Ford Expedition Brake Light Switch Guide for 2007-2017 Models
If your Expedition is stuck in park or the brake lights are acting up, this is the guide you need.
- A failing brake light switch is the most likely cause if your Expedition is stuck in park and/or the brake lights don't work.
- This is a critical safety part. Driving without working brake lights is dangerous and illegal.
- Replacement is a simple, fast DIY job. Paying close attention to twisting the switch to lock it in place is key to a successful repair.
- For best results, using an OEM Motorcraft or a premium aftermarket brand like Standard Ignition is recommended over budget options.
Is Your Expedition's Brake Light Switch Failing?
A faulty brake light switch on the 2007-2017 Expedition often shows clear symptoms. Because the switch controls multiple systems, a failure can appear in several ways. You might experience one or more of these issues, which can start intermittently before the switch fails completely.
Common Symptoms:
- Stuck in Park: This is one of the most common signs. You press the brake, but the gear shifter won't move. This happens because the switch isn't telling the shift interlock solenoid that your foot is on the brake.
- No Brake Lights: Your brake lights do not turn on at all when you press the pedal. This is a major safety risk and makes the vehicle illegal to drive.
- Brake Lights Stay On: The opposite problem can also occur, where the brake lights remain on even when your foot is off the pedal, which can drain your battery.
- Cruise Control Won't Work: The cruise control system may not engage, or it might shut off unexpectedly. The system relies on the brake light switch to know when to disengage.
- ABS Warning Light: In some cases, a failing switch can trigger the ABS warning light on your dashboard.
No Recalls, But a Common Problem
While there are no official recalls from the NHTSA for the brake light switch on the 2007-2017 Ford Expedition, failure is a widely documented issue among owners. The symptoms often appear suddenly, leaving you stranded.
Choosing the Right Aftermarket Brake Light Switch
When replacing the brake light switch, you have a choice between the original Ford part (Motorcraft) and several aftermarket brands. For a simple but critical part like this, quality matters.
Brand Quality Tiers
- OEM (Motorcraft): This is the original part your Expedition came with. It's the benchmark for fit, quality, and longevity. Many owners and mechanics recommend sticking with Motorcraft to avoid potential issues with aftermarket fitment or premature failure.
- Premium Aftermarket (Standard Ignition): Brands like Standard Motor Products (SMP) have a strong reputation for producing quality electronic components that are reliable alternatives to OEM. They are often a trusted choice for professional mechanics.
- Mid-Grade Aftermarket (Dorman, Holstein): Dorman is a massive aftermarket supplier with a wide range of parts. Their quality can be inconsistent; some parts work flawlessly for years, while others may fail sooner than OEM. Holstein focuses on vehicle sensors and claims to meet or exceed OE standards, backing their parts with a good warranty.
- Economy Aftermarket (Replacement, True Tech): These brands focus on providing the lowest-cost option. While budget-friendly, their long-term reliability may not match that of higher-priced brands. For a part this critical to safety and vehicle operation, saving a few dollars here might not be worth the risk.
Installation Pro Tip
Replacing the switch is an easy DIY job. It's located on the brake pedal bracket under the dash. You simply disconnect the wire, twist the old switch to remove it, and install the new one in reverse. However, be careful during installation. The switch must be twisted and locked into the bracket correctly. If not installed properly, the internal plunger won't activate, and the new switch will not work, even if it's a high-quality part. Also, ensure the wiring harness isn't pulled tight, as this can cause the new switch to malfunction.
Cost of a New Brake Light Switch (2007-2017 Expedition)
| Part Type | Estimated Cost |
|---|---|
| New Aftermarket | $23.47 - $57.41 |
| New OEM (Motorcraft) | $25 - $59 |
| Shop Labor | $50 - $100 |
Frequently Asked Questions
Is it hard to replace a Ford Expedition brake light switch?
No, it is considered a very easy repair. It requires no special tools and is accessible from under the driver's side dashboard. The process typically takes less than 30 minutes.
Why won't my Expedition shift out of park even after replacing the switch?
First, check that the new switch was installed correctly; it must be twisted to lock into place, which engages the plunger. Second, check the related fuse to ensure it's not blown. If both are good, the problem may lie with the shift interlock solenoid itself or the wiring between the switch and the solenoid.
Can a bad brake light switch drain my battery?
Yes. If the switch fails in the 'on' position, it will keep your brake lights illuminated even when the truck is off, draining the battery overnight.
What's the difference between a brake light switch and a brake pedal position sensor?
On many modern vehicles, they are the same part. The term Brake Pedal Position (BPP) Sensor is often used interchangeably with Brake Light Switch because the component does more than just control the lights; it sends pedal position data to the vehicle's computer.
Helpful Videos
Technical Specifications
OEM Part Numbers: 8T4Z-13480-A BL3Z-13480-A GL3Z-13480-A
Located on the brake pedal support bracket. The switch activates the brake lights, shift interlock, and cruise control functions.
