Jeep Cherokee Windshield Washer Pump Replacement Guide (2013-2018)
Is your washer fluid not spraying? Here’s what you need to know about fixing the windshield washer pump on your 2014-2018 Jeep Cherokee.
- If you own a 2014 Cherokee, verify that the S83 washer pump recall has been performed to prevent damage to the Body Control Module.
- The vehicle uses two separate pumps for the front and rear; failure of one is common. It's wise to replace both at the same time.
- Before replacing the pump, check fuses F43 (interior) and F25 (engine bay) and listen for the pump motor to rule out simple electrical issues.
- Replacement is a manageable DIY job that requires removing the driver's side wheel and fender liner to access the pumps.
Is Your Jeep Cherokee Washer Pump Failing?
A common issue on the 2014-2018 Jeep Cherokee is for a windshield washer pump to stop working. Usually, the first sign is when you pull the lever and nothing comes out, but you can still hear the wipers moving. You might notice that the front works but the rear doesn't, or vice-versa, since they are two separate pumps. In some cases, owners report that the failure was gradual, with the spray getting weaker over time.
Top 3 Symptoms of a Bad Washer Pump:
- No Spray from Nozzles: When you activate the washer, the wipers move but no fluid sprays on the glass.
- No Sound from Pump: You don't hear the familiar humming or whirring sound of the pump motor when you try to use it.
- Front or Rear Only Works: One of the two pumps has failed, so either the front or rear washer will work, but not both.
Critical Recall Information for 2014 Models
Certain 2014 Jeep Cherokee models are under a safety recall (NHTSA ID: 15V509000, FCA Recall S83). The original front washer pump can create a voltage spike that damages the Body Control Module (BCM), which can cause your front windshield wipers to stop working completely. The official fix is for a Jeep dealer to replace the front washer pump free of charge. Before replacing the pump yourself on a 2014 model, check if this recall work has been completed.
Choosing a New Aftermarket Washer Pump
When replacing the washer pump, you have the choice between an original equipment (OEM) part from Mopar or an aftermarket part. For a component like this, a quality aftermarket part can offer the same performance as OEM for a lower price.
Trico Windshield Washer Pumps: Trico is a well-known brand that produces OE-style replacement parts. Their pumps are designed for easy installation without needing special adjustments. They are a reliable and cost-effective alternative to the dealer part for resolving a failed pump.
Pro Tip: The front and rear pumps are often the same part. Since accessing them requires the same amount of labor, many owners and mechanics recommend replacing both pumps at the same time, even if only one has failed.
Windshield Washer Pump Replacement Cost
The cost to replace a washer pump on your Cherokee depends on the parts you choose and whether you do the job yourself.
| Part Type | Estimated Cost |
|---|---|
| New OEM (Mopar) | $44 - $65 |
| New Aftermarket (Trico) | $57.11 |
| Shop Labor | $98 - $143 |
Frequently Asked Questions
Where is the washer pump located on a 2014-2018 Jeep Cherokee?
The two washer pumps are attached to the bottom of the washer fluid reservoir. The reservoir itself is located inside the front driver's side fender well, behind the wheel liner.
Can I replace the washer pump myself?
Yes, this is a DIY-friendly job for someone with basic tools. The process involves lifting the front of the vehicle, removing the driver's side wheel, and taking out the plastic fender liner to get access. 🎬 Watch this step-by-step guide to locating and replacing the pump. The pumps pull straight out of rubber grommets on the reservoir. The job can take about 90 minutes.
My washer fluid is full but it won't spray. What else could it be?
Before replacing the pump, check the fuses. The washer system uses fuse F43 in the interior fuse box and F25 in the engine bay fuse box. 🎬 See exactly where to find the washer pump fuses and relays. Also, check for clogs. The small filter at the pump inlet can get clogged with slime or debris from old fluid, and the lines or nozzles can also get blocked.
🎬 Learn how to diagnose weak spray or clogged washer lines.Is there a difference between the front and rear washer pumps?
Physically, the pumps are often identical. However, some aftermarket kits may list different part numbers or include an adapter harness for one of the pumps. For the 2014-2018 Cherokee, you can typically use the same pump for both front and rear locations.
Helpful Videos
Technical Specifications
OEM Part Numbers: 68225066AA 68225066AB
Location: Bottom of washer fluid reservoir, inside driver's side fender well. Quantity: Two (front and rear).
We Have This Part in Stock
The information in this article is provided for general reference and educational purposes only. Vehicle specifications, procedures, and part compatibility can vary by production date, trim level, and region. Always consult your vehicle's factory service manual and verify part numbers before purchasing or performing repairs. Safety-critical components such as airbags, seat belts, and braking systems should be installed by a qualified professional.
