Jeep Compass Automatic Transmission Oil Cooler Guide (2007-2016)
A mechanic's guide to fixing transmission overheating issues in your 2007-2016 Jeep Compass.
- The cooler is critical for the CVT transmission in the 2007-2016 Compass; failure leads to expensive transmission damage.
- Symptoms include an overheating light, whining noises, and a burning smell.
- Visually check if your cooler is separate or integrated with the A/C condenser before buying a part.
- Upgrading to a heavy-duty aftermarket cooler from a brand like Hayden or Derale is a common and recommended fix.
Is Your Jeep Compass Transmission Overheating?
If you own a 2007-2016 Jeep Compass, especially one with a CVT automatic, the transmission oil cooler is a part you need to know about. These transmissions are very sensitive to heat. A failing cooler can quickly lead to a transmission that costs thousands to replace. Recognizing the symptoms early is key.
🎬 Watch: Why these transmissions overheat and how to spot it.Critical Failure Signs
The most common signs of a failing transmission cooler are directly related to the transmission fluid getting too hot. Ignoring these can lead to complete transmission failure.
- Transmission Overheating Light: A warning light on your dash is the most obvious sign. Your Jeep may go into "limp mode," reducing power to protect itself.
- Whining Noise: A high-pitched whine or whirring sound that gets louder as you accelerate is a classic symptom of an overheating CVT.
- Burning Smell: Fluid that is too hot gives off a distinct burnt toast smell.
- Fluid Leaks: Finding reddish or brown fluid under the front of your vehicle points to a leak from the cooler or its lines.
- Poor Shifting or Power Loss: If the transmission feels like it's slipping, hesitating, or not accelerating properly, the fluid may be compromised due to heat.
Choosing the Right Aftermarket Cooler
The original Mopar cooler is a known weak point, prone to clogging and causing the very issues it's meant to prevent. Because of this, many owners choose an aftermarket replacement. Aftermarket brands often provide better cooling performance and can be a smart upgrade.
When shopping, you'll find two main types of coolers:
- Direct-Fit, OE-Style: These are designed to be a direct replacement for the factory part. Brands like Four Seasons, Global Parts, and some Skyward models fall into this category. They are affordable and get the job done without modifications.
- Heavy-Duty & Upgrade Kits: Brands like Hayden and Derale specialize in cooling. They offer plate-and-fin style coolers that are more efficient than the factory tube-and-fin design. Many owners choose these as an upgrade to prevent future overheating, especially if they live in a hot climate or do any light towing.
Pro Tip: Some 2007-2016 Compass models have the transmission cooler integrated into the A/C condenser. It's one single unit. Before ordering, visually inspect your vehicle to see if you have a small, separate cooler or if it's part of the larger A/C condenser assembly. This is the most common ordering mistake.
Cost of Replacing a Jeep Compass Transmission Cooler
The cost depends on whether you do it yourself or use a repair shop. The parts themselves are not very expensive, but labor can add up.
| Part/Service | Estimated Cost |
|---|---|
| New Aftermarket Cooler | $51 - $161 |
| New OEM Mopar Cooler | $200 - $320 |
| Shop Labor | $160 - $335 |
| Total Professional Replacement (Aftermarket Part) | $211 - $496 |
Frequently Asked Questions
Are there any recalls for the transmission cooler on my Jeep Compass?
No. As of early 2026, there are no active recalls from Jeep or NHTSA specifically for the automatic transmission oil cooler on the 2007-2016 Jeep Compass. While there was a recall for a cooler *tube* on some Jeep Wranglers, it did not apply to the Compass. Problems with the cooler are considered a component failure to be repaired by the owner.
Can I just add an extra cooler instead of replacing the old one?
Yes. Many owners choose to add a small, universal aftermarket cooler (like one from Hayden or Derale) in-line with the factory system. This is a popular modification to improve cooling and extend the life of the CVT transmission. 🎬 See how to install an auxiliary cooler and change filters. It can significantly lower fluid temperatures.
Is this a difficult part to replace myself?
For a DIY mechanic with some experience, it's a manageable job. It's rated at about a 3 out of 5 for difficulty and should take around 2.5 hours. You'll need to safely lift the vehicle, drain and catch transmission fluid, and have the right tools to disconnect the lines. 🎬 Watch this walkthrough on replacing CVT transmission cooler lines. The main challenge is accessing the cooler, which is located at the front of the vehicle.
What kind of transmission fluid do I need after replacing the cooler?
This is critical. For models with the CVT, you MUST use a fluid that meets the CVTF+4 specification. Using the wrong fluid can destroy the transmission very quickly. Always check your owner's manual or a reliable parts source for the exact fluid type your vehicle requires.
What is the difference between a cooler and a condenser/cooler assembly?
On some Jeep Compass models, the transmission cooler is a separate, small radiator. On others, it is built into the A/C condenser as a single unit. If your A/C condenser has extra ports where transmission lines connect, you have the integrated assembly. You must order the correct part for your specific vehicle, so a visual inspection is highly recommended before purchasing.
Helpful Videos
Technical Specifications
OEM Part Numbers: 68025160AA 68004055AA 68078975AB
Fits 2007-2016 Jeep Compass models with automatic transmissions (both CVT and 6-speed, though failure is more critical on CVT). Available as a standalone unit or as an integrated A/C condenser/cooler assembly. Requires CVTF+4 fluid for CVT models upon refill.
We Have This Part in Stock
The information in this article is provided for general reference and educational purposes only. Vehicle specifications, procedures, and part compatibility can vary by production date, trim level, and region. Always consult your vehicle's factory service manual and verify part numbers before purchasing or performing repairs. Safety-critical components such as airbags, seat belts, and braking systems should be installed by a qualified professional.
