Dodge Nitro Windshield Washer Pump Guide (2007-2012): Replacement and Recall Info
Don't let a bad washer pump disable your wipers; here's what every 2007-2012 Dodge Nitro owner needs to know.
- A faulty washer pump can disable your wipers due to a critical safety recall (NHTSA 16V-813).
- Ensure any replacement part is the updated design to prevent damage to the Body Control Module (BCM).
- Replacement is simple for a DIYer and requires minimal tools, with access through the driver's side wheel well.
- Before replacing the pump, always check for a blown fuse, empty fluid, or clogged nozzles first.
Is Your Dodge Nitro Washer Pump More Than Just a Nuisance?
When your windshield washers stop working, it feels like a minor problem. But for 2007-2012 Dodge Nitro owners, a failed washer pump can lead to a much bigger issue. It's a simple part, but replacing it correctly is important for the health of your vehicle's electrical system.
Urgent Safety Recall Information: NHTSA 16V-813
There is a critical safety recall for the windshield washer pump on the Dodge Nitro. The original factory pump can create a voltage spike when used, potentially overloading and damaging the Body Control Module (BCM). This can cause your front windshield wipers to stop working entirely, which is a serious safety hazard in poor weather. The official remedy was a free replacement of the faulty washer pump with an updated part. Before buying any replacement, it's crucial to ensure your vehicle has had this recall service performed or that the new part is designed to prevent this issue.
Symptoms of a Failing Washer Pump
Before you assume the pump is bad, check the simple things first. Make sure your washer fluid reservoir is full. Check the fuse related to the washer system in your vehicle's fuse box. Also, inspect the spray nozzles on the hood to see if they are clogged with wax or debris. 🎬 See how to easily replace a clogged washer nozzle. If those are fine, you may have a bad pump if you notice these symptoms:
- No Sound: When you activate the washer switch, you should hear a distinct humming sound from the pump. If it's silent, the pump is likely not receiving power or has failed internally.
- No Fluid Spray: If you can hear the pump running but no fluid comes out, the pump's internal impeller might be broken, or the system could have a clog or a disconnected hose.
- Fluid Leaks: Puddles of washer fluid under the front driver's side of the vehicle can indicate a cracked pump housing or a bad seal where the pump enters the reservoir.
Choosing the Right Aftermarket Pump
Given the recall, the choice between OEM and aftermarket is important. A Mopar replacement part is guaranteed to be the corrected version. When choosing an aftermarket part, you want to ensure it's a quality component that won't cause the same electrical issues as the original. Brands like Crown Automotive and Trico are common aftermarket suppliers for these components. While both offer direct-fit replacements, the most critical factor is not the brand name but whether the part is engineered to the revised specifications that prevent BCM damage. Given the identical price point for the available aftermarket options, quality and design are the main considerations.
| Part Type | Estimated Cost |
|---|---|
| New OEM (Mopar) | $110 - $167 |
| New Aftermarket (Crown, Trico) | $57.11 |
| Shop Labor | $73 - $107 |
DIY Installation Tips
Replacing the washer pump on a Dodge Nitro is a job most DIYers can handle in under an hour. The pump is a press-fit into a rubber grommet on the reservoir. You don't need to remove the reservoir itself. The easiest way to access it is by turning the steering wheel to the right, removing a few clips from the driver's side front wheel well liner, and pulling the liner back to reach the pump. Have a bucket 🎬 Watch this step-by-step walkthrough of the pump replacement process. ready to catch the old washer fluid when you pull the pump out.
Frequently Asked Questions
Is there a separate pump for the front and rear washers?
No, the 2007-2012 Dodge Nitro uses a single, reversible pump. The motor spins in one direction for the front sprayers and the opposite direction for the rear sprayer. If both front and rear washers stop working at the same time, the pump is the most likely culprit.
How can I check if the recall was done on my Nitro?
You can check for open recalls on your specific vehicle by entering your Vehicle Identification Number (VIN) on the NHTSA's official website or the Mopar owner's portal. A dealership can also check this for you.
Can I really do this replacement myself?
Yes, this is a very DIY-friendly repair. It typically requires basic hand tools to remove the wheel well liner fasteners. The pump itself just pulls out and the new one pushes in, along with disconnecting a single electrical plug and two hoses.
My pump makes noise but nothing sprays. Is it still the pump?
It could be, but first check for other issues. The small filter screen on the pump's inlet can get clogged with algae or debris from old fluid. Also, check for cracked or disconnected washer fluid lines, which can happen, especially in freezing weather. If the lines and nozzles are clear, the pump's motor may be running but the internal mechanism that moves the fluid has failed.
Helpful Videos
Technical Specifications
OEM Part Numbers: 5179153AC 5179153AB 5179153AA
Single reversible motor pump for front and rear washer systems.
