Chrysler Town & Country Engine Cooling Fan Module Guide (2010-2016)
Keep your 2010-2016 Town & Country from overheating by understanding and diagnosing a faulty engine cooling fan module.
- A failing fan module can cause overheating at idle, poor A/C performance, or a dead battery.
- Symptoms often include a P0480 trouble code and a fan that either won't run or won't shut off.
- Replacing just the aftermarket module is far more cost-effective than buying a full OEM fan assembly.
- Always check fuses (J19/J12) and the fan relay before replacing the entire module.
Is Your Van's Cooling Fan Acting Up?
If you own a 2010-2016 Chrysler Town & Country, you have a reliable minivan. However, a failing engine cooling fan module can cause serious problems. This part controls the fan that keeps your 3.6L Pentastar engine from overheating. When the module fails, it can leave you stranded. Common signs of failure include the fan not turning on at all, or the fan running constantly even after you've turned the van off, which can drain your battery.
Symptoms of a Failing Fan Module
A bad fan module can cause several issues. Recognizing them early can save you from a much bigger repair bill. 🎬 Watch this guide on common radiator fan failure symptoms. Here’s what to look for:
- Engine Overheating at Idle: The most common symptom is the temperature gauge climbing when you're stopped in traffic, but returning to normal when you start moving at higher speeds.
- A/C Blows Warm Air: The cooling fan also helps cool the A/C condenser. If the fan isn't working, your air conditioning will struggle to blow cold air, especially when the vehicle is not moving.
- Fan Stays On: The module can fail in the "on" position, causing the fan to run continuously and drain the battery.
- Fan Won't Turn On: You can do a simple visual check. With the engine running, turn the A/C to max. The fan should kick on. If it doesn't, the module could be the culprit.
- Check Engine Light: A failure in the cooling fan circuit can trigger a Check Engine Light. A common code associated with this issue is P0480 (Cooling Fan 1 Control Circuit Malfunction).
Known Issues & Recalls
While there are no specific recalls for the cooling fan module on the 2010-2016 Town & Country, Chrysler has issued recalls for similar issues on other vehicles like the Ram ProMaster. These recalls often relate to electrical circuits overheating or fan seizure. Forum discussions among owners show that fan module and relay failure are known issues for these minivans.
Choosing a New Aftermarket Part
When it's time for a replacement, you have a choice between OEM (Original Equipment Manufacturer) and aftermarket parts. For the Town & Country, the OEM module is part of the entire fan assembly, making it a very expensive repair from the dealer.
Aftermarket brands like Gates offer the module as a separate, standalone part. This makes the repair much more affordable. Gates is a well-known manufacturer that produces OE-quality parts for the aftermarket. Their modules are designed to be a direct plug-and-play replacement, often incorporating improvements to address common failure points. Choosing a quality aftermarket module like Gates provides a reliable repair without the high cost of a full OEM fan assembly.
Pro Tip: Check the Simple Stuff First
Before replacing the module, check the fuses and relays. A blown fuse (check fuse J19, a 60A fuse, and J12, a 30A fuse) or a bad relay can mimic the symptoms of a failed module and is a much cheaper fix. 🎬 See exactly where to find your fan fuses and relays. The fan relay is located under the headlight assembly on the driver's side.
| Part Type | Cost Range |
|---|---|
| New OEM (Full Assembly) | $350 - $500+ |
| New Aftermarket (Module Only) | $75 - $100 |
| Shop Labor | $100 - $200 |
Frequently Asked Questions (FAQ)
Can I replace the cooling fan module myself?
Yes, this is a DIY-friendly job for many owners. The module is typically located on the fan shroud. Access may require removing the upper radiator hose and coolant overflow tank. The module itself is usually held on by a few screws and has a single electrical connector. The entire job can often be completed in about an hour.
🎬 Follow this step-by-step video to replace your fan resistor.What is the difference between the fan module and the fan relay?
On these vans, the terms are often used interchangeably, but they can be distinct parts. The main control module, often called the fan relay, is a solid-state unit with a heat sink located between the radiator and the grille. It controls the variable speed of the fan. There are also simpler relays in the main fuse box that control low and high-speed fan operation. It's important to correctly diagnose which part has failed.
Will a bad fan module always cause the van to overheat?
Not always. If the module fails in the "on" position, the fan will run constantly, preventing overheating but draining the battery. If it fails where only the high-speed setting works, you may only notice overheating in slow traffic. However, any failure in this system should be addressed immediately to prevent potential engine damage.
What tools do I need to replace the module?
You will likely need a basic socket set, a Phillips head screwdriver, and possibly pliers for hose clamps. No special tools are typically required. Having a catch pan for any spilled coolant is also a good idea.
Helpful Videos
Technical Specifications
OEM Part Numbers: 5058674AD
The cooling fan module for the 2010-2016 Chrysler Town & Country is a solid-state, pulse-width modulated (PWM) relay that controls the variable speed of the engine's electric cooling fan.
