A Guide to Replacing the Radiator on a 2005-2009 Chevrolet Uplander
Keep your Uplander's engine from overheating by understanding the signs of a failing radiator and how to choose the right replacement.
- The most common radiator failure on the Uplander is a leak from the plastic side tanks cracking.
- Overheating is the most serious symptom; pull over immediately to prevent engine damage.
- While a DIY replacement is possible, it is a time-consuming job that requires removing several other components for access.
- When replacing the radiator, it is highly recommended to also replace the radiator hoses and cap.
Is Your Uplander's Radiator Failing?
A bad radiator can lead to serious engine trouble. If you notice any of these signs, it's time to inspect your cooling system. Ignoring them can cause your engine to overheat, which may lead to expensive repairs.
Common Failure Symptoms
- Engine Overheating: The most obvious sign. If your temperature gauge is in the red, 🎬 Follow this video to remove a radiator causing overheating issues. your radiator may not be cooling effectively.
- Coolant Leaks: Finding puddles of green, orange, or pink fluid under the front of your van is a strong indicator of a leak. The most common sources of leaks on an Uplander are the radiator itself, or the hoses connected to it.
- Low Coolant Level: Frequently needing to add coolant to the reservoir means you have a leak somewhere in the system.
- Visible Damage or Corrosion: Look for bent fins, corrosion, or cracks on the radiator's plastic side tanks. Over time, the plastic can become brittle and crack, causing leaks.
- Steam from Engine Bay: If you see steam, pull over immediately. This means hot coolant is escaping the system.
Known Issues for the 2005-2009 Chevrolet Uplander
While there are no specific recalls for the radiator on the 2005-2009 Uplander, some related issues are worth noting. General Motors issued a Technical Service Bulletin (TSB 07-06-02-006E) for some 2006-2007 Uplanders with the 3.5L or 3.9L engines concerning coolant leaks from the crossover pipe gaskets, not the radiator itself. However, the most common failure point on these radiators is cracking of the plastic side tanks where they are crimped to the aluminum core. Coolant leaks can also come from aging rubber hoses or loose hose connections.
Choosing the Right Aftermarket Radiator
When replacing your Uplander's radiator, you don't have to buy an expensive part from the dealer (OEM). Aftermarket parts can offer similar or even better quality for less money. Aftermarket brands are designed to fit and function like the original part. Here’s a look at some available brands:
- Denso: Denso is a well-regarded OEM supplier for many car brands. Their aftermarket radiators generally have a good reputation for quality and fit, though some users note that the replacement parts may differ from the original factory-installed Denso parts.
- Spectra: Spectra is a popular aftermarket brand. While some users have had positive experiences with good fit and performance, others have reported needing warranty replacements after a couple of years. Quality can sometimes be inconsistent.
- CSF Radiator: CSF is another option, though some mechanics report issues like wrong parts being in the box. Their plastic tank radiators are generally considered okay.
- APDI, Global Parts, One Stop Solutions, Onix: These brands are typically more budget-focused. They can be a good value, but quality and longevity may not match premium aftermarket or OEM parts.
Pro Tip: When you replace the radiator, it's a good idea to also replace the upper and lower radiator hoses and the radiator cap. These parts are inexpensive and wear out over time. It's also a good time to flush the cooling system and refill with fresh, correct-spec coolant.
Cost of Replacing a Chevrolet Uplander Radiator
The cost can vary depending on whether you do the job yourself or hire a professional mechanic. Below is an estimated breakdown of costs.
| Part/Service | Estimated Cost |
|---|---|
| New Aftermarket Radiator | $142 - $235 |
| Shop Labor | $317 - $465 |
| Total Professional Replacement | $459 - $700+ |
Note: Labor costs can vary by location. Total cost for a professional replacement is often higher, with some estimates ranging from $917 to $1,066 when including parts at full markup.
Frequently Asked Questions
Can I drive my Uplander with a leaking radiator?
It is not recommended. A small leak can quickly become a big one, leading to rapid coolant loss and engine overheating. This can cause severe engine damage, like a blown head gasket. It's best to get the vehicle repaired as soon as possible.
Is replacing the radiator a DIY job? 🎬 Watch this step-by-step guide for removing your Uplander's radiator.
For a moderately experienced DIYer, yes. The job requires removing the air filter assembly, coolant reservoir, and electric cooling fans to get access. You will also need to disconnect radiator hoses and transmission cooler lines. It can take several hours. 🎬 See a helpful walkthrough of the radiator removal process. If you are not comfortable with this level of work, it's best to have a professional do it.
What's the difference between an OEM and an aftermarket radiator?
OEM (Original Equipment Manufacturer) parts are made by the same company that supplied Chevrolet for the factory. They guarantee a perfect fit but are more expensive. Aftermarket parts are made by other companies to fit your vehicle and are usually more affordable, with a wider range of quality and price points.
What type of coolant should I use in my 2005-2009 Uplander?
Always use the coolant specified in your owner's manual. For this generation of GM vehicles, it is typically DEX-COOL long-life coolant. Using the wrong type of coolant can cause corrosion and clog the radiator.
Helpful Videos
Technical Specifications
OEM Part Numbers: 15841572 22723883
The radiator for the 2005-2009 Chevrolet Uplander is a crossflow type with an aluminum core and plastic tanks. It includes an integrated engine oil cooler and an automatic transmission fluid cooler. Core dimensions and hose connection locations are specific to the vehicle.
We Have This Part in Stock
The information in this article is provided for general reference and educational purposes only. Vehicle specifications, procedures, and part compatibility can vary by production date, trim level, and region. Always consult your vehicle's factory service manual and verify part numbers before purchasing or performing repairs. Safety-critical components such as airbags, seat belts, and braking systems should be installed by a qualified professional.
