Lexus GS350 Engine Oil Pressure Switch Guide (2013-2020)
Understanding the signs of a failing oil pressure switch and how to choose a reliable replacement for your GS350.
- A lit oil pressure warning light is a critical alert; always check your oil level first before suspecting the switch.
- The oil pressure switch on the GS350 is a simple on/off switch, not a variable sensor for a gauge.
- There are no major recalls or TSBs for the oil pressure switch on the 2013-2020 GS350.
- Replacement is a simple DIY job, with the switch located on the front of the engine near the oil filter area.
Is a Failing Oil Pressure Switch a Serious Problem?
Yes, it can be. The switch itself is a small, inexpensive part, but its job is vital. If the switch fails, it can either falsely report low oil pressure, causing unnecessary alarm, or fail to report a genuine low-pressure situation. Ignoring a real low-pressure warning can lead to severe engine damage. If your oil pressure light comes on, you should stop the vehicle safely as soon as possible and check the oil level. Continuing to drive with confirmed low oil pressure can destroy the engine.
Symptoms of a Bad Oil Pressure Switch on a GS350
A failing oil pressure switch can be tricky because its symptoms can point to other, more serious issues. Here are the most common signs that the switch itself is the problem:
- Oil Pressure Light On or Flickering: The most obvious sign is the red oil can light illuminating on your dashboard. If you've checked your oil level and it's correct, the light may be on due to a faulty switch. A flickering light that comes and goes could also indicate a failing sensor.
- Incorrect Gauge Reading: While the GS350 primarily uses a warning light, a faulty switch can sometimes cause erratic behavior if tied to other vehicle systems, though this is less common.
- Warning Lights with No-Start Condition: Some GS350 owners have reported a strange issue where a cluster of warning lights (including "Engine Oil Pressure Low") appears, the radiator fans run constantly, and the car refuses to start. In some cases, this has been traced back to a faulty fuel pressure sensor, not the oil pressure switch, which causes a communication error with the ECU. 🎬 Watch: Diagnosing a GS350 no-start caused by sensor communication errors.
Check Your Oil Level First
Before assuming the switch is bad, always perform the most basic check: inspect your engine oil level using the dipstick. Low oil is the most common reason for a low oil pressure warning. If the level is low, top it off and see if the light goes away. If the level is normal, the switch is a likely suspect.
🎬 See: What your oil pressure warning light is trying to tell you.Known Issues, Recalls, or TSBs
Searches for the 2013-2020 Lexus GS350 did not reveal any specific recalls or Technical Service Bulletins (TSBs) directly related to the engine oil pressure switch. There have been several recalls for this vehicle generation, most notably for a low-pressure fuel pump that could cause the engine to stall. However, this is unrelated to the oil pressure system. Another recall concerned a brake pedal load-sensing switch on 2013 models. There are no widespread, documented issues pointing to premature or common failure of the oil pressure switch on this specific model.
Choosing a New Aftermarket Oil Pressure Switch
For a simple but critical part like an oil pressure switch, quality is important. While an OEM switch from Lexus is always a safe bet, quality aftermarket options can offer significant savings. Aftermarket brands can generally be grouped into tiers based on reputation and perceived quality.
Pro Tip: The oil pressure switch is located on the front of the engine block, near the crankshaft pulley and alternator. It can be accessed by removing the front belly pan.
Aftermarket Brand Tiers for Lexus GS350
- Tier 1 (OEM Equivalents & Reputable Brands): Brands like Standard Ignition (SMP) and Beck Arnley have a long history. Beck Arnley, in particular, has a reputation for sourcing parts from original equipment manufacturers for Japanese vehicles. While some forum users note a decline in quality over the years as they've sourced more parts from China, they are still often considered a reliable choice for import vehicles.
- Tier 2 (Value-Oriented Brands): Brands like Holstein, Facet, Global Parts, and True Tech fall into this category. They offer a cost-effective solution and can be a good choice for a straightforward part like a switch. However, long-term reliability and manufacturing consistency may not be on par with top-tier brands. For a critical sensor, weighing the cost savings against the potential for premature failure is important.
Cost of Replacing a Lexus GS350 Oil Pressure Switch
| Part Type | Estimated Cost |
|---|---|
| New OEM | $40 - $65 |
| New Aftermarket | $13 - $33 |
| Shop Labor | $75 - $150 |
Frequently Asked Questions
Can I replace the oil pressure switch myself?
Yes, this is a DIY-friendly job for someone with basic mechanical skills. The switch is located on the front of the engine and can be accessed from underneath the car. You will need to safely raise the vehicle, remove the splash shield, disconnect the electrical connector, and use a deep socket to unscrew the old switch. 🎬 Watch: Step-by-step guide to removing and replacing the oil pressure switch. An oil change is not strictly required, but you will lose a small amount of oil when the switch is removed.
What is the difference between an oil pressure switch and a sensor?
A switch, like the one in the GS350, is a simple on/off device that only activates a warning light when pressure drops below a fixed point. A sensor (or sending unit) provides a variable reading that can drive a physical gauge on the dashboard, showing the exact pressure. Your GS350 does not have a factory oil pressure gauge, only the warning light.
My oil light is on, but the oil level is full. What else could it be?
If the oil level is correct and a new switch doesn't fix the problem, the issue could be more serious. Potential causes include a clogged oil filter, using the wrong viscosity oil, a failing oil pump, or worn internal engine components causing a genuine loss of pressure. In this case, a professional diagnosis with a mechanical pressure gauge is necessary.
Are there any other sensors that can cause a false oil pressure warning?
Yes, forum users have reported that a failing fuel pressure sensor can cause a cascade of error messages on the GS350, including a low oil pressure warning and a no-start condition. This happens because the faulty sensor disrupts communication with the main computer. If you have multiple, seemingly unrelated warning lights, this is a possibility to investigate.
Helpful Videos
Technical Specifications
OEM Part Numbers: 83530-28020 83530-60020
The switch is a single-pin, on/off type sensor that triggers a warning light when oil pressure drops below a preset threshold (typically 5-7 PSI).
