A Guide to the Brake Light Switch for the 2012-2020 Toyota Camry
Understanding how a small switch can cause major issues with your brake lights, starting system, and cruise control.
- A bad brake light switch affects more than just the lights; it can prevent your Camry from starting or shifting out of park.
- This is an easy and inexpensive DIY repair that most owners can complete in under 30 minutes.
- Always check the brake light bulbs and the 'STOP' fuse before assuming the switch is the problem.
- Quality aftermarket brands like Beck Arnley and Standard Ignition are reliable and cost-effective alternatives to OEM parts.
Is Your Camry Experiencing Electrical Gremlins? It Might Be the Brake Light Switch.
A failing brake light switch on a 2012-2020 Toyota Camry can cause a surprising number of problems that might not seem related to the brakes at first. Because this switch communicates with multiple vehicle systems, its failure can mimic other, more serious issues. Symptoms can range from the obvious, like non-working brake lights, to the confusing, such as the engine not starting or the gear shifter being stuck in Park.
Common Symptoms of a Failing Brake Light Switch
Before you suspect a dead battery or a bad starter, check if you're experiencing these common signs of a faulty brake light switch:
- Brake Lights Don't Work or Stay On: The most direct symptom is your brake lights either failing to illuminate when you press the pedal or staying on constantly, which can drain your battery.
- Car Won't Start: For Camrys with a push-button start, the system requires a signal from the brake light switch to confirm the pedal is pressed before the engine will start. A bad switch can prevent this signal, leading to a no-start condition.
- Shifter Stuck in Park: An automatic transmission's shift interlock feature prevents you from shifting out of Park unless the brake pedal is depressed. A faulty switch won't send the release signal.
- Cruise Control Malfunctions: The cruise control system deactivates when you tap the brakes. If the switch is faulty, cruise control may not engage or might shut off unexpectedly while driving.
- Warning Lights on Dash: A bad brake light switch can sometimes trigger warning lights for the ABS, Vehicle Stability Control (VSC), or Traction Control (TRAC) systems.
Check Fuses and Bulbs First
Before replacing the switch, always check the simple things first. Make sure none of your brake light bulbs have burned out. Also, check the 7.5-amp "STOP" fuse, which is typically located in the fuse panel inside the cabin under the dashboard. A blown fuse or bad bulb can mimic the symptoms of a failed switch.
Choosing the Right Aftermarket Brake Light Switch
When replacing the brake light switch, you don't necessarily need to buy the expensive OEM part from a dealer. Several reputable aftermarket brands offer quality replacements that provide excellent value. Aftermarket parts for this specific component are generally considered reliable.
- Premium Aftermarket (OEM-Equivalent): Brands like Beck Arnley are known for sourcing their parts from a global network of manufacturers, often including the same ones that supply Toyota. They focus on matching the original part's form, fit, and function. Vemo is another brand often seen in this quality tier.
- Standard Aftermarket: Brands such as Standard Ignition (SMP), Holstein, and True Tech are well-established in the market and produce reliable replacement parts that meet or exceed standard specifications. They offer a good balance of quality and price for the average Camry owner.
- Economy Options: The Replacement brand offers a cost-effective solution for getting your vehicle back on the road safely. While they may not have the same longevity or exact material finish as premium options, they are a functional and affordable choice.
Cost of Replacing a Toyota Camry Brake Light Switch
Replacing the brake light switch is one of the more affordable repairs you can perform on your Camry. The part itself is inexpensive, and if you choose to do it yourself, the savings are significant.
| Item | Estimated Cost |
|---|---|
| New OEM Part | $41 - $85 |
| New Aftermarket Part | $24 - $62 |
| Shop Labor | $59 - $140 |
| Total Professional Replacement | $100 - $162 |
DIY Installation is Easy
This is a great job for beginners. The switch is located on a bracket above the brake pedal. The process typically involves removing a plastic trim panel for access, unplugging the electrical connector, and giving the switch a 90-degree turn to release it. The new switch installs in the reverse order. The entire job can usually be done in under 30 minutes with basic tools.
Frequently Asked Questions (FAQ)
Is there a recall on the 2012-2020 Camry brake light switch?
No, there are no specific recalls for the brake light switch on the 2012-2020 Toyota Camry. There was a recall (NHTSA #12V091000) for the 2009 model year due to an issue with silicone grease contamination, but this did not extend to the 2012 model year and newer. There was also a recall for 2018-2019 models related to the brake vacuum pump, but this is a separate issue from the switch.
Can I still drive my Camry with a bad brake light switch?
It is not recommended. If your brake lights are not working, it creates a serious safety hazard as other drivers won't know when you are slowing down or stopping. If the switch has failed in a way that prevents you from starting the car or shifting out of park, you will be stranded.
How do I know if it's the switch or just a bad bulb?
The easiest way to check is to have a friend stand behind the car while you press the brake pedal. If all brake lights are out, the problem is likely the switch or a fuse. If only one light is out, it's almost certainly a burnt-out bulb. It is very unlikely for all bulbs to fail at the same time.
Does the new brake light switch need to be adjusted?
Some brake light switches are self-adjusting upon installation, while others may require manual adjustment to ensure the brake lights turn on and off at the correct pedal position. When installing, make sure the plunger on the switch is fully depressed when the brake pedal is released, but not so far that it prevents the pedal from returning to its resting position.
Helpful Videos
Technical Specifications
OEM Part Numbers: 84340-06010 84340-42020 84340-09291 84340-19025 84340-09070
Plunger-activated switch with a 4-blade male terminal connector. Typically mounts to the brake pedal support bracket.
We Have This Part in Stock
The information in this article is provided for general reference and educational purposes only. Vehicle specifications, procedures, and part compatibility can vary by production date, trim level, and region. Always consult your vehicle's factory service manual and verify part numbers before purchasing or performing repairs. Safety-critical components such as airbags, seat belts, and braking systems should be installed by a qualified professional.
