2008-2013 BMW X5 (E70) Windshield Washer Pump: A Replacement Guide
Is your washer fluid leaking or not spraying? Here’s what you need to know before replacing the pump on your X5.
- Failure is often a physical crack causing a leak, not just a dead motor.
- Replacement is a difficult, high-labor job requiring removal of the fender liner, side skirt, and fender.
- Always replace the rubber pump grommets/filters at the same time to prevent future leaks.
- Consider replacing both the front and rear pumps simultaneously since the labor is the same.
Symptoms of a Failing Windshield Washer Pump
A bad washer pump on an E70 X5 often does more than just stop working. Because of its location and design, a common failure point is a crack in the pump housing, which leads to leaks.
- No Spray: The most obvious sign is when no fluid sprays on the windshield or rear window when you pull the stalk. You may or may not hear the pump motor hum.
- Visible Leak: Finding a puddle of blue or green washer fluid under the front passenger-side of your X5 is a strong indicator. The reservoir and pumps are located behind the fender liner in this area. 🎬 Watch this guide to identify and fix common washer leaks.
- Low Fluid Warning Light: If the 'Low Washer Fluid' warning stays on even after you've filled the reservoir, it's likely leaking out through a cracked pump or a bad grommet seal.
- Weak Spray: Low pressure can be caused by a dying pump or, more commonly, a clogged filter screen at the base of the pump. Algae and residue from certain washer fluids can block these filters over time.
Choosing the Right Aftermarket Pump
When shopping for a replacement, you'll find Original Equipment (OEM) and aftermarket options. For the E70 X5, the labor involved in the replacement is the most significant part of the job, so choosing a reliable part is critical to avoid doing the work twice.
OEM vs. Aftermarket Quality
| Part Type | Assessment |
|---|---|
| OEM (Dealer) | Highest cost, but guaranteed fit and quality. The original parts are known to fail by cracking, so a new OEM part is not necessarily a permanent solution. |
| Premium Aftermarket (e.g., VDO, Febi) | These brands are often the original manufacturers for BMW. They offer OEM quality without the dealer markup and are a trusted choice among BMW owners. |
| Standard Aftermarket (e.g., Trico) | Brands like Trico are well-known in the general auto parts industry and produce a wide range of components. While they are designed to meet OE specifications for fit and function, they are more commonly associated with domestic vehicles. For a complex job like this on a BMW, most owners prefer to use a brand with a proven track record specifically on European vehicles. |
Pro Tip: Regardless of the brand you choose, always replace the small rubber grommet/filter that the pump pushes into. These seals harden over time and are a common source of leaks. It's an inexpensive part that prevents a major headache.
Replacement Overview & Cost
Be warned: replacing the washer pump on a 2008-2013 X5 is a surprisingly difficult and labor-intensive job. The washer fluid reservoir is tucked deep behind the front passenger-side fender. Accessing the pumps requires removing the wheel, the plastic fender liner, the side skirt/running board, and loosening or completely removing the metal front fender. This is not a simple plug-and-play repair.
🎬 Watch a step-by-step walkthrough of the pump removal process.This job is considered difficult for a DIY mechanic due to the number of body panels that must be removed. A shop will typically bill for 2.5 to 3.5 hours of labor.
Estimated Costs
| Item | Cost Range |
|---|---|
| New OEM Pump | $70 - $110 |
| New Aftermarket Pump | $38.34 |
| Shop Labor | $250 - $450 |
Frequently Asked Questions (FAQ)
Where is the windshield washer pump located?
The washer pump (or pumps) are press-fit into the bottom of the washer fluid reservoir. The entire reservoir assembly is located behind the front passenger-side wheel, inside the fender.
Does one pump work for the front and rear windows?
Yes, on the E70 X5, the same pump model is typically used for the front and rear windshields. If your vehicle has headlight washers, it will use a third, different high-pressure pump. When one pump fails, it is common practice to replace both windshield pumps at the same time to save on future labor.
🎬 See how to replace both front and rear pumps together.Can I just replace the pump through the fender liner?
Unfortunately, no. While you can see the reservoir by removing the fender liner, there is not enough space to remove the pumps. You must at least loosen and pull back the side skirt and the main metal fender to gain the necessary clearance.
Are there any recalls for this part?
No, there are no active recalls or Technical Service Bulletins (TSBs) from BMW or the NHTSA for the windshield washer pump on the 2008-2013 X5. Recalls for other X5 model years or for the engine's main water (coolant) pump do exist and should not be confused with this part.
Helpful Videos
Technical Specifications
OEM Part Numbers: 67126934160 67127302589
12V, 2-Pin Mono Pump. Fits front and rear washer systems. Does not fit headlight washer system.
