A Guide to Replacing Fuel Injectors on Your 2011-2020 Ram 2500
Keep your 6.7L Cummins running strong by understanding its fuel injectors and how to replace them.
- Bosch is the OEM supplier; using new or certified remanufactured Bosch injectors is the safest choice for reliability.
- For 2019-2020 models, verify the CP4 fuel pump recall has been performed to prevent new injectors from being destroyed by pump failure.
- Always replace injectors as a full set of six, and replace the high-pressure connector tubes at the same time.
- Fuel contamination is a primary cause of injector failure; use quality fuel and filters to prolong injector life.
Signs of a Failing Fuel Injector
A bad fuel injector in your Ram 2500 can cause problems that range from annoying to engine-damaging. Because injectors wear out over time or can be damaged by dirty fuel, it's important to recognize the warning signs. Catching a problem early can save you from more expensive repairs.
- Rough Idle: The engine may shake or run unevenly when the truck is stopped.
- White or Black Smoke: Excessive white smoke at idle or black smoke when you accelerate can point to an injector that is leaking or not spraying correctly.
- Engine Knock: A sound like a hammer tapping inside the engine can be caused by an injector delivering too much fuel, or delivering it at the wrong time.
- Hard Starting: The engine may take longer than usual to start, especially when cold.
- Loss of Power: You might notice the truck feels sluggish or doesn't accelerate as it should.
- Fuel in Oil: A severely leaking injector can drip fuel into the cylinder, which then seeps past the piston rings and into the engine oil. This is a serious condition that can lead to major engine damage.
- Check Engine Light: Codes related to the fuel system or specific cylinders (like P0201-P0206) may appear. 🎬 Watch how to diagnose failed injectors using a scan tool.
CP4 Fuel Pump Recall on 2019-2020 Models
For 2019 and 2020 Ram 2500 models, be aware of a major recall for the Bosch CP4 high-pressure fuel pump. These pumps can fail and send metal debris throughout the entire fuel system, destroying the fuel injectors. If you own one of these model years, ensure the recall work has been completed, which involves replacing the CP4 pump with a more reliable CP3 pump. 🎬 Watch this detailed walkthrough of the CP4 to CP3 pump conversion. Failure to do so means new injectors could be ruined by a faulty pump.
Choosing the Right Aftermarket Injector
When it's time to replace your injectors, you have several options. For the 6.7L Cummins, the choice you make is critical for engine longevity and performance.
Brand Tiers
Tier 1: OEM (Bosch)
Bosch is the Original Equipment Manufacturer (OEM) for Cummins fuel injectors. This means buying a new or certified remanufactured Bosch injector is the same as getting a part from the dealer. They are widely considered the most reliable and trouble-free option. While they are the most expensive, they provide factory performance and durability. Many experts recommend using only new or Bosch-certified remanufactured injectors to avoid problems.
Tier 2: Reputable Aftermarket Brands (BD Diesel, Industrial Injection, DDP)
Brands like BD Diesel and Industrial Injection offer both stock replacement and performance-oriented injectors. They often build their injectors using new Bosch components. These can be a good choice, especially if you are looking for a slight performance upgrade. However, quality can sometimes be inconsistent with remanufactured parts, so it's important to buy from a trusted source with a good warranty.
Tier 3: Budget-Friendly Brands (Dorman, Standard Ignition, etc.)
While brands like Dorman and Standard Motor Products offer injectors at a lower price point, they are generally not recommended for the high-stress environment of a common-rail diesel engine. The tight tolerances and extreme pressures of the Cummins fuel system demand high-quality components. Using lower-quality injectors can lead to premature failure, poor performance, and even engine damage, costing more in the long run.
New vs. Remanufactured
It is almost always recommended to replace all six injectors at once, especially on a higher-mileage engine. This ensures all cylinders are balanced and reduces the chance of another failure soon after. Also, always replace the high-pressure connector tubes when you replace the injectors to ensure a perfect seal and prevent leaks.
🎬 See a step-by-step guide on replacing injectors and connector tubes.Cost to Replace 2011-2020 Ram 2500 Fuel Injectors
| Part Type | Estimated Cost (Set of 6) |
|---|---|
| New OEM (Bosch) | $2,400 - $4,000+ |
| New Aftermarket (Performance) | $3,900 - $4,600+ |
| Remanufactured (Bosch/Reputable) | $1,500 - $2,700 |
| Shop Labor | $800 - $1,500 |
Note: Prices are estimates and can vary based on location, brand, and the specific condition of your vehicle. A Reddit user reported a dealership quote of $26,000 for a full injector replacement, highlighting the extreme cost variation possible.
Frequently Asked Questions
Do I have to replace all six injectors at once?
It is highly recommended. Injectors wear at a similar rate. Replacing just one failing injector often leads to another one failing shortly after, costing you more in labor. Replacing them as a set ensures balanced engine performance and reliability.
What causes fuel injectors to fail on the 6.7L Cummins?
The most common causes are fuel contamination (dirt, water, debris), inadequate fuel filtration, and normal high-mileage wear. The high-pressure fuel pump failure on 2019-2020 models is also a major cause of injector destruction. Using high-quality fuel and fuel additives can help extend injector life.
Is this a DIY job?
Replacing injectors on a 6.7L Cummins is an advanced DIY job. It requires removing the valve cover, rocker arms, and high-pressure fuel lines. Extreme cleanliness is critical to avoid contaminating the fuel system. The job also requires specific torque wrenches and a precise tightening sequence. For most owners, professional installation is recommended.
Was there a recall for fuel injectors on these trucks?
Yes, for some 2019 models, there was a recall (NHTSA 19V-498) for fuel injector lines that could leak and cause a fire. More importantly, 2019-2020 models were recalled for the CP4 high-pressure fuel pump, which can destroy the injectors when it fails.
Helpful Videos
Technical Specifications
The 2011-2020 Ram 2500 with the 6.7L Cummins engine uses a high-pressure common-rail (HPCR) fuel injection system. The injectors are solenoid-activated and must be able to withstand extreme fuel pressures. Different injectors are used for 2011-2012, 2013-2018, and 2019-2020 model year ranges.
