A Guide to Disc Brake Hardware for the 2011-2019 Volvo S60
Solve common brake noise and ensure proper pad movement by replacing your S60's brake hardware.
- Always replace your disc brake hardware kit when you replace your brake pads to prevent noise and uneven wear.
- Your S60 may have an Electronic Parking Brake (EPB), which requires a special scan tool for rear brake service.
- Brake vibration is a common S60 issue; using quality aftermarket hardware and rotors can provide a better result than some OEM parts.
- Look for hardware kits from reputable brands like Centric or Raybestos for reliable, OEM-quality performance.
Is It Time for a New Disc Brake Hardware Kit?
On the 2011-2019 Volvo S60, the brake hardware is exposed to intense heat, moisture, and road salt. Over time, these components corrode and lose their spring tension. Reusing old hardware during a brake job is a common mistake that can lead to problems right away. If you're replacing your brake pads or rotors, you should always install a new hardware kit at the same time. It's a small cost that prevents bigger headaches.
Symptoms of Failing Brake Hardware
Bad or worn brake hardware can cause a range of annoying and potentially unsafe issues. Because these parts are so important for proper brake pad movement, failure often shows up as noise or uneven wear.
- Rattling or Clunking Noises: Loose or missing clips can allow the brake pads to rattle within the caliper bracket, especially over rough roads.
- Squealing or Scraping: Corroded hardware can prevent brake pads from retracting properly, causing them to drag lightly on the rotors and create a constant high-pitched squeal or scraping sound.
- Uneven Brake Pad Wear: When hardware fails, pads can get stuck at an angle, causing one part of the pad to wear down much faster than the other. This reduces the life of your pads and your stopping power.
- Vibration or Pulsing: While often a sign of warped rotors, sticky hardware can contribute to the uneven heat buildup that causes rotors to warp in the first place, a common issue on the S60.
Known Issues for 2011-2019 Volvo S60 Brakes
This generation of S60 is known for brake-related issues. Volvo has issued Technical Service Bulletins (TSBs) for brake noise (TJ34246) and, more significantly, for vibration or shuddering during braking (TJ36202.2.0). Many owners report premature rotor warping and are often happier with high-quality aftermarket parts than the original equipment. Additionally, a TSB for 2011-2017 models notes that a faulty right-side dust shield can cause the inner brake pad to wear out very quickly.
Choosing the Right Aftermarket Hardware Kit
For your S60, you don't need to insist on dealership parts. Quality aftermarket brands often meet or exceed original equipment (OEM) specifications and can be a better value. The brands available can be grouped into tiers based on reputation and quality.
Tier 1: OEM Quality or Better
These brands are well-regarded in forums and by mechanics for their quality and fit. They often include features like coated clips to resist corrosion.
- Centric: A major player in the brake industry, known for quality parts that fit correctly.
- Raybestos: Considered a leader in brake components, Raybestos provides reliable, high-quality hardware kits.
Tier 2: Standard Replacement
These brands provide a functional, budget-friendly option for a daily driver. They get the job done reliably.
- Carlson: A standard, dependable choice for brake hardware.
- Dynamic Friction: Offers reliable replacement-grade hardware.
- Beck Arnley: Focuses on providing parts that match the original form, fit, and function.
Tier 3: Economy
While functional, some brands may have a less favorable reputation for overall quality or longevity.
- Dorman: While a massive parts supplier, some professional mechanics express concerns about the consistency of their quality.
| Category | Price Range (Aftermarket) | Notes |
|---|---|---|
| Disc Brake Hardware Kit | $6.69 - $33.13 | Price is for one axle (front or rear). Always replace when changing pads. |
| Shop Labor to Install | $150 - $250 | This is the typical labor cost for a full brake pad and hardware replacement per axle. |
Pro Tip: The Electronic Parking Brake
If you plan to replace the rear brake hardware yourself, be aware that the 2011-2019 S60 has an Electronic Parking Brake (EPB). You MUST use a compatible automotive scan tool to put the rear calipers into "Service Mode" before you can press the piston back. Attempting to force the piston without this step will destroy the electric motor inside the caliper, leading to a very expensive repair.
Frequently Asked Questions
Do I really need to replace the hardware with every brake job?
Yes. It is highly recommended. The old clips lose tension from thousands of heat cycles and can be corroded. Reusing them is a common cause of brake noise and premature pad wear. For a few extra dollars, a new kit ensures your new pads work correctly.
Are there any recalls on my S60's brake hardware?
No, there are no recalls for the physical brake hardware, pads, or rotors. There have been software-related recalls for the Automatic Emergency Braking (AEB) system on some 2019-2020 models, but this does not involve the mechanical parts.
What's included in a typical disc brake hardware kit?
A kit for your S60 will typically include new anti-rattle clips (which the pads sit in) and sometimes new caliper guide pin boots. These are all the small parts needed to properly install a set of brake pads on one axle.
Can bad hardware cause my steering wheel to shake when braking?
Indirectly, yes. While a shaky steering wheel is usually caused by warped brake rotors, sticking or binding hardware can cause the uneven heat buildup that leads to rotor warping. This is a very common complaint on the S60, so ensuring your hardware is fresh is a good preventive measure.
Technical Specifications
Kit typically includes anti-rattle clips and guide pin boots for one axle. Some kits feature anti-corrosion coatings.
We Have This Part in Stock
The information in this article is provided for general reference and educational purposes only. Vehicle specifications, procedures, and part compatibility can vary by production date, trim level, and region. Always consult your vehicle's factory service manual and verify part numbers before purchasing or performing repairs. Safety-critical components such as airbags, seat belts, and braking systems should be installed by a qualified professional.
