A Guide to the Engine Intake Manifold Gasket Set for 2011-2018 Ford Mustangs
Everything a Mustang owner needs to know about replacing a leaky or failed intake manifold gasket.
- A failing intake manifold gasket on a 2011-2018 Mustang will typically cause vacuum leaks, leading to a rough idle, misfires, and lean condition error codes (P0171, P0174).
- Coolant leaks are also a common symptom and can lead to engine overheating if not addressed.
- Always buy the correct gasket set for your specific engine (3.7L V6 or 5.0L V8), as they are different.
- Top aftermarket brands like Fel-Pro and Victor Reinz offer excellent quality for stock replacements, while Cometic is a great choice for high-performance applications.
Is Your Mustang's Intake Gasket Failing?
The intake manifold gaskets on the 2011-2018 Ford Mustang, whether it's a 3.7L V6 or a 5.0L Coyote V8, are durable but don't last forever. Made from materials like molded rubber, they are constantly exposed to heat and pressure. Over many miles and heat cycles, these gaskets can become hard, brittle, and crack. This leads to leaks that can cause a range of engine problems, from annoying to serious.
Watch for Manifold Runner Control Issues
For some later model GTs (2015+), a common issue is not the gasket itself but the Intake Manifold Runner Control (IMRC) system failing. This can cause a broken shaft inside the manifold, leading to misfires and codes like P0308. While this is a separate issue from the gasket sealing surface, it occurs in the same component and can cause similar symptoms. The fix is often a full intake manifold replacement.
Choosing the Right Aftermarket Gasket Set
When it's time for a replacement, you have several good aftermarket options. The original Ford gaskets are high quality, but aftermarket brands often provide comparable or even improved designs at a better price. It is crucial to buy the correct gasket set for your specific engine (3.7L V6, 5.0L V8, etc.) as they are not interchangeable.
Brand Quality Tiers
- Premium Aftermarket (Fel-Pro, Cometic): Fel-Pro is a top name in the aftermarket and is widely trusted by mechanics. They are known for high-quality, molded rubber gaskets that often meet or exceed OEM specifications. Cometic is another premium brand, often favored in the performance and racing communities for their robust materials like multi-layer steel (MLS). For a modified or high-performance Mustang, a Cometic gasket is a strong choice.
- OEM-Quality (Victor Reinz): Victor Reinz is a well-respected brand that is often an original equipment supplier to car manufacturers. Their gaskets are known to be reliable, pliable, and a solid choice for a stock replacement, offering a balance of quality and cost.
- Standard/Value: Many other brands offer gasket sets at a lower price point. While budget-friendly, they may use materials that are less durable than the premium options. For a daily driver, they can be sufficient, but for a performance vehicle like a Mustang, investing in a higher-tier brand is often recommended for long-term reliability.
Pro Tip: While the intake manifold is off, it's a great time to clean the intake ports and inspect for other potential issues. Consider replacing other accessible parts like the thermostat or PCV valve at the same time to save on future labor.
Known Issues, Recalls, and TSBs
Searches of the NHTSA database did not show any specific recalls for the intake manifold gaskets on the 2011-2018 Ford Mustang. Most issues are related to normal wear and tear. However, there are recalls for other components on these vehicles, so it's always wise for owners to check their VIN on the NHTSA website for any open safety campaigns.
Aftermarket Intake Manifold Gasket Set Cost
| Part | Price Range |
|---|---|
| New Aftermarket Gasket Set | $22.37 - $91.53 |
| Shop Labor | $183 - $269 |
Frequently Asked Questions (FAQ)
Do I need to use sealant with the new gaskets?
Generally, no. Modern gaskets for the Mustang, like those from Fel-Pro, are designed to be installed dry. They are molded to fit perfectly and create a seal on their own. Adding RTV sealant can actually interfere with the seal and cause a leak. Always follow the specific instructions included with your new gasket set.
Is this a good DIY job for a beginner?
Replacing the intake manifold gasket is considered an intermediate to advanced DIY job. It requires removing several components like the air intake, fuel rails, and various sensors and hoses. While manageable for someone with mechanical experience, it requires careful labeling of parts, attention to detail, and a torque wrench to tighten the bolts in the correct sequence.
What's the difference between upper and lower intake gaskets?
For the 2011-2018 Mustang V6 and V8 engines, the primary seal is made by the lower intake manifold gaskets, which are a set of individual gaskets (usually 6 for the V6 and 8 for the V8) that seal each intake port to the cylinder head. Some older or different engine designs have a two-piece intake manifold with an "upper" and "lower" section, each requiring a gasket, but for this generation of Mustang, you are typically replacing the set that seals the manifold to the engine block.
Can I reuse my old intake manifold bolts?
Yes, in most cases, the original intake manifold bolts can be reused. They are not torque-to-yield bolts. However, it is critical to clean them and to tighten them to the manufacturer's specified torque in the correct sequence to ensure the manifold is seated evenly and the gaskets seal properly.
Helpful Videos
Technical Specifications
OEM Part Numbers: CR3Z-9424-A GR3Z-9448-D
The set for a V8 engine typically includes 8 individual molded rubber gaskets. The set for a V6 includes 6 gaskets. These are designed to be installed dry without any additional sealant.
