Volvo S80 Windshield Washer Pump Replacement Guide (2006-2016)
Everything a 2006-2016 Volvo S80 owner needs to know about diagnosing and replacing a failed windshield washer pump.
- A silent pump is the most common sign of failure; listen for the hum when you pull the washer stalk.
- Replacement is a simple DIY job accessed through the passenger-side wheel well, not by removing the bumper.
- Aftermarket pumps from brands like Vemo or Trico offer good value compared to the much higher cost of an OEM part.
- There are no recalls for this part; failure is a result of normal wear and tear.
Is Your S80's Windshield Washer Pump Failing?
When a washer pump starts to fail on the 2006-2016 S80, the signs are usually obvious. The most common issue is that nothing happens when you try to wash your windshield. Before assuming the pump is bad, make sure your washer fluid reservoir is full and check the fuse for the washer system. On some S80 models, the fuse for the washer pump also powers the wipers, so if the wipers move but no fluid sprays, the fuse is likely okay.
Primary Symptoms of a Bad Washer Pump:
- No Sound, No Fluid: You pull the washer lever and hear nothing from the front of the car. A healthy pump makes a distinct humming or buzzing noise when it runs. No sound is the biggest clue that the pump motor has died.
- Pump Hums, But Weak or No Spray: If you can hear the pump running but the spray is weak or non-existent, the issue could be clogged nozzles, a blocked filter in the reservoir, or a failing pump that can no longer build enough pressure.
- Visible Fluid Leaks: Puddles of washer fluid under the front of your car, especially near the passenger-side wheel, can indicate a cracked pump housing or a bad seal where the pump enters the reservoir.
Check This First!
Before ordering a new pump, check the fuse panel. A blown fuse can mimic the symptoms of a dead pump. Also, check for clogs in the washer nozzles on the hood by clearing them with a small pin.
🎬 See how to diagnose and test a failing washer pump.Choosing the Right Aftermarket Washer Pump
For the 2006-2016 Volvo S80, the original equipment (OEM) washer pump is a reliable part, but it can be expensive, with some dealers charging over $85. Aftermarket pumps offer a significant cost saving and are a very common repair. For a simple part like this, a quality aftermarket brand provides excellent value.
Aftermarket Brand Tiers for Volvo S80
- Vemo: Often considered a higher-tier aftermarket brand, Vemo specializes in electronics and sensors for European cars. They focus on durable materials and reliable, quiet operation, making them a strong choice if you want quality close to OEM.
- Trico: Trico has been a major name in windshield cleaning technology since 1917. While known for wiper blades, their washer pumps are designed for easy, direct-fit installation and are a solid, dependable mid-range option.
- Professional Parts Sweden (PPS): This brand offers a wide range of parts specifically for Volvo and Saab vehicles. They are typically the most budget-friendly option. While they can be a good value, some owner feedback suggests that quality can be inconsistent on more complex parts. For a simple washer pump, they are a viable economy choice.
Cost of Replacing a Volvo S80 Washer Pump (2006-2016)
| Part Type | Estimated Cost |
|---|---|
| New Aftermarket Part | $14 - $35 |
| New OEM Part | $85 - $122 |
| Shop Labor | $95 - $178 |
| Total Professional Replacement (Aftermarket) | $109 - $213 |
| Total Professional Replacement (OEM) | $180 - $300 |
DIY Savings
Replacing the washer pump on an S80 is a beginner-friendly DIY job. The pump is located at the bottom of the washer reservoir and can be accessed by partially removing the front passenger-side wheel well liner. The entire job can often be done in less than an hour, saving you over $100 in labor costs.
🎬 Watch this step-by-step S80 washer pump replacement guide.Frequently Asked Questions
Where is the washer pump located on a 2006-2016 Volvo S80?
The windshield washer pump is push-fitted into the bottom of the washer fluid reservoir. You can access it by turning the steering wheel to the right and removing some of the clips holding the front part of the passenger-side plastic wheel well liner.
Do I need to remove the front bumper to replace the washer pump?
No. While it may seem hidden, you do not need to remove the front bumper. Access is gained through the wheel well. Attempting to remove the bumper will add significant time and complexity to the job unnecessarily.
My S80 has headlight washers. Does it use the same pump?
No, vehicles with headlight washers typically have a separate, high-pressure pump for that system. The pump for the windshield is a different, low-pressure part. The most common failure is the windshield washer pump.
Are there any recalls for the Volvo S80 washer pump?
No, there are no active recalls or technical service bulletins (TSBs) from Volvo or the NHTSA for windshield washer pump failure on the 2006-2016 S80. Failures are typically due to normal age and wear.
What tools are needed to replace the S80 washer pump?
You will need basic hand tools, including a tool to remove the plastic clips for the wheel liner, a pair of pliers to help remove the hose, and a bucket to catch the old washer fluid that will drain from the reservoir when you pull the old pump out. No special Volvo-specific tools are required.
Helpful Videos
Technical Specifications
OEM Part Numbers: 31349235 30699953 30663138
Fits 2006-2016 Volvo S80 models. This is a single-outlet, low-pressure pump for the windshield washer system only. It is a push-fit installation into the washer reservoir grommet.
We Have This Part in Stock
The information in this article is provided for general reference and educational purposes only. Vehicle specifications, procedures, and part compatibility can vary by production date, trim level, and region. Always consult your vehicle's factory service manual and verify part numbers before purchasing or performing repairs. Safety-critical components such as airbags, seat belts, and braking systems should be installed by a qualified professional.
