Ram 1500 HVAC Blower Motor Replacement Guide (2011-2019)
Getting your Ram's cabin airflow back to normal starts with understanding the blower motor.
- A noisy blower motor is the most common failure; check for debris in the fan cage before replacing the part.
- Replacement is very DIY-friendly, located under the passenger dash and requiring only basic tools and about 20-30 minutes.
- If your original motor is old or has failed, it's smart to replace the blower motor resistor at the same time to prevent future issues.
- Aftermarket quality varies, with some brands being prone to noise; OEM is quieter but significantly more expensive.
Is Your Ram's Blower Motor Failing?
When the blower motor in a 2011-2019 Ram 1500 starts to fail, the signs are usually hard to ignore. Because this part is located directly under the passenger-side dashboard, you'll often hear it before you notice a lack of airflow.
- Grinding, Whining, or Ticking Noises: This is the most common symptom. Debris like leaves can get into the fan cage, or the motor's internal bearings may be wearing out. The noise will usually change or get louder as you increase the fan speed.
- No Air From Vents: If the fan doesn't turn on at any speed, the motor may have burned out completely. You might hear the blend doors moving inside the dash when you change settings, but no air will come out. 🎬 Watch this video to troubleshoot and replace your blower motor.
- Fan Only Works on High Speed: This usually points to a failed blower motor resistor, but it's a closely related issue. An aging blower motor can draw too much electrical current, causing the new resistor to burn out quickly. If you've replaced the resistor and it failed again, the motor is the likely culprit.
- Burning Smell: A strong plastic or electrical burning smell from the vents when the fan is on is a serious sign. This indicates the motor or its wiring is overheating and should be addressed immediately.
Known Issues & Technical Service Bulletins (TSB)
While there are no direct safety recalls for the HVAC blower motor on the 2011-2019 Ram 1500, some official service information exists. TSB 24-001-22 was issued for some 2019 models (along with later years) where the blower motor could shut down when set to high speed while a snow plow is operating. This points to high electrical load issues that can affect the motor's performance. Owners have also frequently reported issues with the related blower motor resistor failing, which can be caused by a worn-out motor.
Choosing the Right Aftermarket Blower Motor
When your blower motor fails, you have a choice between an original equipment (OEM) part from the dealer and an aftermarket part. For a straightforward part like this, aftermarket can be a good value, but quality varies.
OEM vs. Aftermarket Quality:
The original Mopar blower motor is proven to last for many years, but it comes at a premium price. Aftermarket motors are much more affordable. However, forum discussions with Ram owners show a pattern: some cheaper aftermarket units can be unbalanced, leading to vibration or a whining noise right out of the box. The general feeling is that if you want to fix it once and forget about it, OEM is the safest bet. Given how easy this job is, some owners don't mind taking a chance on an aftermarket part to save money.
Brand Tiers:
- Four Seasons: This is a widely available aftermarket brand. However, recent owner feedback is often negative, with many complaints about noise and premature failure. It's generally considered a budget-friendly but potentially lower-quality option.
- Global Parts (GPD): There is less feedback on this brand, but it is often categorized as a standard-tier aftermarket part. Some sources suggest its quality can be inconsistent, making it a bit of a gamble.
Pro Tip: Replace the Resistor at the Same Time
The blower motor resistor controls the fan's speed. A failing motor draws more power, which can overheat and destroy the resistor. If you are replacing a high-mileage blower motor, it is wise to replace the resistor at the same time to prevent a premature failure of the new part.
Pro Tip: Consider a Cabin Air Filter
Most 2011-2019 Ram 1500 trucks did not come with a cabin air filter from the factory, even though the slot for one exists behind the glove box. A common cause of blower motor noise is debris hitting the fan blades. You can buy a cabin filter door and filter to prevent this from happening in the future.
🎬 See how to easily add a cabin air filter yourself.Cost of Replacing a Ram 1500 Blower Motor
This is a repair you can easily do yourself to save on labor costs. The part is located under the passenger side dash and held in by just a few screws.
| Part/Service | Estimated Cost |
|---|---|
| New OEM Part | $275 - $300 |
| New Aftermarket Part | $68 - $248 |
| Shop Labor | $65 - $95 |
| Total Professional Replacement | $340 - $370 |
Frequently Asked Questions
Is it hard to replace the blower motor on a 2011-2019 Ram 1500?
No, it is considered a very easy DIY job. The motor is located under the passenger side dashboard and is typically held in by three screws and one electrical connector. The entire job can often be completed in under 30 minutes with basic tools.
🎬 Follow this quick 4th Gen Ram blower motor replacement guide.Why does my new aftermarket blower motor make a whining noise?
This is a common complaint with some lower-cost aftermarket blower motors. The noise can be due to less precise balancing of the fan cage or lower quality motor bearings compared to the OEM unit. Sometimes the noise may quiet down after a brief break-in period, but often it is a sign of the part's quality level.
Do I need to replace the blower motor resistor too?
If your fan only works on the 'high' setting, the resistor is almost certainly bad. If you are replacing the blower motor because it's old or has failed, it is highly recommended to replace the resistor as well. A worn motor pulling excess current is the number one killer of blower motor resistors.
What's that clicking noise from my vents?
Before you replace the motor, check for debris. Leaves, paper, or other small items can fall into the vents and get caught in the blower's fan cage, causing a ticking or clicking sound. Removing the motor and cleaning out the housing is a free first step.
Helpful Videos
Technical Specifications
Located under the passenger side dashboard. Typically secured with three screws (8mm, T25 Torx, or Phillips head) and a 2-pin electrical connector.
