Guide to the Fuel Pump Driver Module for 2009-2017 Volkswagen CC
Stalling or no-start problems on your VW CC could point to this critical fuel system component.
- A major safety recall (VW 20AE / NHTSA 17V-509) exists for this part on 2009-2016 models; check if your car is eligible for a free repair first.
- The most dangerous symptom is a sudden engine stall while driving. Do not drive if you suspect the module is failing.
- Failure is often caused by overheating, which is why the recall repair involves relocating the new module.
- Replacement is a simple DIY job located under the rear passenger seat, requiring no special tools or programming.
Is Your VW CC's Fuel Pump Driver Module Failing?
A failing fuel pump driver module on a 2009-2017 Volkswagen CC can cause confusing and sudden problems. Because this part controls the fuel supply, its failure can mimic a bad fuel pump. The most common cause of failure is overheating, which can cause internal electronic components to burn out or create intermittent connections. 🎬 Watch: See why these electronic modules fail and overheat. This can leave you stranded without warning.
Safety Recall Notice: NHTSA 17V-509 (VW Code 20AE)
Volkswagen issued a major safety recall for the 2009-2016 VW CC due to a defect in the fuel pump control module. The original module could experience an electrical interruption, leading to a sudden engine stall while driving, which increases the risk of a crash. Other symptoms of the defect included the fuel pump running continuously and draining the battery, or a simple no-start condition. The official dealer remedy involves replacing the module with an improved part (Part No. 1K0 906 093 H or newer) and relocating it to reduce heat exposure. Before purchasing a new part, check with a VW dealer or use the NHTSA recall lookup tool with your VIN to see if your vehicle is eligible for this free repair.
Common Symptoms of Failure
- Sudden Engine Stalling: The most serious symptom is the engine cutting out while driving, often without warning.
- Engine Cranks but Won't Start: The starter will turn the engine over, but it won't fire up because the fuel pump isn't being activated.
- Hesitation or Sputtering: The car may hesitate or sputter during acceleration as the module fails to provide consistent power to the fuel pump.
- Dead Battery: In some cases, the module fails in the 'on' position, causing the fuel pump to run constantly even when the car is off, draining the battery.
- Check Engine Light: Fault codes related to low fuel pressure, such as P0087 or P025A, are common. 🎬 Watch: Diagnosing fuel pump circuit codes on a VW.
Choosing the Right Aftermarket Fuel Pump Driver Module
If your vehicle is not covered by the recall or you prefer to do the repair yourself, several aftermarket options are available. Given the history of this part, choosing a quality replacement is important.
Pro Tip: The original module that failed was often part number 1K0 906 093 with indices D, E, F, or G. The updated OEM part is 1K0 906 093 H or a newer version like 1K0 906 093 J. When buying aftermarket, look for brands that meet or exceed the specifications of the updated OEM part.
Brand Quality Tiers
- Tier 1 (OEM Supplier/Equivalent): Brands like Hella are often original equipment suppliers to Volkswagen. Choosing a part from them is the closest you can get to dealer quality without the dealer price tag. These are highly recommended for reliability.
- Tier 2 (Reputable Aftermarket): Standard Ignition (SMP) is a well-known brand that produces reliable replacement parts that meet or exceed OEM specs. They are a solid choice for a balance of quality and cost.
- Tier 3 (Value-Oriented): Brands like Dorman, VNE, and other 'Replacement' private labels offer a budget-friendly solution. Dorman sometimes redesigns parts to fix original flaws, but quality can be inconsistent according to some user reviews. These are viable if the budget is the primary concern, but may not have the same longevity as Tier 1 or 2 brands.
| Part Type | Price Range |
|---|---|
| New OEM (Dealer) | $205 - $310 |
| New Aftermarket | $128 - $256 |
| Shop Labor | $75 - $150 |
Installation Tips
Replacing the fuel pump driver module on the VW CC is a straightforward job that most DIYers can handle. The module is located under the rear passenger-side seat.
- Access the Module: The bottom of the rear seat bench needs to be popped up and removed. No tools are typically required for this; it's held by clips.
- Locate the Cover: Under the seat, you'll find a black, circular cover for the fuel pump assembly. The driver module is usually mounted on or near this cover.
- Disconnect and Replace: Unplug the electrical connector from the module. Remove the old module from its bracket and install the new one. Reconnect the electrical plug. 🎬 See this step-by-step module removal and installation guide.
- Test: Before re-installing the seat, turn the key to the 'on' position to ensure the fuel pump primes, and then start the car to verify the repair.
Frequently Asked Questions (FAQ)
Where is the fuel pump driver module located on a 2009-2017 VW CC?
It is located under the rear seat on the passenger side, typically mounted on or near the fuel pump access cover.
Is this the same as a fuel pump relay?
No. A simple relay is just an on/off switch. This is a driver module, which is a small computer that varies the voltage to the fuel pump to control its speed.
Can I drive with a bad fuel pump driver module?
It is not recommended. The module can fail completely without warning, causing the engine to stall, which is a major safety risk, especially at high speeds.
Do I need to program a new fuel pump driver module?
For this specific part on the VW CC, programming is generally not required. The replacement should be a plug-and-play installation.
Helpful Videos
Technical Specifications
OEM Part Numbers: 1K0906093G 1K0906093F 1K0906093H 1K0906093J
Controls voltage and speed for the in-tank low-pressure fuel pump. Located under the rear passenger seat. Failure is commonly caused by overheating.
