Honda Accord Engine Oil Pressure Switch Guide (2008-2013)
Leaking oil or a flickering dashboard light on your 2008-2013 Honda Accord could point to a failing oil pressure switch.
- The most common failure is an oil leak from the switch itself, not an electrical problem.
- V6 engines have separate oil pressure switches for the main system and the VTEC system; diagnose codes carefully.
- Use a quality aftermarket brand like Beck Arnley or Standard Ignition to avoid premature failure.
- Do not overtighten the new switch; use a torque wrench and thread sealant to prevent leaks and engine damage.
Is Your Accord's Oil Light On? Understanding the Symptoms
A failing oil pressure switch on the 2008-2013 Honda Accord is a common issue. While an oil light can be scary, the problem is often the switch itself and not a lack of oil pressure. Knowing the signs helps you diagnose the problem correctly.
Most Common Failure: The Oil Leak
The most frequent problem with these switches isn't electrical—it's a physical leak. The seal between the plastic connector and the metal body of the switch fails, allowing oil to seep out. You may find oil on the switch, the electrical connector, and dripping down onto the oil filter or the ground. This is a very common issue on Honda vehicles.
Key Symptoms of a Bad Oil Pressure Switch:
- Oil Pressure Light: The light on your dash may flicker, stay on constantly, or come on intermittently, especially when the engine is warm and idling. This can happen even if your oil level is full.
- Visible Oil Leak: This is the number one sign. Check the area around the switch, which is located on the engine block, usually near the oil filter. If the electrical connector boot is full of oil, the switch has failed internally.
- Check Engine Light (V6 Models): A failing rocker arm oil pressure switch (for the VTEC system) can trigger a Check Engine Light with codes like P3400 or P3497, affecting engine performance.
- Incorrect Gauge Readings: If your car has an oil pressure gauge, it might read zero or fluctuate wildly.
Choosing the Right Aftermarket Part for Your Accord
When it comes to sensors, quality matters. While a Genuine Honda part is always a safe bet, several aftermarket brands offer a good balance of quality and value. Be cautious with the cheapest options, as they have a higher risk of premature failure and incorrect thread pitch.
| Brand Tier | Brands | Why Choose? |
|---|---|---|
| Premium Aftermarket | Beck Arnley, Standard Ignition (SMP) | These brands have a strong reputation for quality. Beck Arnley is known for sourcing parts from OEM suppliers, meaning you might get a genuine part in a different box. Standard Ignition designs and tests their switches for durability. These are the most reliable aftermarket choices. |
| Standard Aftermarket | Walker Products, Global Parts, True Tech | These brands offer a more budget-friendly solution. They can be a cost-effective choice for a simple repair, but the risk of an early failure or leak is slightly higher compared to premium brands or OEM. For a critical sensor like this, spending a little more for a premium brand is often worth it. |
A Note on V6 Engines
The 3.5L V6 engine in the 2008-2013 Accord has two or more oil pressure switches. One is the main switch for the dashboard light. The others are for the VTEC system (often called rocker arm oil pressure switches). If you have a V6 and a Check Engine Light with codes P3400 or P3497, you need to replace the specific VTEC switch, not the main one.
Installation & Known Issues
Replacing the switch is a feasible DIY job for many owners. On the 4-cylinder (2.4L) engine, the switch is located on the back of the engine block, often above the oil filter. It can be accessed from underneath the car. For the V6, the main switch is in a similar location, but the VTEC switches can be harder to reach.
- Required Tool: You will need a special deep socket, usually 24mm, to remove and install the switch.
- Thread Sealant: Use a small amount of liquid thread sealant on the new switch's threads to prevent leaks. Do not use Teflon tape, as bits can break off and enter oil passages.
- Torque Spec: Be very careful not to overtighten the new switch. The torque spec is low (around 13-16 ft-lbs). Overtightening can crack the engine block, leading to a catastrophic failure.
- Known Issue: No specific recalls exist for this part on the 2008-2013 Accord. However, leaking oil pressure switches are a widely known problem across many Honda models.
Frequently Asked Questions
Can I drive with a bad oil pressure switch?
It is not recommended. If the switch is faulty and causing a false warning light, you might be safe. However, if the light indicates true low oil pressure, driving can cause severe and immediate engine damage. It's best to stop the vehicle and diagnose the problem. If the switch is just leaking, it's less critical, but you should replace it soon to avoid making a mess and running the engine low on oil.
What's the difference between the main switch and the VTEC switch?
The main oil pressure switch monitors overall engine oil pressure and controls the red warning light on the dash. The VTEC oil pressure switch is part of the VTEC solenoid assembly and ensures there is enough oil pressure to activate the VTEC system. A failure in the VTEC switch will typically cause a Check Engine Light and poor engine performance, not the main oil pressure light.
Why is my new aftermarket switch leaking?
This can happen for a few reasons. The most common is using a low-quality part with improper seals or thread pitch. It's also possible the switch was overtightened, damaging the threads, or installed without thread sealant. Always use a quality brand and torque the switch to the correct specification.
How do I know if I have a 4-cylinder or V6 engine?
The easiest way is to check the emblem on the back of your car. If it has a "V6" badge, you have the V6 engine. You can also look under the hood. The 4-cylinder engine is smaller and has a simpler layout, while the V6 is larger and will have "V6" marked on the engine cover.
Helpful Videos
Technical Specifications
OEM Part Numbers: 37240-R70-A04 37240-R70-A03 37240-R70-A02 28610-R36-004 28600-R94-004
Socket Size: 24mm Deep Socket. Thread: 1/8-28 BSPT (British Standard Pipe Tapered). Torque Spec: Approx. 13-16 ft-lbs.
We Have This Part in Stock
The information in this article is provided for general reference and educational purposes only. Vehicle specifications, procedures, and part compatibility can vary by production date, trim level, and region. Always consult your vehicle's factory service manual and verify part numbers before purchasing or performing repairs. Safety-critical components such as airbags, seat belts, and braking systems should be installed by a qualified professional.
