A Guide to the Engine Coolant Thermostat for the 2008-2016 BMW Z4 (E89)
Is your Z4 running too cold or overheating? Your electronically controlled thermostat might be the culprit.
- The most common failure is 'stuck open', causing a P0128 code and a slow-to-warm-up engine.
- It is highly recommended to replace the electric water pump at the same time as the thermostat.
- For reliability, choose an OEM brand like Mahle/Behr or Wahler; avoid budget electronic parts.
- Owners of the Z4 sDrive28i should check with a dealer about a 10-year/120k-mile extended warranty on the thermostat.
Is Your BMW Z4 Thermostat Failing?
A faulty thermostat in the E89 Z4 can cause a range of issues, from annoying to potentially engine-damaging. Unlike older cars where thermostats often failed stuck closed and caused immediate overheating, the electronically controlled thermostats in these BMWs are designed to fail in the "open" position as a safety measure. This prevents catastrophic overheating but creates its own set of problems.
Key Failure Symptoms: Stuck Open vs. Stuck Closed
Most Common: Stuck-Open Failure
- Check Engine Light: The most frequent sign is a check engine light with fault code P0128, which means 🎬 Watch this guide to troubleshooting P0128 and P0126 codes. the engine coolant temperature is below its normal regulating temperature.
- Slow to Warm Up: Your engine may take much longer than usual (15-20 minutes) to reach the middle of the temperature gauge.
- Poor Fuel Economy: Because the engine isn't reaching its optimal temperature quickly, the computer keeps it in a "warm-up" mode, which uses more fuel.
- Temperature Drops While Driving: You might notice the temperature gauge fall when you're driving on the highway or when you turn the heater on full blast.
Less Common but More Serious: Stuck-Closed Failure
- Engine Overheating: The temperature gauge will quickly move into the red. This is a critical situation, and you should pull over and shut off the engine immediately to prevent severe damage.
- Radiator Fan at Max Speed: The car's main cooling fan will run constantly at its highest speed, making a loud noise.
- Warning Lights: You will see high engine temperature warnings on your dashboard.
- Steam from Hood: In severe cases, coolant may boil over, creating steam.
Known Issues & Warranty Extension
N20 Engine (sDrive28i): BMW extended the limited warranty for the engine coolant thermostat on some models with the N20 engine to 10 years or 120,000 miles. If you own an sDrive28i, contact a BMW dealer with your VIN to see if your vehicle is eligible for a free replacement.
Water Pump Recall (sDrive28i): A recall (NHTSA ID: 24V608) was issued for the 2012-2016 Z4 sDrive28i for a potential short circuit in the electric water pump connector, which poses a fire risk. While not the thermostat itself, it's a critical part of the same system.
Choosing the Right Aftermarket Thermostat
The thermostat in your Z4 is an electronic part, and for modern BMWs, using a quality component is essential. Cheap electronic parts are known to fail prematurely or not communicate correctly with the vehicle's computer.
Tier 1: OEM-Level Quality
- Mahle/Behr & Wahler: These companies are Original Equipment Manufacturers (OEMs) for BMW, meaning they make the part that goes into the car at the factory. Choosing one of these brands gives you the same quality as the genuine BMW part without the dealership price tag. They are the most recommended choice for reliability.
- Gates: Gates is a well-respected aftermarket brand known for quality cooling and belt system components. A Gates thermostat is a solid and reliable alternative to an OEM part.
Tier 2: Budget-Friendly Options
- URO Parts: URO is a budget-focused brand. While some of their simple, non-moving metal parts can be acceptable, forum users often advise against using their electronic components like thermostats and water pumps due to higher failure rates. If your budget is extremely tight, it's an option, but it carries a higher risk of premature failure compared to OEM or Gates.
Tier 3: Performance
- Mishimoto: Mishimoto specializes in performance cooling parts. They may offer thermostats that open at a lower temperature, which is typically only beneficial for heavily modified or track-driven cars. For a daily-driven Z4, sticking with the stock temperature thermostat (usually 97°C for N52/N54 engines) is best for efficiency and engine health.
Pro-Tip: Replace in Pairs
The electric water pump on the N52 and N54 engines is another known failure point. Since replacing the thermostat requires draining the coolant and accessing the same area of the engine, it is highly recommended to replace the water pump and thermostat at the same time, especially if your car has over 60,000 miles. This saves you from paying for the same labor twice 🎬 See a full walkthrough of the Z4 pump and thermostat replacement. in the near future.
Cost to Replace a 2008-2016 BMW Z4 Thermostat
The cost can vary based on your location and the parts you choose. Here is a general breakdown:
| Part/Service | Estimated Cost |
|---|---|
| Shop Labor | $298 - $438 |
| New Aftermarket Part | $65 - $242 |
| New OEM Part | $90 - $220 |
| Total Professional Replacement | $592 - $806 |
Frequently Asked Questions (FAQ)
Can I replace the Z4 thermostat myself?
Yes, this is a feasible DIY for an experienced home mechanic. However, it is a moderately difficult job that can take several hours. Access is tight, requiring the removal of underbody panels and potentially the sway bar. After replacement, the cooling system must be electronically bled using a specific procedure to remove all air pockets.
🎬 Watch how to perform the electronic coolant bleeding procedure.Do I need to replace any other parts with the thermostat?
It is strongly recommended to replace the electric water pump at the same time, as it is a common failure item and shares the same labor. You should also use new aluminum mounting bolts for the water pump, as they are single-use. Also, inspect the plastic coolant hose flange (often called the "Mickey Mouse flange") that connects to the cylinder head, as it is prone to cracking and is an inexpensive part to replace while you're there.
What kind of coolant should I use?
You must use a BMW-approved G48 blue coolant. Do not mix it with other colors or types of coolant. The system should be filled with a 50/50 mixture of coolant and distilled water.
Why is my radiator fan always on?
The engine computer (DME) will command the radiator fan to run at full speed as a failsafe measure if it detects a problem with the cooling system, such as a faulty thermostat or water pump. It's the car's way of protecting the engine from overheating when it can't properly regulate its own temperature.
Helpful Videos
Technical Specifications
OEM Part Numbers: 11537549476 11537544788 11537536655 11538635689 11538648791 11537633476
Electronically controlled thermostat with integrated housing. Opening temperature is typically 97°C (207°F) for N52/N54 engines and 108°C (226°F) for N20 engines, but is actively managed by the DME.
