Dodge Dart Neutral Safety Switch (Transmission Range Sensor) 2013-2016 Guide
If your Dart won't start or shows the wrong gear, this guide helps you diagnose and find the right replacement switch.
- First, verify your car is not affected by the open recall for the transmission shift cable bushing (NHTSA 19V-293), as symptoms are very similar.
- An intermittent no-start where the dash lights work but the engine doesn't crank is the most common symptom of a bad switch.
- You must buy the correct switch for your engine: the 1.4L Turbo has a different part than the 2.0L and 2.4L engines.
- An aftermarket switch from a brand like Standard Ignition is a reliable and cost-effective alternative to the OEM part.
Is Your Dart Refusing to Start?
One of the most common signs of a failing neutral safety switch on the 2013-2016 Dodge Dart is an intermittent no-crank condition. You turn the key or press the start button, and nothing happens. The dashboard lights up, the radio works, but the engine doesn't even try to turn over. This often happens without warning and may not occur every time you try to start the car. You might also notice the gear indicator on your dash is blank or incorrect.
IMPORTANT: Check for Recall V34 First!
Before you replace the neutral safety switch, you must be aware of a major safety recall (NHTSA ID: 19V-293, Recall V34) on all 2013-2016 Darts with automatic transmissions. This recall is for a faulty transmission shift cable bushing. When this small plastic part fails, the shifter cable detaches from the transmission. Your gear shifter in the car will move, but the transmission itself may remain in a different gear. This can prevent the car from starting or, more dangerously, allow the car to roll away if you think it's in Park. Because the symptoms are so similar to a bad neutral safety switch, it's critical to have a dealer check if this recall work has been performed on your vehicle. The repair is free of charge.
🎬 Watch: Why you should address the V34 recall immediately.Choosing the Right Aftermarket Switch
If you've ruled out the shift cable recall and confirmed the neutral safety switch is the problem, an aftermarket part is a cost-effective solution. Brands like Standard Ignition (Standard Motor Products) produce direct-fit replacement switches designed to meet original equipment specifications. These parts are widely available and offer a reliable alternative to a more expensive dealer part.
Pro Tip: The Dodge Dart used different automatic transmissions. You MUST buy the switch that matches your engine. An incorrect part will not fit or function. Check your vehicle's original documentation or the sticker in the driver's side door jamb to confirm your engine size before ordering.
- 1.4L Turbo Engine: Uses a Dual Dry Clutch Auto Transmission (DDCT) and requires a specific range sensor. The OEM part number is 68141741AA.
- 2.0L & 2.4L Engines: Use a 6-speed automatic transmission. The OEM part number is 68273120AA, which replaced 68192769AA.
| Part Type | Estimated Cost |
|---|---|
| New Aftermarket Switch | $71.84 - $247.34 |
| New OEM (Mopar) Switch | $140 - $280 |
| Shop Labor | $120 - $250 |
Frequently Asked Questions
Can I replace the Neutral Safety Switch myself?
Yes, this is a feasible DIY project for someone with basic mechanical skills. The switch is located on top of the transmission. Access is tight, requiring the removal of the battery and battery tray components to reach it. The job itself involves unplugging a connector, removing a linkage, and unbolting two 10mm bolts. For an experienced mechanic, it's a 30-minute job, but a DIYer should plan for 1-2 hours.
What's the difference between a Neutral Safety Switch and a Transmission Range Sensor?
The terms are often used interchangeably for the same part. "Neutral Safety Switch" describes its safety function of preventing starts in gear. "Transmission Range Sensor" describes its other function: telling the car's computer what gear the transmission is in. On the Dodge Dart, it's one part that does both jobs.
How can I tell if my problem is the switch or the shift cable recall?
A key sign of the shift cable bushing failure is a shifter that feels unusually light or disconnected when you move it. If the bushing has failed, you can often move the shifter without any resistance, but the gear display on the dash won't change. With a faulty neutral safety switch, the shifter will feel normal, but the car may not start, or the gear display might be erratic or blank.
My Dart won't start. Is it definitely this switch?
Not necessarily. While a faulty neutral safety switch is a common cause for a no-crank condition on the Dart, other issues like a dead battery, a bad starter, or a faulty ignition switch can cause similar symptoms. It's important to check the battery first. 🎬 Check this video to see if a bad ground is the cause. A diagnostic scan that reveals codes like P0705 is a strong indicator that the Transmission Range Sensor is the culprit.
🎬 See this step-by-step guide to replacing the range sensor.Helpful Videos
Technical Specifications
OEM Part Numbers: 68273120AA 68192769AA 68141741AA
Located on top of the transmission case. Two main versions exist: one for the 6-speed automatic (2.0L/2.4L engines) and one for the 6-speed DDCT automatic (1.4L Turbo engine).
