Ford Fiesta Ignition Switch Guide for 2011-2019 Models
If your Fiesta has power but won't crank, the ignition switch is a likely and simple-to-fix problem.
- The most common symptom is power to the dash but no crank, which usually points to the electrical switch, not the mechanical lock cylinder.
- This is a simple, low-cost repair that most owners can do themselves in under an hour with basic tools.
- Always verify if the replacement switch is for a manual or automatic transmission, as they can be different.
- For best results, choose an OEM Motorcraft or a premium aftermarket brand like Standard Ignition to ensure reliability.
Is Your Fiesta's Ignition Switch Failing?
A common issue for the 2011-2019 Ford Fiesta is turning the key and getting nothing. The dashboard lights and radio come on, but the engine doesn't crank. This often points directly to a failure in the small, electrical ignition switch, not the more complex and expensive lock cylinder assembly. Over time, the electrical contacts inside the switch wear out, preventing it from sending the 'start' signal to the starter.
🎬 Watch this diagnostic guide to confirm your no-crank issue.Top Symptoms of a Bad Fiesta Ignition Switch
- Car Won't Crank or Start: You turn the key to the start position, and nothing happens. You won't hear a click from the starter motor.
- Intermittent Starting: The car may start fine one day but refuse to start the next, with no clear pattern.
- Starts and Immediately Stalls: The engine might fire up for a second while the key is held in the 'start' position but dies as soon as you let go.
- Engine Stalls While Driving: In more severe cases, a faulty switch can lose connection over a bump, causing the engine to shut off unexpectedly.
Switch vs. Lock Cylinder: Know the Difference
Many owners confuse the Ignition Lock Cylinder (the mechanical part your key goes into) with the Ignition Switch (the electronic part behind it). On the Fiesta, the switch is a separate, affordable part that clips onto the back of the lock cylinder housing. If your key turns smoothly but the car won't start, the switch is the most likely culprit.
🎬 Watch a demonstration of this common ignition switch fault.Choosing the Right Aftermarket Ignition Switch
When shopping for a replacement, you have a few quality tiers to consider. For a critical part like this, choosing a reliable brand can save you future headaches.
Brand Quality Tiers
- OEM (Motorcraft): Ford's own parts brand, Motorcraft, is the safest bet for a perfect fit and long-term reliability. It's the benchmark for quality and is often recommended by mechanics for Ford vehicles to avoid compatibility issues.
- Premium Aftermarket (Standard Ignition): Brands like Standard Motor Products (SMP) are well-respected in the industry. They manufacture parts that meet or exceed OEM specifications and perform extensive testing. This is a solid choice if you want OEM-like quality without the dealer price tag.
- Budget Aftermarket (Replacement, True Tech): These are generic or private-label brands that offer the lowest price. While they can be a good value, quality can be inconsistent. They may not last as long as OEM or premium aftermarket options.
Pro Tip: Before ordering, confirm if the part is for a manual or automatic transmission. Some ignition switches are specific to one or the other.
Ignition Switch Replacement Costs for Ford Fiesta (2011-2019)
| Part Type | Estimated Cost |
|---|---|
| New OEM (Motorcraft) | $40 - $90 |
| New Aftermarket | $25 - $86 |
| Shop Labor | $61 - $90 |
| Total Professional Replacement | $129 - $157 |
Frequently Asked Questions
Can I replace the ignition switch myself?
Yes, this is a very DIY-friendly job. The process involves removing the plastic covers around the steering column (usually with a few Torx screws), unplugging the wiring harness, and releasing two clips to remove the old switch. It typically takes less than an hour with basic tools.
🎬 See this step-by-step walkthrough of the ignition switch replacement.Do I need to reprogram my key after replacing the switch?
No. Because you are only replacing the rear electrical switch and not the lock cylinder or immobilizer module, no key reprogramming is necessary. Your original keys will work exactly as they did before.
Could something else cause a no-start problem?
Yes. While the ignition switch is a common culprit, other issues can cause similar symptoms. These include a weak battery, a bad starter motor, a blown fuse, or poor battery ground connections. On automatic models, a faulty Transmission Control Module (TCM) can also prevent the car from starting.
Are there any recalls for the Fiesta ignition switch?
No, there are no active recalls or Technical Service Bulletins (TSBs) from the NHTSA specifically for the ignition switch on the 2011-2019 Ford Fiesta. Recalls you may find for these model years are typically for door latches.
Helpful Videos
Technical Specifications
OEM Part Numbers: AA6Z-11572-B BE8Z-11572-B AA6Z-11572-A BE8Z-11572-A BE8Z-11572-C
The ignition switch is the electrical component that mounts to the rear of the ignition lock housing. It typically has a single rectangular connector with 7 pins.
