Guide to the Engine Crankshaft Position Sensor for 2007-2012 Jeep Wrangler JK
Solve common stalling, misfiring, and no-start problems by understanding this critical sensor in your Wrangler.
- You must verify your engine (3.8L for 2007-2011, 3.6L for 2012) before buying; the sensors are different.
- Symptoms like stalling often worsen as the engine gets hot.
- Premium aftermarket brands like NGK/NTK or Delphi are highly recommended for reliability over cheaper alternatives.
- Replacement is a feasible DIY job that requires basic tools and can be done in about an hour.
A Tale of Two Engines: 3.8L vs. 3.6L Sensors
The 2007-2012 period for the Jeep Wrangler JK covers two different engines, and they use different crankshaft position sensors. It is crucial to buy the correct part for your specific engine.
- 2007-2011 Jeep Wrangler (3.8L V6): This engine, sometimes called the "minivan motor," has its crankshaft sensor located on the passenger side of the transmission bell housing. It can be a little tight to access, but replacement is straightforward with a 10mm socket and an extension.
- 2012 Jeep Wrangler (3.6L V6 Pentastar): The 2012 model year introduced the more modern 3.6L Pentastar engine. On this engine, the sensor is located on the lower passenger side of the engine block, making it relatively easy to access from underneath the vehicle.
Choosing the Right Aftermarket Crankshaft Sensor
While a Mopar-branded sensor is an option, the aftermarket offers a wide range of parts that can provide excellent value and reliability. Not all aftermarket brands are created equal, especially for critical sensors on a Jeep. Here’s a breakdown of brand quality tiers based on community feedback and industry reputation.
- Premium Aftermarket (Recommended): Brands like NGK/NTK and Delphi are often original equipment (OE) suppliers to many automakers. They are widely trusted in the Jeep community for providing OE-level quality and reliability without the dealership price tag. Choosing one of these brands is your best bet for a long-lasting repair.
- Mid-Grade / Value: Brands like Standard Ignition (SMP), Dorman, and Spectra offer a good balance of price and quality. They are generally reliable, though some Jeep owners have reported mixed results, particularly with Dorman. These are a solid choice if premium brands are not available.
- Jeep-Specific & Economy: Brands like Crown Automotive and Omix-Ada specialize in Jeep parts. While they offer a huge catalog, the quality of their electronic sensors can be inconsistent compared to their mechanical parts. Other brands like Holstein or True Tech fall into the economy category. These sensors are very affordable but may have a shorter lifespan, making them more suitable for a temporary fix or a tight budget.
Cost to Replace a Wrangler Crankshaft Position Sensor
| Item | Estimated Cost |
|---|---|
| New OEM (Mopar) Part | $63 - $99 |
| New Aftermarket Part | $21.83 - $114.84 |
| Shop Labor | $84 - $140 |
| Total Professional Replacement | $148 - $223 |
Frequently Asked Questions
What are the most common symptoms of a bad crankshaft sensor on a JK?
The most common symptoms are the engine cranking but not starting, intermittent stalling (especially when the engine is hot), a rough idle, engine misfires, and the check engine light illuminating with codes like P0335 or P0339.
Can I drive my Wrangler with a failing crankshaft sensor?
It is not recommended. A failing sensor can cause the engine to stall unexpectedly at any time, including at high speeds or in traffic, which is a serious safety risk. It's best to get the vehicle repaired as soon as possible.
Is an OEM Mopar sensor better than aftermarket for my Jeep?
For critical sensors, many Jeep owners prefer to stick with Mopar or a known OEM supplier like NGK/NTK. While the Mopar part is a safe bet, a premium aftermarket sensor from a brand like NGK or Delphi will often perform identically for less money. Cheaper, lesser-known aftermarket brands can be a gamble and may fail prematurely.
Do I need to do a "relearn" procedure after replacing the sensor?
For a simple crankshaft position sensor replacement on the 2007-2012 Wrangler, a relearn or recalibration procedure is generally not required. You should be able to install the new sensor, clear any diagnostic codes, and drive the vehicle. In some rare cases after a failure, a scan tool might be needed to resync cam and crank signals if misfires persist.
Helpful Videos
Technical Specifications
OEM Part Numbers: 56028815AA 68067539AA 5149078AD 68029495AA
For 2007-2011 3.8L V6 models. For 2012 3.6L V6 Pentastar models. The sensor is a Hall effect type sensor that reads the position of the crankshaft via a tone wheel.
