Honda Pilot Automatic Transmission Oil Cooler Guide (2009-2016)
Keep your Pilot's transmission safe by understanding how to spot and fix a failing oil cooler.
- For 2016 models with a 'Transmission Temp Too Hot' light, check for TSBs first; you may only need a fluid flush and software update, not a new cooler.
- A failing cooler can cause leaks, poor shifting, and ultimately, catastrophic transmission failure if ignored.
- Always use Honda Genuine ATF DW-1 fluid when refilling the system to ensure proper transmission performance and longevity.
- Aftermarket brands like Hayden offer reliable, cost-effective alternatives to the more expensive OEM part.
Is Your Transmission Overheating? Common Failure Symptoms
A failing transmission cooler can lead to expensive transmission damage. Watch for these warning signs in your Pilot.
- Transmission Overheating Warning: The most obvious sign is a 'Transmission Temp Too Hot' message on your dashboard. If you see this, you should pull over safely as soon as possible.
- Fluid Leaks: Look for puddles of reddish or dark brown fluid under the front of your vehicle. The cooler or its connecting hoses can develop leaks from age or damage.
- Poor Shifting: When transmission fluid gets too hot, it breaks down and loses its ability to lubricate properly. This can cause slipping gears, delayed or harsh shifts, and a whining noise that changes with engine speed.
- Burning Smell: A strong, acrid burning smell from under the hood can indicate that your transmission fluid is overheating and burning.
Important Issues for 2016 Honda Pilot Owners
The 2016 model year is unique as it was offered with two different automatic transmissions (6-speed and 9-speed), and each has a specific known issue.
- 6-Speed Transmission TSB: If you have a 2016 Pilot with the 6-speed automatic and see a 'Transmission Temp Too Hot' message, do not immediately assume the cooler has failed. Honda issued Technical Service Bulletin (TSB) 23-073 🎬 Watch this video to understand the 'Temp Too Hot' warning. for this exact problem. The cause is often deteriorated transmission fluid that foams up, reducing flow. The official fix is a vehicle software update and a triple flush of the automatic transmission fluid (ATF), not a cooler replacement.
- 9-Speed Transmission Warmer Warranty Extension: For 2016 Pilots with the 9-speed automatic, Honda issued a warranty extension for the transmission *warmer* (a different part that can also fail). A defect could cause engine coolant and transmission fluid to mix, leading to catastrophic engine and transmission damage. This warranty was extended to 10 years with unlimited mileage. If you have a 9-speed and suspect this issue (milky fluid in your coolant or on the dipstick), contact a dealer immediately.
Choosing the Right Aftermarket Transmission Cooler
When it's time to replace your Pilot's transmission cooler, you have several aftermarket options. These parts are generally direct-fit, meaning they are designed to install without modification. Aftermarket coolers are often much less expensive than the OEM part.
Brand Quality Tiers
- Specialist Brands (Hayden): Hayden is a well-regarded brand that specializes in vehicle cooling systems. They are known for making high-quality aftermarket coolers, sometimes with designs like stacked plates that can be more efficient than the factory tube-and-fin style. Many professional mechanics and DIYers trust this brand for its reliability.
- Standard Aftermarket (Dorman, Four Seasons): Dorman and Four Seasons are major suppliers of a wide range of aftermarket parts. They offer direct-fit replacements that meet original specifications and provide a good balance of quality and price for a standard repair.
- Economy Brands (Global Parts): These brands represent the most affordable options. While functional, they may not have the same long-term durability or brand recognition as more established names.
| Part Type | Estimated Cost |
|---|---|
| New Aftermarket Part | $51.93 - $231.57 |
| New OEM Part | $235 - $355 |
| Shop Labor | $200 - $400 |
Pro Tip: Check Your Fluid
When replacing the cooler, you will lose some transmission fluid. This is a perfect time to perform a drain and fill with fresh Honda Genuine ATF DW-1 fluid. Using the correct fluid is critical for Honda transmissions. Never use a universal or multi-vehicle fluid unless it explicitly states it is a replacement for DW-1.
🎬 Watch: How to perform a 6-speed transmission fluid drain.Frequently Asked Questions (FAQ)
My 2016 Pilot has a 'Transmission Temp Too Hot' warning. Do I need a new cooler?
Not necessarily. If you have the 6-speed automatic, this is a known issue covered by TSB 23-073. The most likely cause is old fluid, and the fix is a software update and a fluid flush, not a new cooler. Always investigate this TSB before spending money on parts.
Can I install a bigger, upgraded cooler for towing?
Yes. While the factory cooler is adequate for the rated towing capacity, installing a larger aftermarket stacked-plate cooler from a brand like Hayden is a popular upgrade for those who tow frequently or live in hot climates. It provides an extra margin of safety to protect your transmission.
🎬 See this walkthrough for installing an OEM transmission cooler kit.Is replacing the transmission cooler a DIY job?
For an experienced DIYer, yes. The job requires removing the front bumper cover and/or splash shields to access the cooler. It involves disconnecting fluid lines, so you must be prepared to catch and properly refill lost transmission fluid. If you are not comfortable with this, it is best to leave it to a professional mechanic.
What is the difference between a cooler and a warmer?
Your Pilot has both. The 'warmer' uses hot engine coolant to quickly bring the transmission fluid up to operating temperature when the car is cold. The 'cooler' is an external radiator that removes excess heat once the transmission is hot. The 2016 9-speed model had a known issue with the warmer, while the 6-speed had a TSB related to fluid overheating that required a flush, not a cooler replacement.
Helpful Videos
Technical Specifications
OEM Part Numbers: 25510-RN0-003
Fits 2009, 2010, 2011, 2012, 2013, 2014, 2015, and 2016 Honda Pilot models. Note that the 2016 model has specific TSBs and part differences depending on whether it has the 6-speed or 9-speed transmission.
