Chevrolet Cruze Windshield Washer Pump Replacement Guide (2010-2019)
If your washer fluid isn't spraying, this guide will help you diagnose and replace the pump on your 2010-2019 Cruze.
- A failed washer pump is a common issue, but always check for a blown fuse (F56) first.
- The replacement is a simple DIY job, accessible by removing the front passenger wheel and fender liner.
- Quality aftermarket brands like Trico offer a cost-effective alternative to more expensive OEM parts.
- Do not use water in the reservoir, as freezing can damage the pump and is not covered by warranty.
Is Your Cruze's Washer Pump Failing?
A non-working windshield washer system can be a safety hazard. Before you assume the pump is bad, make sure your washer fluid reservoir is full. If it is, here are the common symptoms of a failed pump.
Diagnosing the Problem
- No Sound, No Spray: If you pull the washer lever and hear absolutely nothing, the pump is likely not getting power or has failed completely. The first and easiest thing to check is the fuse. For the Cruze, this is often fuse F56 in the under-hood fuse box. 🎬 Check out this guide for locating and replacing the wiper fuse.
- Pump Hums, But No Spray: If you can hear the pump motor whirring but no fluid comes out, the pump itself is working electrically. The problem could be a clog in the system (at the pump's filter, in the lines, or at the nozzles), or the pump's internal impeller is broken and not moving fluid.
- Weak or Uneven Spray: This can be a sign of a dying pump that is losing pressure. It can also be caused by partially clogged nozzles or a leak in the washer fluid lines.
A Note on Freezing Temperatures
Using water or a non-winterized washer fluid can cause the liquid to freeze in the reservoir and lines. Attempting to use the washers when the system is frozen can overload and burn out the pump motor or blow the fuse. This type of damage is typically not covered by warranty.
Choosing the Right Aftermarket Pump
For a part like the windshield washer pump, you don't always need to buy the expensive OEM (Original Equipment Manufacturer) part from the dealership. A quality aftermarket pump can provide the same performance and reliability for less money. Brands like Trico are well-established in the wiper and washer system industry and design their pumps for easy, direct-fit installation.
When shopping for an aftermarket pump, you'll find they are designed to match the original's specifications, including the electrical connector and hose ports, ensuring a straightforward replacement.
Replacement Cost for a 2010-2019 Chevrolet Cruze
The cost to replace a windshield washer pump can vary based on who does the work and the type of part used. The job is simple enough for many DIYers, which can save significant labor costs.
| Part/Service | Estimated Cost |
|---|---|
| New Aftermarket Pump | $37 - $58 |
| New OEM Pump | $44 - $84 |
| Shop Labor | $58 - $95 |
| Total (Professional Repair) | $131 - $168 |
Installation Overview
Replacing the washer pump on a Cruze is a common DIY task. The basic steps involve safely jacking up the front passenger side of the vehicle, removing the wheel, and pulling back the plastic wheelhouse liner to access the washer fluid reservoir. The pump is press-fit into a rubber grommet on the reservoir. You simply disconnect the electrical plug and fluid hose, pry the old pump out, and press the new one in.
🎬 See a step-by-step demonstration of how to replace the pump.Frequently Asked Questions
Where is the windshield washer pump on a 2010-2019 Chevy Cruze?
The pump is located on the windshield washer fluid reservoir. You can access it by removing the front passenger-side wheel and pulling back the fender liner. The pump is pushed into the bottom of the reservoir.
Is it hard to replace a Cruze washer pump myself?
No, it is considered an easy repair for a DIYer with basic tools. The process takes less than an hour and mainly involves removing the wheel and fender liner for access. The most important part is to work safely with the vehicle on jack stands.
My washer pump is not working. Should I check the fuse first?
Yes, always check the fuse before replacing the pump. A blown fuse is a common and inexpensive fix. On the Cruze, the washer pump fuse is typically F56 🎬 Watch this video to find the exact washer pump fuse location., located in the fuse box in the engine bay.
Are there any recalls for the Chevrolet Cruze windshield washer pump?
No, there are no specific recalls or widespread technical service bulletins (TSBs) for the windshield washer pump on the 2010-2019 Chevrolet Cruze. Failures are typically due to normal wear and tear or environmental factors like freezing.
Helpful Videos
Technical Specifications
OEM Part Numbers: 84139203 13508971 84993622 13349273
The pump is a small, 12V DC electric motor that press-fits into a rubber grommet on the washer fluid reservoir. It typically has one electrical connector and one or two hose ports.
