Ford Taurus Windshield Washer Pump: A Guide for the 2009-2019 Generation
If your washer fluid isn't spraying, the fix is often easier and cheaper than you think.
- The washer pump on the 2009-2019 Taurus is a common failure item, but it is very easy and cheap to replace yourself.
- Access the pump by removing a few screws in the front passenger-side wheel well liner.
- A silent pump means it has failed; a running pump with no spray means you have a clog.
- An aftermarket pump from a brand like Trico is a cost-effective and reliable alternative to the OEM part.
Is Your Windshield Washer Pump Failing?
When a washer pump on the 2009-2019 Ford Taurus fails, the symptoms are usually straightforward. The most common sign is that no fluid sprays onto the windshield when you activate the system. Before you assume the pump is bad, make sure your reservoir is full of fluid.
If the tank is full, listen closely when you try to use the washers. Do you hear a faint humming sound from the front passenger side of the car?
- If you hear the pump motor running but no fluid comes out, the problem could be a clog. The small filter on the pump can get blocked with slime or debris from the tank, or your washer nozzles could be clogged. 🎬 See how to fix a clogged pump without buying new parts.
- If you hear nothing at all, the pump motor has likely failed or isn't receiving power. On these Taurus models, the washer pump does not have its own separate fuse; it's integrated into the same circuit as the wiper motor. So, if your wipers work, a blown fuse is not the issue. 🎬 Watch this video to troubleshoot pump power and fuse issues.
Choosing a New Aftermarket Pump
For a simple part like a washer pump, an aftermarket replacement is a smart choice for most owners. The original Ford (Motorcraft) pump works well, but you can get a quality aftermarket pump for significantly less money. Brands like Trico have been making wiper-related parts for decades and offer reliable, direct-fit replacements. An aftermarket pump from a reputable brand will restore function just like the original, and installation is identical.
Cost of Replacing a Ford Taurus Washer Pump
| Part Type | Part Cost | Labor Cost (Shop) | Total Cost (Shop) |
|---|---|---|---|
| New OEM (Motorcraft) | $50 - $70 | $98 - $143 | $148 - $213 |
| New Aftermarket (Trico) | $42.96 | $141 - $186 | |
| DIY Replacement | $42.96 | $0 | $42.96 |
Pro Tip: Clean Your Reservoir
When you replace the pump, it's the perfect time to clean the washer fluid tank. Over time, using different types of washer fluid can cause a gel-like substance to form, which clogs the new pump's filter screen. Siphon out any old fluid, remove the tank if you can, and rinse it thoroughly with water before installing the new pump.
Frequently Asked Questions (FAQ)
Is it hard to replace the washer pump on a 2009-2019 Taurus?
No, it is a very easy job that most people can do in under 30 minutes. You need to turn the passenger-side front wheel inward, remove three small screws from the wheel well liner, and peel it back to access the pump. It simply pulls out of the reservoir.
🎬 Watch this step-by-step guide to replacing your Taurus washer pump.What tools are needed for the replacement?
You only need a ratchet with a 7/32" or 5.5mm socket and possibly a small flathead screwdriver to help release the electrical clip.
Are there any recalls for the washer pump on this Taurus?
No, there are no specific recalls or widespread technical service bulletins (TSBs) for windshield washer pump failure on the 2009-2019 Ford Taurus. Failures are typically due to age or clogging.
My pump runs, but the spray is weak. What's wrong?
This is usually caused by a blockage. Start by using a small pin to clean the openings on the washer nozzles on your hood. If that doesn't work, the filter on the pump itself is likely clogged with debris from the washer tank. Replacing the pump (which includes a new filter) will solve this.
Does the same pump fit all 2009-2019 Taurus models?
Yes, the same windshield washer pump is used for all Ford Taurus models from 2008 through the end of production in 2019.
Helpful Videos
Technical Specifications
OEM Part Numbers: 8G1Z-17664-A
The windshield washer pump for the 2009-2019 Ford Taurus is a small, 12V electric motor that press-fits into a rubber grommet at the base of the washer fluid reservoir. It has one electrical connector and one outlet port for the fluid hose. The same part fits all models within this year range.
