Dodge Dart Windshield Washer Pump Guide for 2013-2016 Models
Everything a 2013-2016 Dodge Dart owner needs to know before replacing their windshield washer pump.
- A faulty washer pump on a 2016 Dodge Dart can cause the windshield wipers to fail completely due to a voltage spike, which was subject to a safety recall.
- Replacement is a simple DIY job, accessible by removing the driver's side front wheel and fender liner.
- If you hear the pump motor but no fluid sprays, check for clogged lines before assuming the pump is bad.
- Given the known issues with the original part, a quality aftermarket pump is a reliable and recommended choice.
Understanding the Dodge Dart Windshield Washer Pump
If you can't spray washer fluid, the windshield washer pump is a likely suspect. On the 2013-2016 Dodge Dart, this part is located on the washer fluid reservoir. You can access it by removing the front driver's side wheel and the plastic fender liner. While a simple part, it has a very important history on this specific vehicle.
Critical Recall Information for 2016 Dodge Dart Owners
There is a significant safety recall (NHTSA Campaign ID: 16V813000) for 2016 Dodge Dart models built between April 13, 2015, and June 7, 2016. The original factory windshield washer pump could create a voltage spike when used. This spike can overload and destroy the Body Control Module (BCM), which in turn causes the windshield wipers to stop working completely. If your Dart falls in this range, a dealer was required to replace the washer pump free of charge. Even if your vehicle is outside the recall dates, be aware that if your wipers fail immediately after you try to use the washer fluid, this known issue is the likely cause.
Symptoms of a Failing Windshield Washer Pump
Diagnosing a bad washer pump is usually straightforward. Look for these common signs:
- No Sound, No Fluid: You push the button and hear nothing. This usually means the pump's motor has failed or is not receiving power. First, check the fuse before replacing the pump. 🎬 Watch: How to find and replace the washer pump fuse
- Pump Hums, But No Fluid Sprays: If you can hear the pump motor running but nothing comes out, the issue could be a clog in the lines or nozzles, or the pump's internal impeller has failed. Disconnect the hose from the pump to see if it sprays there. If it does, the problem is downstream; if not, the pump is bad. 🎬 See this guide to diagnosing pump, line, and nozzle issues
- Wipers Stop Working After Use: This is the critical symptom for Dodge Dart owners. If using the washer fluid causes your wipers to fail, the pump has likely created a voltage spike and damaged the BCM.
Choosing the Right Aftermarket Pump: OEM vs. Aftermarket
For many parts, the debate between OEM and aftermarket is about price versus quality. For the Dodge Dart washer pump, the decision is simpler. Given the history of the original OEM part causing major electrical issues, a quality aftermarket part is a very safe and reliable choice. Aftermarket brands like Trico design their pumps to meet or exceed original equipment specifications, often without the original design flaws.
Since the replacement requires some labor, choosing a reliable aftermarket part like one from Trico can provide peace of mind and prevent you from having to do the job twice.
Replacement Cost
The cost to replace a windshield washer pump on a 2013-2016 Dodge Dart is relatively low. The part itself is inexpensive, and if you perform the labor yourself, the savings are significant. If you take it to a shop, expect to pay for about an hour of labor.
| Part or Service | Estimated Cost |
|---|---|
| New OEM Part | $26 - $75 |
| New Aftermarket Part (Trico) | $37.72 |
| Shop Labor | $61 - $90 |
| Total Professional Replacement | $118 - $160 |
Frequently Asked Questions (FAQ)
Is it difficult to replace the washer pump on a Dodge Dart myself?
No, it is not considered a difficult job and is very feasible for a DIYer. The process involves safely jacking up the car, removing the driver's side front wheel, and removing some clips and screws to pull back the fender liner. The pump then pulls out of the reservoir. The entire job can typically be done in under an hour.
My wipers stopped working. Is it related to the washer pump?
It is very possible, especially on a 2016 model. The factory washer pump was known to short out the Body Control Module (BCM), disabling the wipers. If your wipers failed right after you tried to wash the windshield, this is the most likely cause.
🎬 Watch: What to do if your wipers are stuckHow do I know if it's the pump or just a clogged line?
Listen for the pump motor. If you can hear it humming when you press the washer button, it's getting power. The next step is to disconnect the fluid hose directly at the pump. Activate the washer and see if fluid comes out of the pump itself. If it does, your pump is good and the clog is in the hoses or nozzles. If no fluid comes out, the pump is the problem.
Do I need to drain the washer fluid before replacing the pump?
Yes, you should have a bucket ready. The pump is located at the bottom of the reservoir, and when you pull it out, all the fluid will drain out. It's best to either run the pump until the reservoir is empty (if it works) or be prepared to catch the fluid when you remove the old pump.
Helpful Videos
Technical Specifications
OEM Part Numbers: 68171073AA 68428899AA 68095361AA
