacing a noisy 3.5L tensioner. A bad tensioner can cause a brand new belt to wear out quickly or even fly off, so it's wise to replace it with the belt.
Were there any recalls on the Saturn Relay serpentine belt?
No, there have been no recalls issued by the NHTSA for the serpentine belt, tensioner, or pulleys on the 2005-2007 Saturn Relay. Recalls for this vehicle were related to other components like the parking brake and seat assemblies.
Helpful Videos
Technical Specifications
OEM Part Numbers: 12570215 12578274
The key difference is the engine type. The 2005 model uses a 3.5L V6 engine. The 2006-2007 models use a 3.9L V6 engine. Belts are not cross-compatible.
